This product is end of life or currently not available.
Key Specifications
Choose one or multiple features to search for items that have the same specifications.Processor | |
Processor manufacturer | Intel |
Maximum number of SMP processors | 1 |
Compatible processor series | Intel® Celeron®, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® |
Processor socket | LGA 1200 |
Memory | |
Maximum internal memory | 64 GB |
Non-ECC | |
Supported memory clock speeds | 2133,2400,2666,2800,2933,3200 MHz |
Supported memory types | DDR4 |
Memory channels | Dual-channel |
Unbuffered memory | |
Memory slots type | DIMM |
Number of memory slots | 2 |
Weight & dimensions | |
Width | 197 mm |
Depth | 188 mm |
Networking | |
Ethernet LAN | |
Wake-on-LAN ready | |
LAN controller | Realtek RTL8111H |
Wi-Fi | |
Ethernet interface type | Gigabit Ethernet |
Internal I/O | |
USB 2.0 connectors | 1 |
CPU fan connector | |
ATX Power connector (24-pin) | |
Chassis intrusion connector | |
Front panel audio connector | |
TPM connector | |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
Number of SATA III connectors | 4 |
12V power connector | |
Back panel I/O ports | |
PS/2 ports quantity | 2 |
USB 2.0 ports quantity | 4 |
Ethernet LAN (RJ-45) ports | 1 |
VGA (D-Sub) ports quantity | 1 |
HDMI ports quantity | 1 |
HDMI version | 2.0 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
Storage controllers | |
Supported storage drive interfaces | SATA III |
Packaging content | |
Cables included | SATA |
Drivers included | |
Expansion slots | |
PCI Express x1 (Gen 3.x) slots | 1 |
BIOS | |
BIOS memory size | 128 Mbit |
BIOS type | UEFI AMI |
ACPI version | 6.0 |
Graphics | |
Maximum resolution | 4096 x 2160 pixels |
HDCP | |
Number of displays supported | 2 |
Features | |
Certification | FCC, CE ErP/EuP |
Motherboard chipset | Intel H510 |
Motherboard form factor | Micro ATX |
Audio output channels | 7.1 channels |
PC health monitoring | Fan, Voltage |
Windows operating systems supported | Windows 10 x64 |
Motherboard chipset family | Intel |
Component for | PC |
Audio chip | Realtek ALC887 / Realtek ALC897 |
EAN | 4710483935039 |
Warranty | 1 year |
Source: Icecat.biz |
PREMIUM 50A POWER CHOKE
ASRock’s premium 50A power chokes effectively make the saturation current up to three times better, thus providing enhanced and improved Vcore voltage to the motherboard.
Clever Access Memory
Conventional PC systems processor can only access a fraction of graphics memory and limits system performance. With Clever Access Memory, the data channel gets expanded to harness the full potential of GPU memory, removes the bottleneck and increase performance.
HDMI 4k @60Hz
Supports the most recent HDMI 4K 60Hz graphics output specification. With the larger bandwidth and increased frame rate, the motion on your screen becomes more fluid and less blurry.
Dual Graphics Outputs
Complete with two types of most used connectors! Packed with a D-Sub + HDMI combo, you have more graphics output options now.
High Density Glass Fabric PCB
High Density Glass Fabric PCB design that reduces the gaps between the PCB layers to protect the motherboard against electrical shorts caused by humidity.
Sapphire Black PCB
Pure black PCB appearance. The new Sapphire Black PCB represents rock-solid quality and gives the motherboard a more mysterious touch.
Water Pump Header
This is not only a standard CPU fan header, but also supports water pumps! This header provides a maximum of 2A power for supporting the most popular water pumps. User also can adjust the voltage of water pump to get higher cooling performance with lower noise.
Full Spike Protection
Some sensitive digital components on the motherboard are vulnerable to power surges, the excessive current may cause your system to malfunction immediately. ASRock Full Spike Protection includes various technologies to prevent your motherboard’s components from being damaged by these unexpected voltage spikes.
Live Update & APP Shop
ASRock Live Update & APP Shop is designed for your convenience. We provide various apps and support software for users to download. You can also easily optimize your system and keep your motherboard up to date with ASRock Live Update & APP Shop.
