Aruba AP-577EX (RW) Otdr 11ax Hazloc AP
Ports & interfaces | |
USB connector type | USB Type-C |
USB 2.0 ports quantity | 1 |
Ethernet LAN (RJ-45) ports | 2 |
Weight & dimensions | |
Weight | 2.1 kg |
Height | 140 mm |
Width | 230 mm |
Depth | 220 mm |
Energy management | |
Power over Ethernet (PoE) | ![]() |
Power consumption (max) | 32 W |
Operational conditions | |
Operating altitude | 0 - 3000 m |
Operating relative humidity (H-H) | 5 - 93% |
Storage temperature (T-T) | -40 - 70 °C |
Operating temperature (T-T) | -40 - 65 °C |
Security | |
Security algorithms | WPA2, WPA3 |
Antenna | |
Antenna type | Internal |
Antenna gain level (max) | 6.8 dBi |
Antenna features | Integrated antenna |
Antenna direction type | Directional |
Design | |
Product colour | White |
International Protection (IP) code | IP66, IP67 |
Placement | Ceiling, Pole, Wall |
Features | |
Maximum data transfer rate | 4800 Mbit/s |
Bluetooth version | 5.0 |
Spread spectrum method | DSSS, OFDM, OFDMA |
Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bt |
Bluetooth | ![]() |
Trusted Platform Module (TPM) | ![]() |
Ethernet LAN data rates | 1000,2500 Mbit/s |
Auto MDI/MDI-X | ![]() |
2.4 GHz | ![]() |
5 GHz | ![]() |
MIMO | ![]() |
Maximal-Ratio Combining (MRC) | ![]() |
Cyclic Delay Diversity (CDD) | ![]() |
Cyclic Shift Diversity (CSD) | ![]() |
6 GHz | ![]() |
EAN | 190017447285 |
Warranty | 5 years |
Source: Icecat.biz |
In outdoor and environmentally challenging locations such as oil rigs, mining facilities, and industrial plants, networks need to be protected from extreme temperatures, flammable gases or vapors, and dust concentrations. With Class 1 Division 2 and ATEX Zone 2 certifications, the 570EX Series Access Points deliver reliable Wi-Fi 6 performance to the most extreme environments.
The 570EX delivers 4x4:4SS MU-MIMO capability, Aruba ClientMatch and integrated Bluetooth to enable Aruba location services. Purpose-built to survive in the harshest industrial outdoor environments, 570EX Series APs withstand exposure to extreme high and low temperatures, persistent moisture and precipitation, and are fully sealed to keep out airborne contaminants. All electrical interfaces include industrial strength surge protection.
Aruba Wi-Fi 6 access points provide high-performance connectivity in dense mobile and IoT environments. With maximum aggregate on air data rates of 3 Gbps (HE80/HE40), the 570EX Series APs deliver the speed and reliability needed for demanding environments.
