Fractal Design Define R6 - midi case, window, black
Manufacturer: FRACTAL DESIGN
ID: FD-CA-DEF-R6-BK-TG
Product unavailable
This product is end of life or currently not available.
This product is end of life or currently not available.
Key Specifications
Choose one or multiple features to search for items that have the same specifications.
Specifications
Description
Store availability
Delivery
Price development
| Ports & interfaces | |
| Audio input | Yes |
| Audio output | Yes |
| USB 2.0 ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| Weight & dimensions | |
| Weight | 12.4 kg |
| Height | 465 mm |
| Width | 233 mm |
| Depth | 543 mm |
| Storage | |
| Supported HDD sizes | 2.5,3.5" |
| HDD/SSD combo cage |  |
| Packaging data | |
| Package weight | 14.4 kg |
| Package depth | 560 mm |
| Package height | 650 mm |
| Package width | 347 mm |
| Accessories included | Accessory box |
| Packaging content | |
| Manual | |
| Cooling | |
| Cooling | |
| Front fans installed | 2x 140 mm |
| Number of front fans supported (max) | 3 |
| Front fans diameters supported | 120,140 mm |
| Rear fans diameters supported | 120,140 mm |
| Top fans diameters supported | 120,140 mm |
| Bottom fans diameters supported | 120,140 mm |
| Number of rear fans supported (max) | 1 |
| Number of top fans supported (max) | 3 |
| Rear fans installed | 1x 140 mm |
| Liquid cooling capability | |
| Rear radiator sizes supported | 120 mm |
| Front radiator sizes supported | 120,140,240,280,360 mm |
| Top radiator sizes supported | 120,140,240,280,360,420 mm |
| Design | |
| Type | PC |
| Form factor | Midi Tower |
| Material | Aluminium, Tempered glass |
| LED indicators | |
| Product colour | Black |
| Cable management | |
| Reset button | |
| Supported motherboard form factors | ATX, EATX, ITX, micro ATX |
| Anti-dust filter | |
| Number of 5.25" bays | 1 |
| Number of 3.5" bays | 6 |
| Suitable for | Gaming |
| Side window | |
| Maximum CPU cooler height | 18.5 cm |
| Maximum graphics card length | 44 cm |
| Number of expansion slots | 9 |
| Maximum PSU length | 30 cm |
| Number of 2.5" bays | 8 |
| Power supply | |
| Power supply location | Bottom |
| Power supply included |  |
| Supported power supply form factors | ATX |
| EAN | 7350041085904 |
| Warranty | 1 year |
| Source: Icecat.biz | |
Designed from the ground up, the Define R6 goes beyond iteration with a profound stride of innovation – the latest and largest step in the legacy of the world-renowned Define Series.
Seamless tempered glass and sound dampened steel panels encase a fully redesigned interior with more storage capability than ever before, and with nine fan mounts, PWM fan hub, and 420mm radiator support, the R6 is the perfect platform for building your dream water loop. Improved third generation ModuVent™ technology allows an effortless transition from metal-clad sound dampened top panel to filtered high airflow multi-fan ventilation.
Expanding on the timeless elegant form and silent modular function that brought so much success to its predecessors, the new Define R6 offers the most demanding hardware enthusiast a solid foundation and flexible framework with limitless potential.
Seamless tempered glass and sound dampened steel panels encase a fully redesigned interior with more storage capability than ever before, and with nine fan mounts, PWM fan hub, and 420mm radiator support, the R6 is the perfect platform for building your dream water loop. Improved third generation ModuVent™ technology allows an effortless transition from metal-clad sound dampened top panel to filtered high airflow multi-fan ventilation.
Expanding on the timeless elegant form and silent modular function that brought so much success to its predecessors, the new Define R6 offers the most demanding hardware enthusiast a solid foundation and flexible framework with limitless potential.
