No price development information for this product.
This product is end of life or currently not available.
Key Specifications
Choose one or multiple features to search for items that have the same specifications.Display | |
Pixel pitch | 0.364 x 0.364 mm |
Contrast ratio (typical) | 3000:1 |
Horizontal scan range | 31.5 - 80 kHz |
Viewing angle, horizontal | 178° |
Viewing angle, vertical | 178° |
Aspect ratio | 16:9 |
Vertical scan range | 50 - 75 Hz |
Display diagonal | 80 cm (31.5") |
Response time | 4 ms |
Display resolution | 1920 x 1080 pixels |
Supported graphics resolutions | 1920 x 1080 (HD 1080) |
Display technology | LCD/TFT |
Native aspect ratio | 16:9 |
HD type | Full HD |
Display number of colours | 16.78 million colours |
Ports & interfaces | |
DVI port | |
VGA (D-Sub) ports quantity | 1 |
S-Video inputs quantity | 1 |
PC Audio in | |
HDMI ports quantity | 1 |
PC Audio out | |
BNC input ports | 1 |
Weight & dimensions | |
Weight | 10 kg |
Height | 503.8 mm |
Width | 752.5 mm |
Depth | 189 mm |
Energy management | |
Power consumption (typical) | 65 W |
Energy efficiency class | C |
Annual energy consumption | 95 kWh |
AC input frequency | 50/60 |
AC input voltage | 100 - 240 |
Operational conditions | |
Operating relative humidity (H-H) | 10 - 85% |
Storage temperature (T-T) | -10 - 50 °C |
Operating temperature (T-T) | 0 - 40 °C |
Storage relative humidity (H-H) | 10 - 95% |
Packaging data | |
Package weight | 10.2 kg |
Package depth | 122 mm |
Package height | 560 mm |
Package width | 812 mm |
Certificates | |
Certification | CE, FCC, RoHs, WEEE |
Ergonomics | |
Cable lock slot | |
Panel mounting interface | 200 x 100 mm |
VESA mounting | |
Thin Client | |
Thin client installed | |
Packaging content | |
Cables included | AC, Audio (3.5mm), VGA |
Manual | |
Other features | |
Display | LED |
Design | |
Certification | CE, FCC, RoHs, WEEE |
Product colour | Black |
Multimedia | |
RMS rated power | 4 W |
TV tuner integrated | |
Built-in camera | |
Number of speakers | 2 |
EAN | 190695000482 |
Warranty | 1 year |
Source: Icecat.biz |
The SC-32 featuring 450 nits of brightness, 3000:1 contrast ratio and Full HD 1920 x1080 resolution, delivers clear images and colour performance. 4ms response time and quick signal-switching enable the effectiveness of surveillance control. Flexibility of VGA, HDMI, BNC and S-Video connections ensure smooth system integration. Comfortable wide viewing angle makes the SC-32 an ideal solution for security control applications.
Features
- FHD 1920 x 1080 resolution
- Anti-Burn-in™ technology
- Built-in Image Enhancer: 3D Comb Filter/Deinterlace/Noise Reduction
- Versatile connectivity (VGA, HDMI, BNC in/out, S-Video, Audio in/out)
- Looping BNC video inputs for multiple connections
- Quick signal-switching time (<=0.8 sec.)
- NTSC/PAL auto-detection
- Selectable signal source
- PC compatible
- Built-in speakers
- Auto-adjustment for optimal setting
- Security socket
- VESA standard wall mount
