Corsair 850W CX Series CX850M - Power supply

Manufacturer: CORSAIR
ID: CP-9020099-EU
Product unavailable
This product is end of life or currently not available.

Key Specifications

Choose one or multiple features to search for items that have the same specifications.
Specifications
Description
Store availability
Delivery
Price development
Ports & interfaces
Floppy disk drive connectorcheckmark
PCI Express connectorcheckmark
Motherboard power connector20+4 pin ATX
Floppy drive power connector2
Number of SATA power connectors8
ATX Power connector (20-pin)checkmark
Peripheral (Molex) power connectors (4-pin)6
CPU power connector (4+4 pin)checkmark
PCI Express power connectors (6+2 pin)4
Cabling typeSemi-Modular
Weight & dimensions
Weight3.27 kg
Energy management
Input current6 - 12
Nominal power850 W
Efficiency85%
Power factor0.99
Power Factor Correction (PFC) typeActive
Combined power (+3.3V)130 W
Combined power (+12V)840 W
Combined power (+5V)130 W
Combined power (-12V)9.6 W
Combined power (+5Vsb)15 W
Max output current (+3.3V)25 A
Max output current (+12V)70 A
Max output current (+5V)25 A
Max output current (-12V)0.8 A
Max output current (+5Vsb)3 A
AC input frequency47 - 63 Hz
AC input voltage100 - 240 V
Maximum input current (@110V)+12V,+3.3V,+5V,+5Vsb,-12V
Packaging data
Package weight3.53 kg
Package depth290 mm
Package height130 mm
Package width216 mm
Package typeBox
Certificates
CertificationErP Lot 6
80 PLUS certification80 PLUS Bronze
Cooling
Number of fans1
Cooling typeActive
Fan locationTop
Design
Product colourBlack
Performance
Form factorATX
PurposePC
ATX version2.3
EPS version2.92
EAN843591054508
Warranty1 year
Source: Icecat.biz

CX Series Modular power supply units are an excellent choice for basic system builds and desktop PC computer
upgrades, offering high reliability, low noise, easy installation. The flexible modular cabling system lets you use only the
cables you need, and 80 PLUS Bronze certified efficiency means less excess heat, lower noise, and lower power bills. The
large-diameter, thermally controlled fan makes CX Series Modular quieter at idle, and the large diameter reduces noise
even when you’re pushing your system hard. And, the matte black finish, black-sleeved cables and black connectors help
give your system a restrained, high-tech look.

Top Three Call Outs

- Modular cabling system lets you use only the cables you need
- Built and tested to strict standards for trouble-free installation and smooth operation
- 80 PLUS Bronze certified efficiency for low noise and lower power bills

Additional Features

- Up to 85% energy efficiency means less heat generation and lower energy bills.
- 0.99 Active Power Factor Correction provides clean and reliable power.
- Universal AC input from 100-240V.
- A dedicated single +12V rail offers maximum compatibility with the latest components.
- Over-voltage and over-power protection, under-voltage protection, and short circuit protection provide maximum safety to your critical system components.
- Extra long fully-sleeved cables support full tower chassis.
- It supports the latest ATX12V v2.3 standard and is backward compatible with ATX12V 2.2 and ATX12V 2.01 systems.
- ErP Lot 6 Compliant
- A three year warranty and lifetime access to Corsair’s legendary technical support and customer service.
