Noctua NF-F12 industrialPPC-2000 PWM 120 mm Case Fan - Black
This product is end of life or currently not available.
Key Specifications
Choose one or multiple features to search for items that have the same specifications.| Technical details | |
| Bearing technology | SSO2 |
| Weight & dimensions | |
| Weight | 175 g |
| Cable length | 0.4 m |
| Height | 25 mm |
| Width | 120 mm |
| Depth | 120 mm |
| Fan thickness | 2.5 cm |
| Fan dimensions (W x D x H) | 120 x 120 x 25 mm |
| Energy management | |
| Power consumption (typical) | 1.2 W |
| Rated current | 0.1 A |
| Voltage | 12 V |
| Packaging content | |
| Mounting kit | ![]() |
| Screws included | ![]() |
| Other features | |
| Power requirements | 12 V |
| Design | |
| Material | Fiberglass, Polyamide |
| Product colour | Black, Brown |
| Number of fans | 1 fan(s) |
| Illumination LED | ![]() |
| Performance | |
| Type | Fan |
| Mean time between failures (MTBF) | 150000 h |
| Compatible processor series | Not supported |
| Speed detection | ![]() |
| Airflow | 121.8 m³/h |
| Fan diameter | 12 cm |
| Supported processor sockets | Not supported |
| Suitable location | Computer case |
| Maximum air pressure | 3.94 mmH2O |
| Noise level (high speed) | 29.7 dB |
| Rotational speed (max) | 2000 RPM |
| Rotational speed (min) | 450 RPM |
| Pulse-width modulation (PWM) support | ![]() |
| Features | |
| Product type | Case fan |
| EAN | 4716123315391 |
| Warranty | 1 year |
The Noctua NF-F12 industrialPPC-2000 PWM is a 120mm fan engineered for high-demand computing environments and industrial applications. Its frame is constructed from fibreglass-reinforced polyamide, which enhances structural integrity and thermal stability. This model also carries an IP52 rating, providing certified protection against dust and limited water ingress. The fan incorporates Noctua's SSO2 bearing, a self-stabilising oil-pressure design intended to offer consistent performance and a long operational lifespan under continuous use.
Performance is managed via a 4-pin PWM connector, which allows for precise speed control across a wide rotational range of 550 to 2000 RPM. The fan is designed to deliver high static pressure, measured at 3.94 mmH₂O, making it effective for applications that require pushing air through restrictive components like radiators and dense heatsinks. It also moves up to 71.69 CFM of airflow for general case ventilation. This balance of controlled speed and focused airflow makes it a functional choice for both system-wide cooling and component-specific tasks in performance-oriented builds.
Key Features:- Produces a maximum noise level of 29.7 dB
- Designed with a solid black color profile
- Equipped with a 0.4-meter fan cable
- Requires a standard 12 V power source
- Includes standard fan mounting screws
- Has a unit weight of 175 grams
