QNAP TS-253A-4G-NAS 2-Bay Intel Celeron N3150 QuadCore 1.6GHz | 8GB RAM | SATA 6Gb/s 4xGbE
Manufacturer: QNAP SYSTEMS
ID: TS-253A-4G
Product unavailable
This product is end of life or currently not available.
This product is end of life or currently not available.
Key Specifications
Choose one or multiple features to search for items that have the same specifications.
Specifications
Description
Store availability
Delivery
Price development
| Processor | |
| Processor model | N3150 |
| L2 cache | 2 MB |
| Processor lithography | 14 nm |
| Processor family | Intel Celeron |
| Processor socket | BGA 1170 |
| Stepping | C0 |
| Processor cores | 4 |
| Processor code | SR29F |
| System bus rate | 5 GT/s |
| Processor threads | 4 |
| PCI Express slots version | 2.0 |
| Processor operating modes | 64-bit |
| Processor boost frequency | 2.08 GHz |
| Processor cache | 2 MB |
| CPU configuration (max) | 1 |
| Tjunction | 90 °C |
| PCI Express configurations | 1x4,4x1 |
| Processor frequency | 1.6 GHz |
| Thermal Design Power (TDP) | 6 W |
| Scenario Design Power (SDP) | 4 W |
| Processor codename | Braswell |
| Processor cache type | Smart Cache |
| Processor series | Intel Celeron N3000 series |
| Maximum internal memory supported by processor | 8 GB |
| ECC supported by processor |  |
| Processor package size | 25 |
| Conflict-Free processor |  |
| Integrated 4G WiMAX | |
| Processor ARK ID | 87258 |
| Memory | |
| Flash memory | 512 MB |
| Memory slots | 2 |
| Memory clock speed | 1600 MHz |
| RAM capacity | 4 GB |
| Maximum RAM supported | 8 GB |
| RAM type | DDR3L |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 2 |
| HDMI ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| Weight & dimensions | |
| Weight | 1.74 kg |
| Package weight | 2.92 kg |
| Height | 150 mm |
| Width | 102 mm |
| Depth | 216 mm |
| Energy management | |
| Power consumption (typical) | 14.43 W |
| Number of power supply units | 1 |
| Power consumption (off) | 1.18 W |
| Power consumption (sleep) | 8.38 W |
| AC input voltage | 110-240 V |
| Power supply location | External |
| Fan voltage | 12 V |
| Power supply unit (PSU) capacity | 65 W |
| Operational conditions | |
| Operating relative humidity (H-H) | 5 - 95% |
| Operating temperature (T-T) | 0 - 40 °C |
| Networking | |
| Supported network protocols | CIFS/SMB, AFP (v3.3), NFS(v3), FTP, FTPS, SFTP, TFTP, HTTP(S), Telnet, SSH, iSCSI, SNMP, SMTP, SMSC |
| Ethernet LAN | |
| Wake-on-LAN ready | |
| Wi-Fi | |
| Link aggregation | |
| Jumbo frames support | |
| DHCP client | |
| DHCP server | |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| iSCSI support | |
| Storage | |
| RAID levels | 0, 1, JBOD |
| Supported file systems | FAT32,HFS+,NTFS,ext3,ext4 |
| RAID support | |
| Storage drive size | 2.5/3.5" |
| Storage drive interface | Serial ATA III |
| Number of storage drives supported | 2 |
| Storage drives installed | |
| Installed storage drive type | |
| Supported storage drive types | HDD, SSD |
| Hot-swap drive bays | |
| Certificates | |
| Digital Living Network Alliance (DLNA) certified | |
| Packaging content | |
| Cables included | AC, LAN (RJ-45) |
| External power adapter | |
| Quick installation guide | |
| Number of screws | 14 |
| Other features | |
| Power management | |
| Design | |
| Chassis type | Tower |
| Cable lock slot | |
| LED indicators | HDD, Status, USB |
| Product colour | Black |
| Number of fans | 1 fan(s) |
| Cooling type | Active |
| Fan diameter | 7 cm |
| Cable lock slot type | Kensington |
| Graphics | |
| On-board graphics card model | |
| On-board graphics card base frequency | 320 MHz |
| On-board graphics card burst frequency | 640 MHz |
| Maximum on-board graphics card memory | 8 GB |
| Number of displays supported (on-board graphics) | 3 |
| Processor special features | |
| Intel® Identity Protection Technology (Intel® IPT) | |
| Intel® Anti-Theft Technology (Intel® AT) | |
| Intel® Smart Response Technology | |
| Intel Smart Connect Technology | |
| Intel® vPro™ Technology | |
| Intel® Hyper Threading Technology (Intel® HT Technology) | |
| Intel® Turbo Boost Technology | |
| Intel® Quick Sync Video Technology | |
| Intel® InTru™ 3D Technology | |
| Intel® Wireless Display (Intel® WiDi) | |
| Intel® Clear Video HD Technology (Intel® CVT HD) | |
| Intel® Insider™ | |
| Intel® AES New Instructions (Intel® AES-NI) | |
| Enhanced Intel SpeedStep Technology | |
| Execute Disable Bit | |
| Idle States | |
| Thermal Monitoring Technologies | |
| Intel Trusted Execution Technology | |
| Intel Enhanced Halt State | |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | |
| Intel VT-x with Extended Page Tables (EPT) | |
| Embedded options available | |
| Intel Rapid Storage Technology | |
| Intel® High Definition Audio (Intel® HD Audio) | |
| Intel® Small Business Advantage (Intel® SBA) | |
| Intel® Secure Key | |
| Intel 64 | |
| Intel Stable Image Platform Program (SIPP) | |
| Intel® OS Guard | |
| UART | |
| Intel Virtualization Technology for Directed I/O (VT-d) | |
| Number of execution units | 12 |
| Maximum number of PCI Express lanes | 4 |
| Intel Secure Boot | |
| Intel Clear Video Technology | |
| Intel Identity Protection Technology version | 1.00 |
| Intel Secure Key Technology version | 1.00 |
| Intel Secure Boot Technology version | 1.00 |
| Intel Small Business Advantage (SBA) version | 0.00 |
| Intel Smart Response Technology version | 0.00 |
| Intel Virtualization Technology (VT-x) | |
| Intel Stable Image Platform Program (SIPP) version | 0.00 |
| Intel Smart Connect Technology version | 0.00 |
| Memory types supported by processor | DDR3L-SDRAM |
| Memory channels supported by processor | Dual |
| Home Networking (by Intel) | |
| Performance | |
| Type | NAS |
| Security algorithms | 256-bit AES,FIPS 140-2,HTTPS,SSH |
| Browser supported | Microsoft Internet Explorer 10+, Mozilla Firefox 8+, Apple Safari 4+, Google Chrome |
| Noise level | 18.3 dB |
| Buzzer | |
| Operating system installed | QNAP Turbo System |
| Web-based management | |
| Access Control List (ACL) | |
| Reset button | |
| Multilingual support | |
| On/off switch | |
| S.M.A.R.T. support | |
| Operating system version | 4.2 |
| Windows operating systems supported | Windows 7 Enterprise,Windows 7 Enterprise x64,Windows 8 Enterprise,Windows 8 Enterprise x64 |
| Mac operating systems supported | |
| Linux operating systems supported | |
| Server operating systems supported | Windows Server 2003,Windows Server 2003 R2,Windows Server 2008,Windows Server 2008 R2,Windows Server 2012,Windows Server 2012 R2 |
| Device class | Home & Home Office |
| Backup function | |
| Backup features | Cloud, iSCSI LUN |
| Built-in UPnP AV media server | |
| Built-in iTunes server | |
| Built-in FTP server | |
| System log | |
| Hot spare | |
| Password authentication | |
| Share folder | CIFS/SMB |
| Share folder access right management | |
| EAN | 0885022009879 |
| Warranty | 2 years |
In response to the coming era of Internet of Things (IoT), the TS-253A innovatively supports the open-source Linux® platform as a gateway for IoT solutions to other smart devices. The TS-253A allows users to directly utilize various feature-rich Liunx apps, enjoying a private cloud combining storage and IoT applications, and professional developers can develop and run IoT applications directly on the TS-253A. The secure, reliable TS-253A is packed with business-critical features such as Volume/LUN Snapshot – allowing files/folders to revert to a previous state in case of any corruption or file-loss. The TS-253A is powered by the latest quad-core Intel® Celeron® processor which allows users to enjoy 4K (H.264) video playback and 1080p/4K video real-time transcoding directly from the TS-253A to an HD/4K display.
- Supports the Linux® OS with direct output via HDMI.
- Dual HDMI output for switching between duplicated and extended desktop options.
- AES-NI hardware-accelerated encryption for efficient cryptographic performance up to 224 MB/s.
- Supports 4K hardware decoding and transcodes 4K H.264 videos on-the-fly or offline.
- Quickly find files using a real-time, natural search with Qsirch 2.1.
- NAS and iSCSI-SAN unified storage solution for virtualization.
- Supports VMware®, Citrix®, Microsoft® Hyper-V and advanced virtualization features.
- A hybrid approach to virtualization in one NAS: Virtualization Station & Container Station.
- Build a personal karaoke system with high-quality audio output with the new OceanKTV app.
- Supports the Linux® OS with direct output via HDMI.
- Dual HDMI output for switching between duplicated and extended desktop options.
- AES-NI hardware-accelerated encryption for efficient cryptographic performance up to 224 MB/s.
- Supports 4K hardware decoding and transcodes 4K H.264 videos on-the-fly or offline.
- Quickly find files using a real-time, natural search with Qsirch 2.1.
- NAS and iSCSI-SAN unified storage solution for virtualization.
- Supports VMware®, Citrix®, Microsoft® Hyper-V and advanced virtualization features.
- A hybrid approach to virtualization in one NAS: Virtualization Station & Container Station.
- Build a personal karaoke system with high-quality audio output with the new OceanKTV app.
