MSI MEG Z590 Unify Mini-ITX - moderkort

MSI MEG Z590 Unify Mini-ITX - moderkort

Tillverkare: MSI
ID: MEG Z590I UNIFY
319,00 € Visa Moms 0% Visa Moms 24%
Spara 36,00 € norm. 355,00 €
Webblager: 10 st Beräknad leverans: 08.12 - 10.12
Produktspecifikation
Beskrivning
På lager i butiker 3
Leverans
Prisutveckling
Processor
ProcessortillverkareIntel
Kompatibla processorerIntel® Celeron®, Intel® Core™ i3, Intel Core i5, Intel Core i7, Intel Core i9, Intel® Pentium G
ProcessorsockelLGA 1200
Stödd processor uttagLGA 1200 (Socket H5)
Minne
Maximalt internminne64 GB
Icke ECCcheckmark
Minnets hastigheter2133,2666,2933,3200 MHz
Minnestyper som stödsDDR4
Minneskanaler stödDual-channel
obuffrat minnecheckmark
Minnesplatser, typDIMM
Antal minnesplatser2
Vikt & dimension
Bredd170 mm
Djup170 mm
Nätverk
Wi-Fi-standarder802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac),Wi-Fi 6 (802.11ax)
Bluetooth-version5.2
Nätverksansluten (Ethernet)checkmark
Bluetoothcheckmark
LAN-styrenhetIntel I225-V
Wi-Ficheckmark
Ethernet-gränssnitt typ2.5 Gigabit Ethernet
Wi-Fi-standardWi-Fi 6 (802.11ax)
WLAN-kontrollens modellIntel Wi-Fi 6E AX210
Intern I/O
USB 2.0 anslutning1
CPU fläkt anslutningcheckmark
ATX strömkontakt (24-pin)checkmark
Chassi genomgångsanslutningcheckmark
Ljudanslutning på framsidancheckmark
TPM anslutningcheckmark
Periferiska (Molex) strömkontakter (4-pin)3
EPS strömkontakt (8-polig)checkmark
USB 3.2 Gen 1 (3.1 Gen 1)-anslutningar1
Antal SATA III kontakter4
USB 3.1 (3.1 Gen 2)-anslutningar1
12V-kontaktcheckmark
Anslutningsmöjligheter
USB-anslutningUSB Type-A, USB Type-C
Antal USB 2.0 anslutningar2
Antal LAN (RJ-45) anslutningar1
Hörlursutgångar2
Uttag för mikrofon/linje incheckmark
WiFi-AP antenn jack2
Antal HDMI-portar1
HDMI-version2.0b
Antal Displayportar2
Antal Thunderbolt-portar2
DisplayPort-version1,4
Antal USB 3.0 (3.1 Gen 1) typ A-portar2
Antal USB 3.1 (3.1 Gen 2) typ A-portar2
Lagringskontroll
RAID-nivåer0,1,5,10
Antal lagringsenheter som stöds6
Typer av lagringsenheter som stödsHDD & SSD
Lagringsenhetsgränssnitt som stödsM.2,SATA III
Förpackningens innehåll
Kabel inkluderadSATA
Drivrutiner medföljercheckmark
Expansionsplatser
PCI Express x16 platser1
Antal M.2 (M)-platser2
BIOS
BIOS minnesstorlek256 mbit
BIOS-typUEFI AMI
ACPI-version6.2
Clear CMOS knappcheckmark
Grafiken
Maximal upplösning3840 x 2160 pixlar
Stöd för parallellprocessteknikStöds inte
Egenskaper
Moderkortets chipsetIntel Z590
Moderkort formfaktorMini-ITX
Ljudutgångskanaler7.1 kanaler
Antal monteringshål4
PC hälsoövervakningFan, Temperatur
Windows-operativsystem som stödsWindows 10 x64
Moderkort, chipsetfamiljIntel
Komponent förPC
LjudchippRealtek ALC1220P
EAN4719072802837
Garanti3 år
Source: Icecat.biz

FROZR HEATSINK DESIGN
MEG Z590I UNIFY features active cooling solution for the enthusiast gamers and prosumers. The Double Ball Bearing Design, Zero Frozr Technology and dedicated software functions enhance the user experience and provide the extreme performance.

FULLY CONTROLLABLE IN BIOS AND SOFTWARE
MSI motherboards let you manage speeds and temperatures for all your system and CPU fans. Total Fan Control allows you check your primary system characteristics in a simplified graphical interface. You can also set up to 4 temperature targets for CPU and motherboard, which will adjust the fan speeds automatically.

FROZR AI COOLING
Detecting CPU & GPU temperatures and automatically adjusting fan duty of system fans to a proper value by adopting MSI AI ENGINE.

OPTIMIZED FOR WATER COOLING
Designed to support the most popular All-In-One & customized water cooling solutions on the market. A dedicated water pump PIN header supports up to 3 amp, giving you full control of the water pump speed. A clearly marked ‘keep-out-zone’ allows for easy and safe installation and a perfect fit.

DIRECT 8 PHASES ROBUST POWER DESIGN
Unleash and sustain maximum performance with an aggressive VRM design built with direct 8 phases digital power phases. Combining INTERSIL digital PWM and 90A Smart Power Stage, MEG Z590I UNIFY is ready for the challenge of high-end processors.

CORE BOOST
Core Boost technology combines MSI’s premium layout and digital power design which allows for faster and undistorted current delivery to the CPU at pin-point precision. This creates the perfect conditions for multi-core CPU while doing

1-SECOND OVERCLOCKING!
MSI Game Boost enables one-second overclocking, giving you the performance boost you need to get more FPS.

MORE FOR PERFORMANCE
LOAD-LINE CALIBRATION

What you set, is what you get. LLC makes sure your CPU voltage remains 100% stable under any load. This greatly improves stability when demanding more CPU performance.

OVERVOLTAGE PROTECTION
Prevents potential short-circuit damage to the CPU and other critical components.

DIGITALL POWER DESIGN
A fully digital power design allows for faster and undistorted current delivery to the CPU at pin-point precision. Creating the perfect conditions for CPU overclocking.

PRE-INSTALLED IO SHIELD
Featuring the pre-installed IO shield, makes your installation process easier and safer. The patent-pending design protect your IO ports and also prevent electrostatic discharge damage, makes your motherboard a strong gaming foundation.

MORE USER FRIENDLY ENHANCEMENTS
XL CLIP

The enlarged PCI-E clip helps you swap or remove your devices easier. Keep the PCI-E slot stronger and safer.

EZ DEBUG LED
Run into trouble? Onboard LEDs for key components will indicate the source of the problem so you know exactly where to look to get up and running again.

MORE RELIABLE CIRCUIT TRANSMISSION
10 PCB layers allows for higher bandwidth and faster transfer speeds. This is also beneficial for reliable circuit transmission.

PCB WITH 2OZ THICKENED COPPER
An enhanced PCB design with 2oz thickened copper increases conductivity, improving heat dissipation and performance reliability especially during overclocking.

FORTIFY YOUR SYSTEM WITH PCI-E STEEL ARMOR
MSI PCI Express Steel Armor slots are secured to the motherboard with extra solder points and support the weight of heavy graphics cards. When every advantage in games counts, Steel Armor shields the point of contact from electromagnetic interference.

ULTIMATE MOTHERBOARD PROTECTION
Double ESD protection doubles up the grounding layer around the mounting holes, preventing static discharge surges from damaging the motherboard.

SUPER STABLE GAMING WITH THE HIGHEST QUALITY COMPONENTS
MSI uses high quality components rated for reliable operation even under extreme conditions.

TITANIUM CHOKE III
Ti choke III has 30% improved power delivery efficiency compared to its predecessor, allowing for improved overclocking stability

90A SMART POWER STAGE
Next-gen 3-in-1 Mosfet package capable of delivering more power at precise timings with fewer components.

SOLID CAP
Japanese made Solid CAPs are built for high-reliability motherboards with their aluminum core design. These capacitors have low Equivalent Series Resistance (ESR) and are rated to work for more than 10-years.

LIGHTNING GEN 4 M.2
Utilizing 11th Gen Intel processors, MSI Z590 motherboards feature latest Lightning Gen 4 M.2 which is the fastest onboard storage solution on the market with up to 64 Gb/s transfer speed.

FAST AND FUTURE-READY STORAGE
MSI motherboards support all the latest storage standards, which allows users to connect any ultra-fast storage device. Higher efficiency makes your work easier.

OPTANE: BOOST YOUR HDD TO PERFORM LIKE AN SSD
PC Enthusiasts can now enjoy the performance of an SSD on their HDD by coupling it with the new Intel® Optane™ Memory device. Intel® Optane™ technology provides an unparalleled combination of high throughput, low latency, high quality of service, and high endurance.

EASY RAID SETUP WITH M.2 GENIE
Looking to go all out in terms of raw data speed and put multiple SSDs in RAID 0? Setting this up can prove to be quite the challenge. That’s why we created M.2 Genie, a brilliant feature to make setting up RAID 0 for M.2 and U.2 much easier and less time consuming.

A HUGE STEP OF DDR PERFORMANCE
MSI OC LAB does not merely work hard on extreme overclocking. The XMP memory profile has great improvement on performance and efficiency for Z590. Easy to enable XMP profile with auto power settings to get the best memory speed and stability.

EXTREME STABILITY & COMPATIBILITY TESTING
MSI conducts thorough memory testing with the most popular memory brands under extreme conditions to ensure your system runs stable no matter what. Our memory partners include brands like Corsair, Crucial, Kingston, G.Skill and many more to optimize memory modules, configurations and even improve overclocking.

MEMORY FORCE – EASY TUNING YOUR DDR4 MEMORY
MSI MEG series motherboards feature exclusive Memory Force function which shows the current state of DDR4 memory. This patent-pending feature simplifies the complicated training flow to an easy graphic that helps you determine the direction of overclocking without the redundant reboot and testing process.

EASY OVERCLOCKING WITH XMP PROFILE
The XMP (Extreme Memory Profiles) in MSI BIOS are tested and certified by MSI OC LAB. It is easy to enable with auto power settings to get the best memory speed and stability.

MSI CENTER
MSI brand new MSI Center unifies a suite of MSI software utilities into a single centralized application. Take control of advanced motherboards features and unleash endless possibilities.

CLICK BIOS 5
Get more from a loaded BIOS designed for ease of use. Fine-tune the motherboard for gaming performance, efficiency, or overclocking world records!

GAME BOOST
Quickly overclock your CPU with a single button for more performance.

XMP
Choose from a preset XMP profile and automatically overclock compatible DDR memory.

M-FLASH
Conveniently flash or upgrade the BIOS in a few minutes from the CMOS Setup Utility.

HARDWARE MONITOR
Get immediate access to your critical hardware information in real-time including temperature, memory capacity, clock speed, and voltage.

MEMORY TRY IT
Get extreme speed out of your system memory and get more performance.

SEARCH & FAVORITES
A permanent search & favorite option in the top right corner moves you through the BIOS menus quickly.

Sound Clearly. Tune Smartly.
The AI-powered noise cancellation is trained through deep neural network (DNN), the model is generated with more than 500 million data, simulate the way human brain works. When a sound is heard, the model automatically recognizes and separate vocal sound from background noises; hence, filtering out all the unwanted Noise.

HIGH-BANDWIDTH AND LOW-LATENCY NETWORK
2.5Gbps LAN provides incredible data transfer speed faster than general Gigabit LAN. This is a premium solution for demanding users.

SURFACING WITH THE REAL MU-MIMO TECHNOLOGY
The latest Wi-Fi 6E solution supports 6GHz spectrum, Bluetooth 5.2, two-way MU-MIMO and BSS color technology, provide up to 4X network capacity and efficiency in the high signal density environment, delivering speeds up to 2400Mbps.

OPTIMIZE ONLINE GAMING TRAFFIC FOR LOWER LATENCY!
MSI LAN Manager automatically classifies and prioritizes the latency-sensitive applications for online games, giving you the best online gaming experience with low latency.

MSI LAN MANAGER
- Automatically prioritizes games above other applications
- Allows you to change applications' traffic priority
- Allows you to customize bandwidth for each application

DUAL THUNDERBOLT™ 4 PORTS
Experience Thunderbolt 4 with unprecedented interface bandwidth speeds up to true 40Gbp and support for up to six daisy-chained devices. Additionally, Maximum 8K display support, Multi-Port Accessory Architecture and USB 4.0 compliant provide reliable connectivity and better user experience.

USB FRONT TYPE-C
MSI gaming motherboards support USB Front Type-C that allows gamers to connect with the latest USB devices. Built up a system with MSI PC case to have the most convenient experience.

HIGH DEFINITION ALC1220P AUDIO PROCESSOR
Supports DSD Super Audio CD playback & recording (64x better than regular CD quality)

HIGH QUALITY AUDIO CAPACITORS
A high fidelity sound experience with exceptional acoustics and realism for studio level headphones is ensured.

GOLDEN AUDIO JACKS
Keep your sound perfect by transmit your audio with pure digital signal

ALL NEW NAHIMIC 3 - FOR NEXT LEVEL AUDIO IMMERSION
Get ready to be amazed by the all new Nahimic 3 and live the gaming immersion like never before! With simple and intuitive new UI, the Nahimic 3 not only further enhances in game 3D surround sound, but also offers even more finite control over your music, movies, and conference calls.

ISOLATED AUDIO DESIGN
Like a dedicated sound card, audio components and circuits have been laid on a reserved motherboard section and electrically isolated.

SEPARATED AUDIO LAYERS FOR CLEAN LEFT & RIGHT CHANNELS
Using separated layers in the PCB ensures equally pristine sound quality for both left and right audio channels.

Audio Boost protects your ears by eliminating those annoying loud popping sounds when you plug/unplug devices or turn your PC on/off.
