This product is end of life or currently not available.
Weight & dimensions | |
Weight | 2.7 kg |
Height | 165 mm |
Width | 371 mm |
Depth | 371 mm |
Operational conditions | |
Operating temperature (T-T) | -40 - 80 °C |
Packaging content | |
Quick installation guide | |
Mounting kit | |
Performance | |
Frequency band | 5.15 - 5.875 GHz |
Antenna gain level (max) | 20 dBi |
Impedance | 50 Ω |
Features | |
Antenna type | Directional antenna |
Product colour | Grey, White |
Antenna connector type | N-type |
Voltage Standing Wave Ratio (VSWR) | 2.0:1 |
Front to back ratio | -30 dB |
Ultraviolet (UV) resistant | |
Survival wind speed | 216 km/h |
Sidelobes level | -10 dB |
EAN | 4718937593125 |
Warranty | 1 year |
Source: Icecat.biz |
When building a wireless LAN infrastructure, the IT staff should consider several factors influencing transmission efficiency, such as different facility sizes, building materials and interior divisions. To address this concern, a comprehensive WLAN solution for wireless LAN deployments can be critical.
To facilitate the installation process, ZyXEL offers a complete range of 2.4 GHz and 5 GHz antennas, cables and other accessories for Access Points (APs) to enable customized wireless deployments for almost any installation types.
The ZyXEL antennas are available in various space, directionality, gain and range capabilities in different form factors. With appropriately coupled antennas and APs, businesses will enjoy prefect WLAN environments with superior coverage, better reliability and higher data rates in all kinds of facilities. In addition, the ZyXEL lowloss cables can be used to extend the distance between any ZyXEL 2.4 GHz and 5 GHz AP and the antenna through N-plug or RP-SMA connectors.
This document is to help our customers with the selection of suitable antennas and related accessories for their deployment.
