| Technical details | |
| Device type | SSD |
| Processor | |
| Processor model | J3355 |
| Number of processors installed | 1 |
| Processor lithography | 14 nm |
| Processor family | Intel Celeron |
| Processor socket | BGA 1296 |
| Stepping | B1 |
| Processor cores | 2 |
| System bus rate | 5 GT/s |
| Processor threads | 2 |
| PCI Express slots version | 2.0 |
| Processor operating modes | 64-bit |
| Processor boost frequency | 2.50 GHz |
| Processor cache | 2 MB |
| Tjunction | 105 °C |
| PCI Express configurations | 1x2+2x1,4x1 |
| Processor frequency | 2.00 GHz |
| Thermal Design Power (TDP) | 10 W |
| Processor codename | Apollo Lake |
| Maximum number of PCI Express lanes | 6 |
| Processor cache type | Smart Cache |
| Maximum internal memory supported by processor | 8 GB |
| Memory types supported by processor | DDR3L,LPDDR3-SDRAM,LPDDR4-SDRAM |
| Memory clock speeds supported by processor | 1866,2400 MHz |
| ECC supported by processor | ![]() |
| Memory | |
| Internal memory type | DDR3 |
| Memory slots | 2x SO-DIMM |
| Maximum internal memory | 8 GB |
| Memory clock speed | 1600 MHz |
| Memory channels | Dual |
| Memory layout (slots x size) | 1 x 4 GB |
| Internal memory | 4 GB |
| Ports & interfaces | |
| Serial ports quantity | 1 |
| PS/2 ports quantity | 1 |
| USB 2.0 ports quantity | 4 |
| Ethernet LAN (RJ-45) ports | 1 |
| Headphone outputs | 1 |
| Microphone in | ![]() |
| DC-in jack | ![]() |
| DVI port | ![]() |
| VGA (D-Sub) ports quantity | 1 |
| HDMI ports quantity | 1 |
| HDMI version | 1.4b |
| DisplayPorts quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| Weight & dimensions | |
| Weight | 1.3 kg |
| Package weight | 2.1 kg |
| Height | 43 mm |
| Width | 165 mm |
| Depth | 190 mm |
| Energy management | |
| Power supply | 40 W |
| Power supply input voltage | 100 - 240 V |
| Power supply input frequency | 50 - 60 Hz |
| Operational conditions | |
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | 0 - 40 °C |
| Networking | |
| Wi-Fi standards | 802.11b,802.11g,Wi-Fi 4 (802.11n) |
| Cabling technology | 10/100/1000Base-T(X) |
| Ethernet LAN | ![]() |
| Wake-on-LAN ready | ![]() |
| Wi-Fi | ![]() |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Top Wi-Fi standard | Wi-Fi 4 (802.11n) |
| Storage | |
| Drive capacity | 128 GB |
| Compatible memory cards | SD,SDHC,SDXC |
| Optical drive type | N |
| Total storage capacity | 128 GB |
| Card reader integrated | ![]() |
| SSD interface | SATA |
| Number of SSDs installed | 1 |
| Storage media | SSD |
| Number of storage drives installed | 1 |
| Certificates | |
| Certification | FCC, CE, BSMI, RCM, VCCI, R&TTE, CB, BSMI, ETL, CCC |
| Energy Star certified | ![]() |
| RoHS compliance | ![]() |
| Operating system/software | |
| Operating system installed | ![]() |
| Drivers included | ![]() |
| Packaging content | |
| AC adapter included | ![]() |
| Cables included | AC |
| Display included | ![]() |
| Manual | ![]() |
| VESA mount included | ![]() |
| Other features | |
| Panel mounting interface | 75 x 75,100 x 100 mm |
| Number of displays supported | 3 |
| Design | |
| Chassis type | Mini PC |
| Cable lock slot | ![]() |
| Product colour | Black |
| Placement supported | Horizontal/Vertical |
| Volume | 1 L |
| Cable lock slot type | Kensington |
| VESA mounting | ![]() |
| Water cooling system | ![]() |
| Graphics | |
| On-board graphics card model | Intel® HD Graphics 500 |
| Discrete graphics card model | Not available |
| On-board graphics card | ![]() |
| On-board graphics card base frequency | 250 MHz |
| On-board graphics card burst frequency | 700 MHz |
| Number of execution units | 12 |
| Maximum on-board graphics card memory | 8 GB |
| Number of displays supported (on-board graphics) | 3 |
| Discrete graphics card | ![]() |
| Processor special features | |
| Processor code | SR2Z8 |
| Intel® Identity Protection Technology (Intel® IPT) | ![]() |
| Intel® Anti-Theft Technology (Intel® AT) | ![]() |
| Intel® Smart Response Technology | ![]() |
| Intel Smart Connect Technology | ![]() |
| Intel® Hyper Threading Technology (Intel® HT Technology) | ![]() |
| Intel® Turbo Boost Technology | ![]() |
| Intel® Quick Sync Video Technology | ![]() |
| Intel® InTru™ 3D Technology | ![]() |
| Intel® Wireless Display (Intel® WiDi) | ![]() |
| Intel® Clear Video HD Technology (Intel® CVT HD) | ![]() |
| Intel® Insider™ | ![]() |
| Intel® AES New Instructions (Intel® AES-NI) | ![]() |
| Enhanced Intel SpeedStep Technology | ![]() |
| Execute Disable Bit | ![]() |
| Idle States | ![]() |
| Thermal Monitoring Technologies | ![]() |
| Intel Trusted Execution Technology | ![]() |
| CPU configuration (max) | 1 |
| Intel Enhanced Halt State | ![]() |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | ![]() |
| Intel VT-x with Extended Page Tables (EPT) | ![]() |
| Embedded options available | ![]() |
| Intel Rapid Storage Technology | ![]() |
| Intel® High Definition Audio (Intel® HD Audio) | ![]() |
| Intel® Small Business Advantage (Intel® SBA) | ![]() |
| Intel® Secure Key | ![]() |
| Intel 64 | ![]() |
| Intel Stable Image Platform Program (SIPP) | ![]() |
| Intel® OS Guard | ![]() |
| UART | ![]() |
| Intel Virtualization Technology for Directed I/O (VT-d) | ![]() |
| Intel Secure Boot | ![]() |
| Intel Clear Video Technology | ![]() |
| Intel Virtualization Technology (VT-x) | ![]() |
| Processor package size | 24 x 31 mm |
| Conflict-Free processor | ![]() |
| Processor ARK ID | 95597 |
| Performance | |
| Motherboard chipset | Intel SoC |
| Compatible processor series | Intel® Celeron® G, Intel Pentium G |
| Product type | Mini PC |
| Password protection | ![]() |
| Audio chip | Realtek ALC662 |
| EAN | 4046047103201 |
Fanless 1-litre PC suitable for 24/7 operation
The Shuttle XPC slim PC-System DX3000XA is a fanless and virtually noiseless PC which is suitable for continuous 24/7 operation. It is equipped with an energy-efficient Intel Celeron J3355 "Apollo Lake" processor, 128 GB SSD and 4 GB RAM. DX3000XA can be easily upgraded with another 2.5" storage drive. The powerful integrated graphics supports triple monitoring on DisplayPort, HDMI and VGA outputs. This slim nettop PC is versatilely applicable in noise-sensitive environments and also for professional applications.
HDMI interface
Goodbye cable spaghetti! Modern flat-screen TVs and large-format TFT screens can be connected to this Mini-PC with just a single thin cable. Often the audio output is also transferred in brilliant quality via the HDMI cable.
High-resolution DisplayPort
The DisplayPort connector allows for connections with digital high-resolution displays. Besides picture signal, DisplayPort cables can also lead digital sounds signals in excellent quality.
Low energy consumption
Thrift is a virtue. In terms of power consumption this Mini-PC sets an example. It is not just good for the environment but for your pocket, too.
Fanless and whisper-quiet
The fanless technology used in this PC means it is incredibly quiet. Doing away with these mechanical components also reduces the number of wearing parts, making the machine more durable and stable.
You can rely on SSD
This is where an energy-saving "Solid State Drive" should be used. This drive technology guarantees extremely short access times, the highest data transmission rates and considerably lower energy consumption compared to conventional hard disks. SSDs have no mechanical components at all, are therefore subject to less wear and tear and consequently benefit from a longer service life.
Multiformat card reader
At last – no more searching for missing digital camera leads. Simply insert the memory card and you can access all stored photos and videos immediately.
Anti-theft protection
The Kensington Lock forms part of the anti-theft system. As with many other Notebooks, this Mini-PC can also be safely locked, ensuring long-term enjoyment from your Shuttle product.
Fan-less external power supply
A highly effective external power supply provides the Shuttle Mini-PC with its energy. And since it works without a fan, it is completely noise-free.
Connections without all those annoying cables
Data is transferred by WLAN completely without cables. Accessing the Internet and local network resources (e.g. printers) is now child's play when within range of an access point/hotspot.
Just 2.5" HDDs
An extremely compact PC housing offers less space for drives, that's why this Mini-PC uses slimline 2.5-inch hard disks. The advantage of this is that there's less noise, less heat generated and reduced power consumption. However small hard disks in a small housing does not have to mean less memory. Modern 2.5" HDDs are every bit as good as their 3.5" brothers.
Optimal air flow
Warm air is transported out of the chassis by means of cleverly arranged components, which enables a large number of parts to be cooled simultaneously in the air flow. At no time can heat build up and adversely affect the stability of the system.
The fastest connection to external peripheral devices available to date
The USB 3.0 connectors of this model allow for data transfer of up to 5 Gbit/s (625 MB/s). This enables external devices such as USB hard disks to be connected and run at nearly the same speed as their internal siblings. USB 3.0 is downward compatible so that also devices of previous USB generations can be hooked up.
Communication in the fast lane
The integrated gigabit LAN chipset opens up completely new possibilities for communication with no restriction on the speed of data transfer. Say goodbye to information bottlenecks, whether in the company network or for home Internet access.
The Shuttle XPC slim PC-System DX3000XA is a fanless and virtually noiseless PC which is suitable for continuous 24/7 operation. It is equipped with an energy-efficient Intel Celeron J3355 "Apollo Lake" processor, 128 GB SSD and 4 GB RAM. DX3000XA can be easily upgraded with another 2.5" storage drive. The powerful integrated graphics supports triple monitoring on DisplayPort, HDMI and VGA outputs. This slim nettop PC is versatilely applicable in noise-sensitive environments and also for professional applications.
HDMI interface
Goodbye cable spaghetti! Modern flat-screen TVs and large-format TFT screens can be connected to this Mini-PC with just a single thin cable. Often the audio output is also transferred in brilliant quality via the HDMI cable.
High-resolution DisplayPort
The DisplayPort connector allows for connections with digital high-resolution displays. Besides picture signal, DisplayPort cables can also lead digital sounds signals in excellent quality.
Low energy consumption
Thrift is a virtue. In terms of power consumption this Mini-PC sets an example. It is not just good for the environment but for your pocket, too.
Fanless and whisper-quiet
The fanless technology used in this PC means it is incredibly quiet. Doing away with these mechanical components also reduces the number of wearing parts, making the machine more durable and stable.
You can rely on SSD
This is where an energy-saving "Solid State Drive" should be used. This drive technology guarantees extremely short access times, the highest data transmission rates and considerably lower energy consumption compared to conventional hard disks. SSDs have no mechanical components at all, are therefore subject to less wear and tear and consequently benefit from a longer service life.
Multiformat card reader
At last – no more searching for missing digital camera leads. Simply insert the memory card and you can access all stored photos and videos immediately.
Anti-theft protection
The Kensington Lock forms part of the anti-theft system. As with many other Notebooks, this Mini-PC can also be safely locked, ensuring long-term enjoyment from your Shuttle product.
Fan-less external power supply
A highly effective external power supply provides the Shuttle Mini-PC with its energy. And since it works without a fan, it is completely noise-free.
Connections without all those annoying cables
Data is transferred by WLAN completely without cables. Accessing the Internet and local network resources (e.g. printers) is now child's play when within range of an access point/hotspot.
Just 2.5" HDDs
An extremely compact PC housing offers less space for drives, that's why this Mini-PC uses slimline 2.5-inch hard disks. The advantage of this is that there's less noise, less heat generated and reduced power consumption. However small hard disks in a small housing does not have to mean less memory. Modern 2.5" HDDs are every bit as good as their 3.5" brothers.
Optimal air flow
Warm air is transported out of the chassis by means of cleverly arranged components, which enables a large number of parts to be cooled simultaneously in the air flow. At no time can heat build up and adversely affect the stability of the system.
The fastest connection to external peripheral devices available to date
The USB 3.0 connectors of this model allow for data transfer of up to 5 Gbit/s (625 MB/s). This enables external devices such as USB hard disks to be connected and run at nearly the same speed as their internal siblings. USB 3.0 is downward compatible so that also devices of previous USB generations can be hooked up.
Communication in the fast lane
The integrated gigabit LAN chipset opens up completely new possibilities for communication with no restriction on the speed of data transfer. Say goodbye to information bottlenecks, whether in the company network or for home Internet access.
