Key Specifications
Choose one or multiple features to search for items that have the same specifications.
Specifications
Description
Store availability
Delivery
Price development
| Ports & interfaces | |
| Motherboard power connector | 20+4 pin ATX |
| Floppy drive power connector | 1 |
| Number of SATA power connectors | 8 |
| Peripheral (Molex) power connectors (4-pin) | 3 |
| EPS power connector (8-pin) |  |
| ATX power connector (20+4 pin) | |
| PCI Express power connectors (6+2 pin) | 2 |
| Cabling type | Non-Modular |
| Weight & dimensions | |
| Weight | 1.8 kg |
| Height | 86 mm |
| Width | 150 mm |
| Depth | 170 mm |
| Energy management | |
| Input current | 8 |
| Nominal power | 550 W |
| Efficiency | 92% |
| Power protection features | Over current, Over voltage, Short circuit |
| Voltage tolerance | 10% |
| Combined power (+3.3V) | 100 W |
| Combined power (+12V) | 540 W |
| Combined power (+5V) | 100 W |
| Combined power (-12V) | 3.6 W |
| Combined power (+5Vsb) | 12.5 W |
| AC input frequency | 50 - 60 |
| AC input voltage | 100 - 240 |
| Total power | 550 W |
| Maximum input current (@110V) | +12V,+3.3V,+5V,+5Vsb,-12V |
| Packaging data | |
| Package type | Box |
| Certificates | |
| Certification | cTUVus, CB, CE, FCC, TÜV, CCC, RCM, BSMI, Gost-R, KCC |
| RoHS compliance | |
| 80 PLUS certification | 80 PLUS Gold |
| Cooling | |
| Number of fans | 1 fan(s) |
| Cooling type | Active |
| Fan diameter | 13.5 cm |
| Fan location | Side |
| Design | |
| Product colour | Black |
| Illumination | |
| Performance | |
| Purpose | PC |
| On/off switch | |
| ATX version | 2.4 |
| Power supply unit (PSU) form factor | ATX |
| EAN | 761345050555 |
| Warranty | 1 year |
Antec’s EDGE series is the pinnacle of power supplies. EDGE is fully modular with a revolutionary 18+10-pin MBU socket for the needs of tomorrow. By using a PSU that is 80 PLUS® GOLD & ErP Lot 6: 2013 certified, operating up to 92% efficient, you can reduce your electricity bill by up to 20% when compared to many other power supplies. EDGE’s innovative 16-pin sockets create a new level of flexibility by doubling the modular connectivity, supporting two different 8-pins connectors and even future connectors of 10, 12, 14 or 16-pins. All cables are darkened and also flat (except MBU cable) to become Flat Stealth Wires and are thus nearly invisible in your chassis. 2 High Current Rails and a ~99% +12V output ratio maximize EDGE’s capabilities to power the latest CPU’s & GPU’s. CircuitShield™ makes EDGE safe and reliable in any environment with its 7 industrial-grade protections. Backed by a 5 year warranty and lifetime global 24/7 support, EDGE embodies everything a power supply can accomplish today.
