| EAN | 5711045897467 |
| Source: Icecat.biz | |
CPU
LGA1155 socket for Intel® 3rd/2nd Generation Core i7/ i5/ i3/ Pentium® / Celeron® Processors**
Supports 32/22nm CPU
Supports Intel® Turbo Boost Technology 2.0*
* The Intel® Turbo Boost Technology 2.0 support depends on the CPU types.
** Refer to www.asus.com for Intel CPU support list
Chipset
Intel® Z77 Express Chipset
Memoria
4 x DIMM, max. 32GB, DDR3 2400(O.C.)*/2200(O.C.)*/2133(O.C.)/1866(O.C.)/1600/1333/1066 MHz, non-ECC, un-buffered memory
Dual channel memory architecture
Supports Intel® Extreme Memory Profile (XMP)
* Hyper DIMM support is subject to the physical characteristics of individual CPUs. Please refer to Memory QVL(Qualified Vendors List) for details.
ranuras de expansión
1 x PCI Express 3.0*/2.0 x16 slot [blue] (at x16 mode)
1 x PCI Express 2.0 x16 slot [black] (max. at x4 mode, compatible with PCIe x1 and x4 devices)
2 x PCI Express 2.0 x1 slot
2 x PCI slot
* PCIe 3.0 speed is supported by Intel® 3rd generation Core processors.
VGA
Integrated Graphics Processor- Intel® HD Graphics support
Multi-VGA output support: HDMI, RGB port
- Supports HDMI with max. resolution 1920 x 1200@60Hz
- Supports RGB with max. resolution 2048 x 1536@75Hz
- Maximum shared memory of 1696MB
Multi-GPU support
Supports ATI® Quad-GPU CrossFireX Technology
Storage
Intel® Z77 Express Chipset
- 2 x SATA 6.0 Gb/s ports (gray) with RAID 0, 1, 5, 10 support
- 4 x SATA 3.0 Gb/s ports (blue) with RAID 0, 1, 5, 10 support
- Supports Intel® Smart Response Technology, Intel® Rapid Start Technology, Intel® Smart Connect Technology*
* Supports on Intel® Core processor family with Windows 7 operating systems.
LAN
Realtek® 8111F Gigabit LAN controller
Audio
Realtek® ALC887 8-Channel High Definition Audio CODEC*
- Supports Jack-Detection, Multi-streaming and Front Panel Jack-Retasking
* Use a chassis with HD audio module in the front panel to support an 8-channel audio output
USB
Intel® Z77 Express Chipset- supports ASUS USB 3.0 Boost UASP Mode.*
- 4*USB 3.0 (2@back, 2@onboard)
- 8*USB 2.0 (4@back, 4@onboard)
* The USB 3.0 ports only support Windows® 7 or later versions. UASP standard only supports Windows® 8.
ASUS Unique Features
ASUS DIGI+ VRM
- Digital Power Control: Digital Power Design for the CPU and iGPU
- ASUS 4+1Phase Power Design
ASUS EPU
- EPU
ASUS Exclusive Features
- Network iControl featuring instant network bandwidth domination for top network program in use
- USB 3.0 Boost featuring the latest USB 3.0 UASP standard
- TurboV
- GPU Boost
- AI Charger
- Disk Unlocker featuring 3TB+ HDD support
- AI Suite II
- Anti Surge
- Low EMI Solution
- 100% Solid Capacitors
ASUS Quiet Thermal Solution
- ASUS Fanless Design: Stylish Heatsink solution
- ASUS Fan Xpert+
ASUS EZ DIY
- ASUS UEFI BIOS EZ Mode featuring friendly graphics user interface
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 2
- ASUS My Logo 2
ASUS Exclusive Overclocking Features Precision Tweaker 2:
- vCore: Adjustable CPU voltage at 0.005V increment
- vCCSA: 190-step system agent voltage control
- vDRAM Bus: 190-step Memory voltage control
- vPCH: 190-step Chipset voltage control
- iGPU: 127-step iGPU voltage control
SFS (Stepless Frequency Selection)
- BCLK/PCIE frequency tuning from 80MHz up to 300MHz at 0.1MHz increment
Overclocking Protection:
- ASUS C.P.R.(CPU Parameter Recall)
Back Panel I/O Ports
1 x PS/2 Keyboard port
1 x PS/2 Mouse port
1 x HDMI
1 x RGB
1 x LAN (RJ45) ports
2 x USB 3.0 ports
4 x USB 2.0/1.1 ports
3-jack 8-channel Audio I/O
Conectores Internos I/O
2 x USB 2.0/1/1 connectors support additional 4 USB ports
1 x USB 3.0 connector supports additional 2 USB ports
2 x SATA 6.0Gb/s connectors (gray)
4 x SATA 3.0Gb/s connectors (blue)
1 x CPU Fan connector (4-pin)
1 x Power Fan connector (3-pin)
2 x Chassis Fan connectors (4-pin)
Front panel audio connector
1 x S/PDIF Out Header
24-pin ATX Power connector
4-pin ATX 12V Power connector
System Panel
1 x COM port connector
1 x Clear CMOS jumper
BIOS
64 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI2.0, WfM2.0, SM BIOS 2.7, ACPI 4.0a, Multi-language BIOS, ASUS EZ Flash 2, ASUS CrashFree BIOS 3, F12 PrintScreen, F3 Shortcut Function and ASUS DRAM SPD (Serial Presence Detect) memory information
Manageability
WfM 2.0, DMI 2.0, WOL by PME, WOR by PME, PXE
Accesorios
2 x Serial ATA 6.0Gb/s cables
1 x I/O Shield
1 x User´s manual
1 x Support DVD
Support DVD
Drivers
ASUS Utilities
ASUS Update
Form Factor
ATX Form Factor, 12.0x 8.4 (30.5cm x 21.3cm)
