Specifications
Description
Store availability
Delivery
Price development
Manuals
| Technical details | |
| Pallet type | 800 x 1200 mm |
| System requirements | |
| Windows operating systems supported | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 x64, Windows 7, Windows 7 x64, Windows 8.1, Windows 8.1 x64 |
| Server operating systems supported | Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019 |
| Ports & interfaces | |
| USB version | 2.0/3.2 Gen 1 (3.1 Gen 1) |
| USB port |  |
| Weight & dimensions | |
| Weight | 3.23 kg |
| Height | 391 mm |
| Width | 243 mm |
| Depth | 320 mm |
| Input capacity | |
| Auto document feeder (ADF) input capacity | 80 sheets |
| Scanning | |
| Greyscale levels | 256 |
| Maximum scan size | 355.6 x 215.9 mm |
| Optical scanning resolution | 600 x 600 DPI |
| Enhanced scan resolution | 1200 x 1200 DPI |
| Colour scanning | |
| Duplex scanning | |
| Input colour depth | 48 bit |
| Output colour depth | 24 bit |
| ADF scan speed (b/w, A4) | 40 ppm |
| ADF scan speed (colour, A4) | 40 ppm |
| Duplex ADF scan speed (b/w, A4) | 80 ipm |
| Duplex ADF scan speed (colour, A4) | 80 ipm |
| Output greyscale depth | 8 bit |
| Energy management | |
| Power consumption (typical) | 26 W |
| Power supply type | AC |
| Input voltage | 100-240 V |
| Output voltage | 24 V |
| Power consumption (off) | 0.1 W |
| Power consumption (PowerSave) | 1.7 W |
| Power consumption (standby) | 8.6 W |
| Output current | 1.9 A |
| Auto power off | |
| Power consumption (sleep) | 1.7 W |
| AC input frequency | 50 - 60 Hz |
| Sleep mode | |
| Operational conditions | |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating temperature (T-T) | 5 - 35 °C |
| Storage relative humidity (H-H) | 10 - 90% |
| Networking | |
| Wi-Fi standards | 802.11b, 802.11g |
| Security algorithms | WEP, WPA-PSK, WPA2-PSK, WPA3 |
| Supported network protocols | DHCP, APIPA (Auto IP), WINS/NetBIOS, DNS Resolver, mDNS, SNMPv1/v2c/v3, ICMP, Web Services(Scan), HTTP/HTTPS server, LLMNR responder, SNTP Client, LDAP, RA, ICMPv6 |
| Ethernet LAN | |
| Wi-Fi | |
| IPv6 support | |
| Paper handling | |
| Legal | |
| Scanning media types supported | Business Card, Plain paper, Plastic Card, Recycled paper, Thick paper, Thin paper |
| Maximum scan width | 21.6 cm |
| Media thickness (min) | 0.08 mm |
| Card thickness (max) | 1.32 mm |
| Maximum ISO A-series paper size | A4 |
| Maximum scan length | 35.6 cm |
| Long-paper mode | |
| Paper tray media weight | 40 - 200 g/m² |
| Packaging data | |
| Package weight | 3.88 kg |
| Package depth | 243 mm |
| Package height | 320 mm |
| Package width | 391 mm |
| Quantity per pack | 1 pc(s) |
| Other features | |
| Certification | GS Mark, WHQL, WHQL, ISIS, Wi-Fi CERTIFIED - WPA3 Enterprise, WPA3 Personal, Wi-Fi Protected Setup, Wi-Fi Direct, KofaxTM 5,10 - VRS Elite 5.2.0, Kofax Express 3.3.0 |
| Spare part retention | 5 year(s) |
| Design | |
| Display | LCD |
| Scanner type | ADF + Sheet-fed scanner |
| Display diagonal | 10.9 cm (4.3") |
| Product colour | Black, White |
| Control type | Buttons |
| Touchscreen | |
| Built-in display | |
| Colour display | |
| Performance | |
| Internal memory | 512 MB |
| Maximum duty cycle | 120000 pages per month |
| Sensor type | Dual CIS |
| Scan file formats | JPEG, PDF, TIFF |
| Scanning noise level | 59 dB |
| Scan to | PC |
| Scan drivers | ISIS, TWAIN, WIA |
| Daily duty cycle (max) | 6000 pages |
| Ultrasonic sensor | |
| Logistics data | |
| Products per pallet | 40 pc(s) |
| Master (outer) cases per pallet | 40 pc(s) |
| Layers per pallet | 5 pc(s) |
| Country of origin | China |
| Master (outer) cases per pallet layer | 8 pc(s) |
| Pallet gross weight | 170.4 kg |
| Pallet gross height | 17.5 cm |
| Harmonized System (HS) code | 84716070 |
| EAN | 4977766814737 |
| Warranty | 1 year |
| Source: Icecat.biz | |
Designed to enable businesses to simplify complex workflow or operational processes. Securely capture your documents to easily share and collaborate with colleagues whether they're at home or in the office. Large intuitive 10.9cm touchscreen with 56 configurable shortcuts Personalised multi-user experience Secure workgroup sharing Advanced image processing and batch scanning Features Auto Start scan, ultrasonic multifeed sensor, Separation Switch, Scan Preview, CIS Cleaning Alarm Includes Brother ScanEssentials software Driver compatibility with TWAIN (WIN and macOS), WIA, ISIS, Linux SANE
