AOPEN DE5500 Full system with i5-7287U 4GBx2 128GB SSD Iris Plus Graphics 650 2xHDMI 2.0

AOPEN
91.DEK00.E1A0
1669,90 € Visa Moms 0% Visa Moms 24%
Webblager: 20.07.2020 Uppskattad leveranstid: 20.07.2020
Produktspecifikation
Beskrivning
Tillgänglig / Leverans
Prisutveckling
Tekniska data
Antal per förpackning1 styck
Processor
Processorfrekvens1100 MHz
Processori5-7287U
ProcessorfamiljIntel Core i5
Processorkärnor2
Inbyggd processorcheckmark
Processorboostfrekvens3,7 GHz
Lagring
Total lagringskapacitet128 GB
Minne
Internminne4266 MB
Typ av internminneDDR4
Skärm
Inbyggd displaycross
Anslutningar
Antal LAN (RJ-45) anslutningar2
Hörlursutgångar1
Likströmsingångcheckmark
Antal HDMI-portar2
HDMI-version2.0
HDCPcross
RS-232Ccheckmark
Antal USB 3.0 (3.1 Gen 1) typ A-portar4
Vikt & dimension
Vikt1,12 kg
Höjd157,5 mm
Bredd166 mm
Djup48 mm
Strömtillförsel
Strömförbrukning (vanlig)65 W
Miljökrav
Intervall för relativ operativ luftfuktighet0 - 95%
Temperaturintervall (förvaring)-20 - 60 ° C
Temperatur vid drift0 - 50 ° C
Nätverk
Nätverksansluten (Ethernet)checkmark
Datahastighet för Ethernet-LAN10,100,1000 Mbit/s
Grafikstyrenhet
Maximal videoupplösning3840 x 2160 pixlar
HD-typ4K Ultra HD
Lagringsmedia
Inbyggd kortläsarecross
Typ av lagringsmediaSSD
Inbyggd lagringsmediacheckmark
Lagringsenhetens storlekM.2
LagringsmediaSSD
Ergonomi
Plug & Play-kompatibelcheckmark
Indikationercheckmark
Produktens färgSvart
På / av-knappcheckmark
Radio
FrekvensbandStöds inte
Förpackningens innehåll
Bruksanvisningcheckmark
Filformat
Videoformat som stödsHEVC/H.265
Grafiken
Video adapterIntel® HD Graphics
EAN4712947239189
Garanti3 år
Source: Icecat.biz

The Digital Engine DE5500 is supported by the 7th generation Intel® Core(available in i3, i5 and i7). It consumes little power due to the of this mobile processor. It supports a DDR4 dual channel memory with a maximum capacity of 32GB. The standard Digital Engine small form factor can easily be integrated into a kiosk or behind a screen for a digital signage application. Furthermore, the latest AOPEN intelligent Control (AiCU) is optional. This feature provides an easy management tool that can monitor and control the device.

Small form factor
This form factor ensures an easy integration into kiosks or behind screens. The AOPEN small form factor is a standard that is used for Digital Engine (DE) models. The size of our Digital Engine series is set to maximum 166x48x177 mm. Its width set to 166 mm. Do the math and you will see that a Digital Engine is an investment that will last, even after replacing the item in a kiosk or mount that already exists.

Trusted Platform Module 2.0
The TPM is a dedicated micro controller, designed to secure hardware through integrated cryptographic keys. This means the data on your hard drive will be encrypted to ensure your data is safe, even when your device gets stolen.

Intel Core-i Desktop platform
The DEX5550 and the DE5550 are both based on the Intel Core-I platform. More specifically, on the 6th generation Kaby Lake platform technology. These computing devices are available in i3, i5 and i7, and therefore in different SKU’s.

Integrated HEVC/H.265 10bit codec
These units support native hardware decoding for modern codecs like the HEVC/H265 10 bit. Offloading the CPU, the GPU handles the decoding of the video. This creates a fluent playback up to 60fps.

AOPEN intelligent Control
AOPEN Intelligent Control (AiCU) is built for global enterprise brands, AiCU enables network operators with an intelligent device management solution that automates industrial and commercial applications. AiCU brings cloud service and advanced embedded device control technology together into a single dashboard.
