TS TC M900 TINY Intel Q170

Manufacturer: LENOVO
ID: 10FM000CMX
Product unavailable
This product is end of life or currently not available.
Specifications
Description
Store availability
Delivery
Price development
Technical details
Device typeSSD
Processor
Processor modeli5-6500T
Number of processors installed1
Processor lithography14 nm
Processor familyIntel Core i5
Processor socketLGA1151
SteppingR0
Processor cores4
System bus rate8 GT/s
Processor threads4
PCI Express slots version3.0
Processor operating modes64-bit
Processor boost frequency3.1 GHz
Processor cache6 MB
Tcase66 °C
FSB Paritycross
Bus typeDMI3
PCI Express configurations1x16,2x8,1x8+2x4
Processor frequency2.5 GHz
Thermal Design Power (TDP)35 W
Processor codenameSkylake
Maximum number of PCI Express lanes16
Processor cache typeSmart Cache
Processor seriesIntel Core i5-6500 Desktop series
Maximum internal memory supported by processor64 GB
Memory types supported by processorDDR3L-SDRAM,DDR4-SDRAM
Memory clock speeds supported by processor2133,1333,1600,1866 MHz
Memory bandwidth supported by processor (max)34.1 GB/s
Memory channels supported by processorDual
ECC supported by processorcross
Memory voltage supported by processor1.35 V
Memory
Internal memory typeDDR4-SDRAM
Memory slots2x SO-DIMM
Maximum internal memory32 GB
Memory clock speed2133 MHz
Internal memory4 GB
Optical drive
Optical drive typeN
Ports & interfaces
Ethernet LAN (RJ-45) ports1
Headphone outputs1
Microphone incheckmark
DC-in jackcheckmark
DVI portcross
DisplayPorts quantity2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity6
Weight & dimensions
Weight1.3 kg
Height34.5 mm
Width179 mm
Depth182.9 mm
Energy management
Power supply65 W
Networking
Wi-Fi standardsWi-Fi 5 (802.11ac)
Ethernet LANcheckmark
Bluetoothcheckmark
Wi-Ficheckmark
Ethernet LAN data rates10,100,1000 Mbit/s
Top Wi-Fi standardWi-Fi 5 (802.11ac)
Storage
Drive capacity128 GB
Total storage capacity128 GB
Card reader integratedcross
Storage mediaSSD
Number of storage drives installed1
Certificates
Energy Star certifiedcheckmark
RoHS compliancecheckmark
Operating system/software
Operating system installedWindows 7
Operating system architecture64-bit
Packaging content
Display includedcross
Mouse includedcheckmark
Keyboard includedcheckmark
Design
Chassis typeMini PC
Product colourBlack
Placement supportedHorizontal/Vertical
Volume1 L
Water cooling systemcross
Intel segment taggingEnterprise,Professional
Graphics
Graphics card Open GL supportcheckmark
On-board graphics card modelIntel® HD Graphics 530
Discrete graphics card modelNot available
On-board graphics cardcheckmark
On-board graphics card base frequency350 MHz
On-board graphics card dynamic frequency (max)1100 MHz
On-board graphics card burst frequency1100 MHz
On-board graphics card ID0x1912
Maximum on-board graphics card memory1.7 GB
Number of displays supported (on-board graphics)3
On-board graphics card DirectX version12
On-board graphics card OpenGL version4.4
On-board graphics card familycheckmark
Processor special features
Supported instruction setsSSE4.2,AVX 2.0,SSE4.1
Processor codeSR2BZ
Intel® My WiFi Technology (Intel® MWT)cross
Intel® Identity Protection Technology (Intel® IPT)checkmark
Intel® Anti-Theft Technology (Intel® AT)cross
Intel® vPro™ Technologycheckmark
Intel® Hyper Threading Technology (Intel® HT Technology)cross
Intel® Turbo Boost Technology2.0
Intel® Quick Sync Video Technologycheckmark
Intel® InTru™ 3D Technologycheckmark
Intel® Wireless Display (Intel® WiDi)checkmark
Intel FDI Technologycross
Intel® Clear Video HD Technology (Intel® CVT HD)checkmark
Intel Dual Display Capable Technologycross
Intel® Insider™checkmark
Intel Fast Memory Accesscross
Intel Flex Memory Accesscross
Intel® Smart Cachecheckmark
Intel® AES New Instructions (Intel® AES-NI)checkmark
Enhanced Intel SpeedStep Technologycheckmark
Execute Disable Bitcheckmark
Idle Statescheckmark
Thermal Monitoring Technologiescheckmark
Intel Trusted Execution Technologycheckmark
Scalability1S
CPU configuration (max)1
Intel Enhanced Halt Statecheckmark
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)checkmark
Intel VT-x with Extended Page Tables (EPT)checkmark
Embedded options availablecross
Intel Demand Based Switchingcross
Intel Rapid Storage Technologycross
Graphics & IMC lithography14 nm
Intel® Small Business Advantage (Intel® SBA)checkmark
Intel TSX-NIcheckmark
Intel® Secure Keycheckmark
Thermal solution specificationPCG 2015A
Intel 64checkmark
Intel Stable Image Platform Program (SIPP)checkmark
Intel® OS Guardcheckmark
Intel Virtualization Technology for Directed I/O (VT-d)checkmark
Intel® Built-in Visuals Technologycheckmark
Intel Clear Video Technologycheckmark
Intel HD Graphicscheckmark
Intel Secure Key Technology version1.00
Intel Small Business Advantage (SBA) version1.00
Intel Virtualization Technology (VT-x)checkmark
Intel Stable Image Platform Program (SIPP) version1.00
Intel TSX-NI version1.00
Processor package size37.5 mm
Conflict-Free processorcheckmark
Intel® Unite™checkmark
Processor ARK ID88183
Performance
Motherboard chipsetIntel Q170
Product typeMini PC
EAN889955663191
Warranty1 year
Up to Windows 10
It is the familiar feel of Windows, only improved. The Start menu is back, better than ever. Expand it, customize it, make it yours. Work with more of the devices you care about, such as printers, cameras, and USBs. Boot up and resume quickly with technologies like InstantGo. And enjoy additional security features that help to safeguard you against device theft and malicious software.

The Most Powerful Desktop Per Cubic Inch
The M900 Tiny equipped with the latest 6th Generation Intel® Core™ i Series processor and optional PCIe SSD is up to 48% more powerful than its nearest competitors and 128% more powerful than the first generation Tiny. That makes it the most powerful desktop per cubic inch.

Tiny Form Factor
ThinkCentre M900 Tiny is an ultrasmall form factor. It offers mounting solutions, including support for standard VESA mounts and Tiny-in-One configurations – which transform your PC into a space-saving modular all-in-one. Tiny desktops fit just about anywhere, while still delivering reliable, enterprise-level performance.

The Most Powerful Tiny Desktop per Cubic Inch
With the latest Intel Core i series processors and PCIe SSD, the ThinkCentre Tiny M900 is the most powerful tiny desktop per cubic inch. Experience a 1l powerhouse that delivers cutting-edge processing and a turbo boost to your productivity.

Intel® vPro™-Ready
The M900 Tiny includes Intel® vPro™ technology to make enterprise-level manageability even more convenient and cost-efficient. The built-in management capabilities of Intel vPro allow IT administrators to access your PC remotely, even when the system if powered off, to diagnose and repair systems and automate security patches and updates – ensuring your system is always up and running.

Stable Image Platform Program
Intel's Stable Image Platform Program (SIPP) facilitates the often tricky process of transitioning from one technology generation to the next.

Optional Ease of Use
A unique Lenovo solution, tool-less access to your Tiny PC delivers convenient servicing and minimum downtime.

Multiple Monitor Support
Maximize productivity with independent display support for up to three monitors. The expanded work area and easier navigation between applications help reduce errors and improve productivity as you extend your desktop across multiple monitors.

Keyboard Power-On Support
If you choose to mount this compact unit on the back of your monitor, you can still power on conveniently from the front, by simply pressing Alt+P on a USB-connected keyboard. Also compatible with wireless keyboards.

Fast Data Transfer
Move data between the M900 Tiny and other devices quickly with USB 3.0 — it’s up to 10 times faster than previous USB technologies, and is backward-compatible.

Optional ThinkCentre Dust Shield
Extend the life of your M900 Tiny with unique, Lenovo-developed dust filters. The filters reduce dust intake by almost 40 percent – so your machine will last longer, with less maintenance. What's more, the dust filter has an unobtrusive design and can be conveniently removed for cleaning.Test simulated three-year usage in an end-user environment using 400g of free-settling dust. The test compared the amount of dust accumulated inside a ThinkCentre Tiny with a dust filter and a ThinkCentre Tiny without one.

Tested to Military Specifications
Military-specification testing validates the ruggedness, durability, and quality of this PC by testing against multiple parameters.

Variety of I/O Support
No matter your port needs, this desktop has you covered, with support for USB 3.0 (including fast charge), DisplayPort, VGA, HDMI, LAN, and serial connections.
