ASROCK 990FX EXTREME9 socketAM3+ AMD 990FX DDR3 SATA3 USB3.0 Clear CMOS ATX
Manufacturer: ASROCK
ID: 990FX EXTREME9
Product unavailable
This product is end of life or currently not available.
This product is end of life or currently not available.
Key Specifications
Choose one or multiple features to search for items that have the same specifications.
Specifications
Description
Store availability
Delivery
Price development
| Processor | |
| Processor manufacturer | AMD |
| Maximum number of SMP processors | 1 |
| Compatible processor series | AMD Phenom II X2, AMD Phenom II X3, AMD Phenom II X4, AMD Phenom II X6, AMD Phenom II X8 |
| Processor socket | AM3+ |
| Memory | |
| Maximum internal memory | 64 GB |
| Non-ECC |  |
| Supported memory clock speeds | 2450,1066,1333,1600,2100 MHz |
| Supported memory types | DDR3 |
| Memory channels | Dual-channel |
| Unbuffered memory | |
| Memory slots type | DIMM |
| Number of memory slots | 4 |
| Weight & dimensions | |
| Width | 305 mm |
| Depth | 244 mm |
| Networking | |
| Ethernet LAN | |
| Bluetooth |  |
| Wake-on-LAN ready | |
| LAN controller | Intel® 82583V |
| Wi-Fi | |
| Ethernet interface type | Gigabit Ethernet |
| Internal I/O | |
| USB 2.0 connectors | 2 |
| CPU fan connector | |
| Number of COM connectors | 1 |
| ATX Power connector (24-pin) | |
| Number of EATX power connectors | 1 |
| Number of chassis fan connectors | 3 |
| Front panel audio connector | |
| Power fan connector | |
| EPS power connector (8-pin) | |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors | 2 |
| Number of SATA III connectors | 8 |
| Back panel I/O ports | |
| PS/2 ports quantity | 2 |
| USB 2.0 ports quantity | 4 |
| Firewire (IEEE 1394) ports | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Headphone outputs | 1 |
| Microphone in | |
| S/PDIF out port | |
| eSATA ports quantity | 2 |
| Digital audio optical out | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| Storage controllers | |
| RAID levels | 0, 1, 0+1, 5, JBOD |
| Supported storage drive interfaces | SATA III |
| Packaging content | |
| Cables included | SATA |
| Trial software | Antivirus, CyberLink MediaEspresso 6.5 |
| Drivers included | |
| Expansion slots | |
| PCI slots | 1 |
| PCI Express x16 slots | 4 |
| PCI Express x1 slots | 1 |
| PCI Express slots version | 2.0 |
| PCI Express configurations | 1x1, 1x4, 1x8, 1x16, 2x8 |
| BIOS | |
| BIOS memory size | 32 Mbit |
| BIOS type | UEFI AMI |
| ACPI version | 1.1 |
| Clear CMOS jumper | |
| Other features | |
| Controller interface type | AMD SB950 |
| Controller 2nd interface type | ASMedia ASM1061 |
| Quick installation guide | |
| Mac operating systems supported | |
| Graphics | |
| Parallel processing technology support | SLI |
| Features | |
| Certification | FCC, WHQL ErP/EuP |
| Motherboard chipset | AMD 990FX |
| Motherboard form factor | ATX |
| Audio output channels | 7.1 channels |
| Overclocking features | Asrock AXTU |
| Cooling type | Passive |
| Motherboard southbridge | AMD SB950 |
| Windows operating systems supported | |
| Power source type | ATX |
| Motherboard chipset family | AMD |
| Component for | PC |
| Audio chip | Realtek ALC898 |
| EAN | 4717677320695 |
| Warranty | 2 years |
| Source: Icecat.biz | |
- Premium Gold Caps, Multiple Filter Cap
- Supports Dual-Stack MOSFET (DSM), Digi Power, 12 + 2 power phase design
- Supports AM3+ Processor, 8-Core CPU
- Supports Dual Channel DDR3 2450(OC)
- 4 PCIe 2.0 x16 Slots, Support NVIDIA® 3-Way SLI, AMD 3-Way CrossFireX™
- 8 x SATA3, 2 x eSATA3, 8 x USB 3.0, 8 x USB 2.0
- Supports Hi-Density Power Connector
- Intel® Gigabit LAN
- Supports ASRock X-Boost, XFast 555, Fast Boot, Restart to UEFI, Dehumidifier, OMG, Internet Flash, Easy RAID Installer
- 7.1 CH HD Audio with Content Protection (Realtek ALC898 Audio Codec), supports THX TruStudio™
- Free Bundle : CyberLink MediaEspresso 6.5 Trial, Google Chrome Browser and Toolbar, 1 x Front USB 3.0 Panel with 2.5" HDD/SSD Rack
