DiskStation DS916+

Manufacturer: SYNOLOGY
ID: DS918+
Product unavailable
This product is end of life or currently not available.
Specifications
Description
Store availability
Delivery
Price development
Processor
Processor modelJ3455
Processor manufacturerIntel
Processor lithography14 nm
Processor familyIntel Celeron
Processor socketBGA 1296
SteppingB1
Processor cores4
Processor codeSR2Z9
Processor threads4
PCI Express slots version2.0
Processor operating modes64-bit
Processor boost frequency2.3 GHz
On-board graphics card modelIntel® HD Graphics 500
Processor cache2 MB
CPU configuration (max)1
Tjunction105 °C
PCI Express configurations1x2+2x1,4x1
Processor frequency1.5 GHz
Thermal Design Power (TDP)10 W
Processor codenameApollo Lake
Processor cache typeSmart Cache
Maximum internal memory supported by processor8 GB
ECC supported by processorcross
Processor package size24 x 31 mm
Conflict-Free processorcheckmark
Memory
Internal memory typeDDR3
Memory slots2
Maximum RAM supported8 GB
Internal memory4 GB
Ports & interfaces
Ethernet LAN (RJ-45) ports2
eSATA ports quantity1
USB 3.0 (3.1 Gen 1) Type-A ports quantity2
USB portcheckmark
Weight & dimensions
Weight2.28 kg
Height166 mm
Width199 mm
Depth223 mm
Energy management
Power consumption (typical)28.8 W
Power consumption (sleep)12.6 W
AC input frequency50 - 60 Hz
AC input voltage100 - 240 V
Power supply locationExternal
Power supply unit (PSU) capacity100 W
Operational conditions
Operating altitude0 - 5000 m
Operating relative humidity (H-H)5 - 95%
Storage temperature (T-T)-20 - 60 °C
Operating temperature (T-T)5 - 40 °C
Networking
Ethernet LANcheckmark
Wake-on-LAN readycheckmark
Wi-Ficross
Ethernet LAN data rates10,100,1000 Mbit/s
iSCSI supportcheckmark
Storage
RAID levels0,1,5,6,10,JBOD
Supported file systemsBTRFS,FAT,HFS+,NTFS,ext3,ext4
RAID supportcheckmark
Storage drive size2.5/3.5"
Storage drive interfaceM.2, Serial ATA
Number of storage drives supported4
Storage drive sizes supported2.5,3.5,M.2
Storage drives installedcross
Maximum supported storage capacity40 TB
Installed storage drive typecross
Supported storage drive typesHDD & SSD
Hot-swap drive bayscheckmark
Supported storage drive interfacesSerial ATA, Serial ATA II, Serial ATA III
Certificates
CertificationFCC Class B
CE Class B
BSMI Class B
Operating system/software
Mac compatibilitycheckmark
Operating system installedDiskStation Manager
Operating system version6.2.3
Windows operating systems supportedWindows 10,Windows 7
Mac operating systems supportedMac OS X 10.11 El Capitan
Packaging content
Cables includedAC, LAN (RJ-45)
External power adaptercheckmark
Quick installation guidecheckmark
Other features
Processor ARK ID95594
Design
Chassis typeDesktop
Cable lock slotcheckmark
LED indicatorsHDD, Power, Status
Product colourBlack
Number of fans2 fan(s)
Cooling typeActive
Fan diameter9.2 cm
Cable lock slot typeKensington
Drive bay lockingcheckmark
Fan diameter 29.2 cm
Graphics
On-board graphics adapter base frequency250 MHz
On-board graphics adapter dynamic frequency (max)750 MHz
On-board graphics adapter burst frequency750 MHz
Maximum on-board graphics adapter memory8 GB
Number of displays supported (on-board graphics)3
Processor special features
Intel® Identity Protection Technology (Intel® IPT)checkmark
Intel® Anti-Theft Technology (Intel® AT)cross
Intel® Smart Response Technologycross
Intel Smart Connect Technologycross
Intel® Hyper Threading Technology (Intel® HT Technology)cross
Intel® Turbo Boost Technologycross
Intel® Quick Sync Video Technologycheckmark
Intel® InTru™ 3D Technologycross
Intel® Wireless Display (Intel® WiDi)cross
Intel® Clear Video HD Technology (Intel® CVT HD)checkmark
Intel® Insider™cross
Intel® AES New Instructions (Intel® AES-NI)checkmark
Enhanced Intel SpeedStep Technologycheckmark
Execute Disable Bitcheckmark
Idle Statescheckmark
Thermal Monitoring Technologiescheckmark
Intel Trusted Execution Technologycross
Intel Enhanced Halt Statecheckmark
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)checkmark
Intel VT-x with Extended Page Tables (EPT)checkmark
Embedded options availablecheckmark
Intel Rapid Storage Technologycross
Intel® High Definition Audio (Intel® HD Audio)checkmark
Intel® Small Business Advantage (Intel® SBA)cross
Intel® Secure Keycheckmark
Intel 64checkmark
Intel Stable Image Platform Program (SIPP)cross
Intel® OS Guardcross
UARTcheckmark
Intel Virtualization Technology for Directed I/O (VT-d)checkmark
Number of execution units12
Maximum number of PCI Express lanes6
Intel Secure Bootcheckmark
Intel Clear Video Technologycheckmark
Intel Identity Protection Technology version1.00
Intel Secure Key Technology version1.00
Intel Secure Boot Technology version1.00
Intel Small Business Advantage (SBA) version0.00
Intel Smart Response Technology version0.00
Intel Virtualization Technology (VT-x)checkmark
Intel Stable Image Platform Program (SIPP) version0.00
Intel Smart Connect Technology version0.00
Memory types supported by processorDDR3L, LPDDR3-SDRAM, LPDDR4-SDRAM
Memory channels supported by processorDual
Home Networking (by Intel)checkmark
Performance
TypeNAS
Number of users2048 user(s)
Noise level19.8 dB
Access Control List (ACL)checkmark
On/off switchcheckmark
Built-in optical drivecross
Device classSmall & Medium Business
Backup functioncheckmark
Backup featuresiSCSI LUN
Intel insidecheckmark
Hot sparecheckmark
EAN4711174722594
Warranty3 years

DiskStation DS918+

Powerful and scalable 4-bay NAS for growing businesses

High-speed scalable storage server

Synology DS918+ is designed for small and medium-sized businesses and IT enthusiasts. With a powerful built-in AES-NI hardware encryption engine, DS918+ provides exceptional encrypted file transmission. Also capable of transcoding up to two channels of H.265/H.264 4K videos at the same time, DS918+ is ideal for sharing and storing ultra-high definition media content.

Satisfy your need for performance and capacity

DS918+ supports up to two M.2 NVMe 2280 SSDs, allowing fast system cache creation without occupying internal drive bays. Scalable up to 9 drives with a Synology Expansion Unit DX517, DS918+ answers the need for flexible storage capacity.

Btrfs: Next generation storage efficiency

Btrfs file system introduces the most advanced storage technologies to meet the management needs of modern large scale businesses:

- Flexible Shared Folder/User Quota System provides comprehensive quota control on all user accounts and shared folders
- Snapshot Replication provides schedulable and storage capacity-saving data protection with 1,024 shared folder backups and 65,000 system-wide snapshots
- File or folder level data restoration makes data recovery fast and flexible
- Automatic file self-healing detects and recovers corrupted files without user intervention


Digital asset protection

Powered by Synology DiskStation Manager (DSM), Synology NAS offers advanced security measures to protect against sudden data loss and potential security holes. Learn more

Security Advisor

Analyzes system settings, password strength, network preferences, and removes any possible malware.

AppArmor

A kernel-level enhancement that blocks malicious programs from accessing unauthorized system resources.

AES 256-bit encryption

Encrypt shared folders and network data transmission to keep data from unauthorized access.

2-step verification

Prevent others from logging in to your DSM by generating a one-time password (OTP) on your mobile device.

Trust Level

Customize the trust level in Package Center to avoid installing packages from untrusted sources, safeguarding your NAS from unknown or tampered package files.

Synchronize files across your devices

Cloud Station Suite provides real-time data synchronization across all your devices, such as computers, mobile devices, and other Synology NAS whenever a file is modified. "Intelliversioning" keeps the most important file versions to better utilize storage space.

4K Multimedia Server

Access and stream your 4K media content anytime and anywhere. DS918+ supports 4K H.264/H.265 online transcoding via Video Station and DS video, allowing 4K videos to be converted and played on the fly on other computers, smartphones, and media players that originally do not support Ultra HD formats.

Powered by Synology DSM

Surveillance Station

Complete surveillance solution for recording, monitoring, and management.

Collaboration Suite

Synology Office, Calendar and Chat guarantee a secure and high-performance private communication and user-friendly content organization.

All-in-one server

Save additional investment by integrating various network services, web/mail services, management applications into your NAS.

DSM UI

Award-winning operating system with an intuitive user interface and powerful capabilities.

Desktop Backup

Simplified backup solution for your Mac, PC, and mobile devices.

Security

Comprehensive built-in security tools are constantly updated to tackle evolving threats and protect your devices.
