Core i7-860 2860MHz LGA1156 TR

Technical details
Product type	Processor
Processor cache	8192 KB
Processor core voltage	0.6500-1.4000 V
Status	Discontinued
Launch date	Q3'09
Product name	Intel Core i7-860 (8M Cache, 2.80 GHz)
Born on date	Q3'09
Bus type units	GT/s
Bus bandwidth	2.5
Maximum memory	16 GB
Processor brand name	Intel Core i7 vPro
Last change	63903513
Product family	Previous Generation Intel Core i7 Processor
Processor
Processor model	i7-860
Processor front side bus	1333 MHz
Processor lithography	45 nm
Processor family	Intel Core i7
Box
Processor socket	LGA 1156 (Socket H)
Processor cores	4
CPU multiplier (bus/core ratio)	21
System bus rate	2.5 GT/s
Processor threads	8
Compatible chipsets	Intel® H55 Express, Intel® H57 Express, Intel® P55 Express, Intel® Q57 Express
Processor operating modes	64-bit
Processor boost frequency	3.46 GHz
Component for	PC
Processor cache	8 MB
Bus type	DMI
Processor frequency	2.8 GHz
Processor codename	Lynnfield
Processor cache type	Smart Cache
Processor series	Intel Core i7-800 Desktop series
Memory bandwidth supported by processor (max)	21 GB/s
Processor ARK ID	41316
Memory
ECC
Memory channels	Dual
Maximum internal memory supported by processor	16 GB
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	1066,1333 MHz
Weight & dimensions
Processor package size	37.5 x 37.5 mm
Energy management
VID Voltage Range	0.65 - 1.400 V
Thermal Design Power (TDP)	95 W
Operational conditions
Tcase	72.7 °C
Other features
Maximum internal memory	16384 MB
Intel® Virtualization Technology (Intel® VT)	VT-d,VT-x
Cache memory	8 MB
Graphics
On-board graphics card
Processor special features
Intel® vPro™ Technology
Intel® Hyper Threading Technology (Intel® HT Technology)
Intel® Turbo Boost Technology	1.0
Intel® AES New Instructions (Intel® AES-NI)
Enhanced Intel SpeedStep Technology
Intel Trusted Execution Technology
Intel Enhanced Halt State
Intel VT-x with Extended Page Tables (EPT)
Intel Demand Based Switching
Intel 64
Intel Virtualization Technology for Directed I/O (VT-d)
Intel Virtualization Technology (VT-x)
Conflict-Free processor
Features
Supported instruction sets	SSE4.2
PCI Express slots version	2.0
Execute Disable Bit
Idle States
Thermal Monitoring Technologies
CPU configuration (max)	1
Number of Processing Die Transistors	774 M
Embedded options available
Processing Die size	296 mm²
Number of Graphics & IMC Die Transistors	774 M
PCI Express configurations	1x16,2x8
Maximum number of PCI Express lanes	16
Physical Address Extension (PAE)	36 bit
Market segment	DT
EAN	0675901017282
Warranty	3 years
Source: Icecat.biz

With previous generation Intel® Core™ i7 processors access multiple applications faster and unleash incredible digital media creation. Experience great performance for everything you do with the combination of Intel® Turbo Boost Technology and Intel® Hyper-Threading Technology (Intel® HT Technology), which maximizes performance to match your workload.

Intel® Turbo Boost Technology maximizes speed for demanding applications, dynamically accelerating performance to match your workload—more performance when you need it the most.

Intel® HT Technology enables highly threaded applications to get more work done in parallel. With 8 threads available to the operating system, multi-tasking becomes even easier.

Intel® Smart Cache provides a higher-performance, more efficient cache subsystem. Optimized for industry leading multi-threaded games.

Integrated memory controller enables three channels of DDR3 1066 MHz memory, resulting in up to 25.6 GB/sec memory bandwidth. This memory controller's lower latency and higher memory bandwidth delivers amazing performance for data-intensive applications.
