Tätä tuotetta ei valmisteta enää tai sitä ei ole tällä hetkellä saatavilla.
Prosessori | |
Emolevyn piirisarja | Intel C242 |
Yhteensopivat prosessorit | Intel® Xeon® |
Prosessorin kanta | LGA 1151 |
Sisäänrakennettu prosessori | |
Tuettujen prosessorien lukumäärä | 1 |
Muisti | |
Sisäinen enimmäismuisti | 64 GB |
ECC | |
DIMM-paikkojen lukumäärä | 4 |
Non-ECC | |
Tuettujen DIMM-moduulien kapasiteetit | 4GB, 8GB, 16GB |
Tuetut muistityypit | DDR4 |
Tuettu UDIMM kellotaajuus | 2400,2666 MHz |
UDIMM-muistin enimmäismäärä | 64 GB |
Liitettävyys | |
Ethernet LAN (RJ-45) -portit | 4 |
VGA (D-Sub) -porttien määrä | 1 |
SATA III-liittimiä | 6 |
IPMI LAN (RJ-45) -portti | |
USB 3.2 (3.1 sukupolvi 1) A-tyypin porttien määrä | 4 |
USB 3.2 Gen 2 (3.1 Gen 2) A-tyypin porttien määrä | 2 |
Paino ja mitat | |
Paino | 7,5 kg |
Tuotteen korkeus | 44 mm |
Tuotteen leveys | 430 mm |
Tuotteen syvyys | 380 mm |
Virranhallinta | |
Virtalähde | 250 W |
Syöttöjännite | 4 A |
80 PLUS certification | 80 PLUS Bronze |
AC-syöttötaajuus | 50 - 60 Hz |
AC-syöttöjännite | 100 - 240 V |
Ympäristöolosuhteet | |
Varastointilämpötila | -40 - 70 °C |
Käyttölämpötila (T-T) | 10 - 35 °C |
Säilytysympäristön kosteus | 20 - 90% |
Verkko | |
Ethernet LAN | |
LAN-kontrolleri | Intel I210 |
Ethernet LAN -datanopeudet | 1000 Mbit/s |
Ethernet-liitännän tyyppi | Gigabitti Ethernet |
Tallennusväline | |
Hot-swap-kiintolevypaikkoja | |
RAID-tasot | 0,1,5,10 |
Tuettujen tallennusasemien lukumäärä | 2 |
Tuetut tallennusasemien koot | 2.5,3.5,M.2 |
Tuetut tallennusasemaliitännät | M.2, Serial ATA III |
Pakkaustiedot | |
Pakkauksen paino | 11,7 kg |
Laajennuspaikat | |
PCI Express x16 (Gen 3.x)-paikat | 1 |
M.2 (M) paikkojen määrä | 2 |
Suunnittelu | |
Sertifiointi | BSMI, CE, C-Tick, FCC(Class B) |
Alustatyyppi | Teline ( 1U ) |
LED-merkkivalot | Hälytys, HDD, LAN, Teho |
Tuotteen väri | Musta, Metallinen |
Uudelleenkäynnistyspainike | |
On/off-kytkin | |
Grafiikka | |
Sisältyvän näytönohjaimen malli | Aspeed AST2500 |
Sisäisen näytönohjaimen muisti | 64 MB |
Ominaisuudet | |
Yhteensopivat käyttöjärjestelmät | Windows Server 2016 RedHat Enterprise Linux SuSE Linux Enterprise Server CentOS Vmware Citrix XenServer |
EAN | 4718017147293 |
Takuu | 3 vuotta |
Source: Icecat.biz |
Delivers a workload optimized solution
RS100-E10-PI2 supports the latest Intel® Xeon® E processors, which are 1.36x faster than the previous generation and operate at a maximum of 95W for leading performance. It supports four memory slots that fit up to 64GB of DDR4 2666 for memory-intensive computing.
Flexible expansion for better storage
RS100-E10-PI2 offers the performance required by demanding visual computing workloads with support of one NVIDIA graphics card, or you can utilize one PCIe Gen3 x16 slot to expand I/O capacity.
RS100-E10-PI2 fits two internal 3.5-inch HDDs and comes with optical disc drive, and offers different storage choice for storage support. Two M.2 slots accommodate 22110-size SSDs with support for additional OS storage and PCIe Gen3 bandwidth — 5.3X faster than 6 Gb/s SATA III — for faster boot speeds.
High-speed mini-SAS HD connections
RS100-E10-PI2 comes with a mini-SAS HD connector that support up to four SATA for 6Gb/s connectivity with external devices and cleaner cable routing. RS100-E10-PI2 also supports ASUS PIKE II 3000 series, the latest enterprise storage solution, featuring support for 12Gb/s SAS storage and integrated RAID data protection. With ASUS PIKE cards, you can immediately improve the storage capacity and performance of RS100-E10-PI2, making it a great upgrade option.
Quad Intel® Gigabit Ethernet
RS100-E10-PI2 features quad server-class Intel® Ethernet ports and teaming support that speed up the network bandwidth and the failover function ensures uninterrupted network connection. This suits virtualization applications perfectly which requires ultrafast and reliable network. Optional ASUS PEB series Ethernet cards are available for networking upgrade.
Comprehensive IT infrastructure management
RS100-E10-PI2 features an optional embedded iKVM module and is bundled with ASUS Control Center to provide comprehensive out-of-band and in-band management features for small and mid-size businesses.
The optional ASMB9-iKVM module supports remote BIOS updates, fan control, standalone KVMs, video recording, and BSOD capture, providing around-the-clock remote monitoring and diagnostics — even if the operating system is down or offline — through a user-friendly, web-based graphical interface that works with all major browsers.
ASUS Control Center (ACC) is a centralized and integrated IT management platform for monitoring and controlling ASUS commercial products, including servers, workstations and digital signage. ACC enables remote BIOS updates, monitoring of multiple systems via mobile devices, and one-click software updates and dispatching, allowing easier server management for any IT infrastructure.
Enhanced serviceability
With its power button located on the front I/O panel, RS100-E10-PI2 is designed to provide easier maintenance and deployment for diverse applications.
Quick initialization guidance
RS100-E10-PI2 provides instant system information during initialization as well as any unusual diagnostic results for more efficient IT operation and easy troubleshooting.
