Key Specifications
Choose one or multiple features to search for items that have the same specifications.
Specifications
Description
Store availability
Delivery
Price development
| Technical details | |
| Product type | Processor |
| Processor cache | 6144 KB |
| Status | Discontinued |
| Launch date | Q1'11 |
| Bus type units | GT/s |
| Bus bandwidth | 5 |
| Maximum memory | 32 GB |
| Processor brand name | Intel Core i5 Intel Core i5 Processor |
| Last change | 63903513 |
| Product family | 2nd Generation Intel Core i5 Processors |
| Processor | |
| Processor model | i5-2300 |
| Processor lithography | 32 nm |
| Processor family | Intel Core i5 |
| Box |  |
| Processor socket | LGA 1155 |
| Stepping | D2 |
| Processor cores | 4 |
| Processor code | SR00D |
| CPU multiplier (bus/core ratio) | 28 |
| Processor threads | 4 |
| Processor operating modes | 64-bit |
| Processor boost frequency | 3.10 GHz |
| Processor cache | 6 MB |
| Bus type | DMI |
| Processor frequency | 2.8 GHz |
| Processor codename | Sandy Bridge |
| Processor cache type | L3 |
| Processor series | Intel Core i5-2300 Desktop series |
| Memory bandwidth supported by processor (max) | 21 GB/s |
| Processor ARK ID | 52206 |
| Memory | |
| ECC | |
| Maximum internal memory supported by processor | 32 GB |
| Weight & dimensions | |
| Processor package size | 37.5 x 37.5 mm |
| Energy management | |
| Thermal Design Power (TDP) | 95 W |
| Operational conditions | |
| Maximum operating temperature | 72.6 °C |
| Tcase | 72.6 °C |
| Other features | |
| Maximum internal memory | 32768 MB |
| Graphics | |
| On-board graphics card model | Intel® HD Graphics 2000 |
| On-board graphics card |  |
| On-board graphics card base frequency | 850 MHz |
| On-board graphics card dynamic frequency (max) | 1100 MHz |
| On-board graphics card ID | 0x102 |
| Number of displays supported (on-board graphics) | 2 |
| Processor special features | |
| Intel® Identity Protection Technology (Intel® IPT) | |
| Intel® vPro™ Technology | |
| Intel® Hyper Threading Technology (Intel® HT Technology) | |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® Quick Sync Video Technology | |
| Intel® InTru™ 3D Technology | |
| Intel® Wireless Display (Intel® WiDi) | |
| Intel FDI Technology | |
| Intel® Clear Video HD Technology (Intel® CVT HD) | |
| Intel Dual Display Capable Technology | |
| Intel® Insider™ | |
| Intel Fast Memory Access | |
| Intel Flex Memory Access | |
| Intel® AES New Instructions (Intel® AES-NI) | |
| Enhanced Intel SpeedStep Technology | |
| Intel Trusted Execution Technology | |
| Intel Enhanced Halt State | |
| Intel VT-x with Extended Page Tables (EPT) | |
| Intel 64 | |
| Intel Virtualization Technology for Directed I/O (VT-d) | |
| Intel Identity Protection Technology version | 1.00 |
| Intel Virtualization Technology (VT-x) | |
| Conflict-Free processor | |
| Features | |
| Supported instruction sets | AVX |
| PCI Express slots version | 2.0 |
| Execute Disable Bit | |
| Idle States | |
| Thermal Monitoring Technologies | |
| CPU configuration (max) | 1 |
| Embedded options available | |
| Maximum number of PCI Express lanes | 16 |
| Market segment | DT |
| EAN | 0675901058445 |
Intel® 64
Intel® 64 architecture delivers 64-bit computing on server, workstation, desktop and mobile platforms when combined with supporting software. Intel 64 architecture improves performance by allowing systems to address more than 4 GB of both virtual and physical memory.
Enhanced Intel SpeedStep® Technology
Enhanced Intel SpeedStep® Technology is an advanced means of enabling high performance while meeting the power-conservation needs of mobile systems. Conventional Intel SpeedStep® Technology switches both voltage and frequency in tandem between high and low levels in response to processor load. Enhanced Intel SpeedStep® Technology builds upon that architecture using design strategies such as Separation between Voltage and Frequency Changes, and Clock Partitioning and Recovery.
Execute Disable Bit
Execute Disable Bit is a hardware-based security feature that can reduce exposure to viruses and malicious-code attacks and prevent harmful software from executing and propagating on the server or network.
