No price development information for this product.
This product is end of life or currently not available.
Key Specifications
Choose one or multiple features to search for items that have the same specifications.Processor | |
Processor manufacturer | Intel |
Maximum number of SMP processors | 1 |
Compatible processor series | Intel® Celeron®, Intel® Pentium® |
Processor socket | LGA 1151 |
Memory | |
Maximum internal memory | 64 GB |
ECC | |
Non-ECC | |
Supported memory clock speeds | 2133,4000 MHz |
Supported memory types | DDR4 |
Memory channels | Dual |
Unbuffered memory | |
Memory slots type | DIMM |
Number of memory slots | 4 |
Weight & dimensions | |
Height | 305 mm |
Width | 244 mm |
Energy management | |
Power source type | ATX |
Networking | |
Ethernet LAN | |
LAN controller | Realtek RTL8111H |
Ethernet interface type | Gigabit Ethernet |
Internal I/O | |
Number of SATA connectors | 6 |
USB 2.0 connectors | 2 |
CPU fan connector | |
ATX Power connector (24-pin) | |
Chassis intrusion connector | |
Number of chassis fan connectors | 4 |
Front panel audio connector | |
TPM connector | |
EPS power connector (8-pin) | |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 2 |
Number of SATA III connectors | 6 |
Serial port headers | 1 |
Serial port via internal header | |
Parallel port via internal header | |
Supported storage drive interfaces | M.2,Serial ATA III |
Thunderbolt headers | 1 |
Front panel connector | |
Back panel I/O ports | |
PS/2 ports quantity | 1 |
USB 2.0 ports quantity | 2 |
Ethernet LAN (RJ-45) ports | 1 |
Headphone outputs | 1 |
Microphone in | |
VGA (D-Sub) ports quantity | 1 |
DVI-D ports quantity | 1 |
DisplayPorts quantity | 1 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
Storage controllers | |
RAID levels | 0,1,5,10 |
Supported storage drive types | HDD,SSD |
Packaging content | |
Cables included | SATA |
Quick installation guide | |
Drivers included | |
Expansion slots | |
PCI Express x1 (Gen 3.x) slots | 4 |
PCI Express x16 (Gen 3.x) slots | 2 |
Number of M.2 (M) slots | 1 |
BIOS | |
BIOS type | UEFI |
Graphics | |
Parallel processing technology support | CrossFire |
Graphics card family | Intel |
Discrete graphics support | |
Processor special features | |
Intel Extreme Memory Profile (XMP) | |
Intel® Optane™ Memory Ready | |
Features | |
Motherboard chipset | Intel Z370 |
Motherboard form factor | ATX |
Audio output channels | 7.1 channels |
Cooling type | Passive |
Supported processor sockets | LGA 1151 (Socket H4) |
PC health monitoring | CPU,FAN,Power supply,Temperature,Voltage |
Windows operating systems supported | |
Motherboard chipset family | Intel |
Component for | PC |
Audio chip | Realtek ALC892 |
EAN | 4719072540395 |
Warranty | 3 years |
MAKING YOUR LIFE EASIER IS OUR BUSINESS
Combining quality you can rely on with top performance and clever business solutions are key aspects of the MSI PRO SERIES motherboards. Engineered to gratify even the most demanding professional, these motherboards will fit in any PC. Making your life easier and supporting your business with super stable, reliable and long-lasting top performance.
MAKING YOUR LIFE EASIER IS OUR BUSINESS
Combining quality you can rely on with top performance and clever business solutions are key aspects of the MSI PRO SERIES motherboards. Engineered to gratify even the most demanding professional, these motherboards will fit in any PC. Making your life easier and supporting your business with super stable, reliable and long-lasting top performance.
BUILT FOR CONTENT CREATORS AND PROFESSIONALS
This motherboard is designed to fully utilize the Intel® Coffee Lake 6 core processors, ready to deliver world class performance when gaming.
GENERATE YOUR OWN MONEY
MSI PRO Series motherboards are optimized for crypto currency mining like Bitcoin, Litecoin, Ethereum and more. These motherboards come with more PCI expansion slots, perfectly placed so you can install multiple graphics cards simultaneously with ease. Optimized Power Design and special BIOS options ensure a rock solid system for long mining sessions to maximize efficiency and coin generation.
STAY COOL
Cooling your PC is essential for reliable performance. We've made sure to include enough fan headers with full control to allow you to cool your system to the max.
ENJOY THE LATEST VIDEO STANDARDS
Supporting the latest display connectors for new technologies (OLED, HDR) and legacy connectors for beamers, MSI motherboards are designed to make life easier for any professional user.
BE THE FIRST TO BOOT UP IN THE MORNING
This MSI product supports all the latest storage standards. This allows you to connect any ultra-fast storage device, giving you noticeable benefits. Start programs faster, load data faster and increase productivity.
PROFESSIONAL SOUND QUALITY
Get the most immersive sound experience. MSI Audio Boost delivers the highest sound quality through the use of premium quality audio components. This lets you enjoy breathtaking, game-changing sound to create the most dynamic soundscapes.
IMMERSE YOURSELF INTO VIRTUAL WORLDS
Integrating the very best of cutting edge technologies on MSI hardware provides a smooth VR ride. Through joint efforts with major VR brands, combined with unique MSI features geared to VR, MSI brings gamers and VR professionals a vivid and realistic experience in which content truly comes alive.
UNMATCHED MEMORY PERFORMANCE
MSI motherboards are crammed with features to fuel your system's memory with more speed, higher overclockability and increased stability.
DESIGNED FOR LIMITLESS TUNING
Founded on experience and with a long history of creating the best performing motherboards packed with smart features, you can count on this motherboard to deliver the best performance under the most extreme conditions. Countless system tuning and troubleshooting tools are at your disposal to push your system to new heights and satisfy even the most demanding tweaker.
MAXIMIZE YOUR USB DEVICE PERFORMANCE
Transfer lots of data, music and movies over USB faster than ever. MSI offers a wide variety of options to connect and boost your USB 3.1 devices, delivering lightning-fast transfer speeds!
APPS TO GREATLY IMPROVE EFFICIENCY
With years of experience in creating performance enhancing tools that are easy to use, only the highest quality applications are at your disposal. Use these tools to get the most out of your motherboard and achieve victory when gaming.
BUILT ON EVERLASTING QUALITY
Using only the finest quality components and integrating the latest technological innovations delivers the best possible professional experience. Rigorous quality testing under the most extreme conditions ensures a super reliable, long-lasting and high performance motherboard.
A USER-FRIENDLY BIOS
We made sure our BIOS contains all the latest options and is easy to use for everyone. The extensive features found in CLICK BIOS 5 let you fine-tune your system to deliver reliable maximum performance.
- Supports 8th Gen Intel® Core™ / Pentium® Celeron® processors for LGA 1151 socket
- Supports DDR4 Memory, up to 4000+(OC) MHz
- DDR4 Boost: Advanced technology provided by MSI OC lab to ensure maximum compatibility for overclocking performance
- AUDIO BOOST :Reward your ears with studio grade sound quality for the most immersive audio experience
- MULTI-GPU: With Steel Armor PCI-E slots. Supports AMD 2-Way Crossfire™
- Heavy plated heatsinks:Leading heatsink design, for maximum cooling
- EZ Debug LED: Easiest way to troubleshoot
- Turbo M.2: Delivering Speeds Up to 32Gb/s, Intel Optane Memory Ready
- PCI-E Steel Armor:Protecting VGA cards against bending and EMI
- X-Boost: Great tool to boost your USB & Storage performance
- Double ESD Protection: Double layer grounding motherboard mounting holes
- Military Class 5, Guard-Pro: Latest evolution in high quality components for best protection and efficiency
- Click BIOS 5: Award-winning BIOS with high resolution scalable font, favorites and search function
- VR Ready: Best virtual reality game experience without latency, reduces motion sickness
