| Ports & interfaces | |
| Fiber ports quantity | 8 |
| External mini-SAS ports | 4 |
| USB port |  |
| Weight & dimensions | |
| Height | 131 mm |
| Width | 447 mm |
| Depth | 507 mm |
| Energy management | |
| Number of power supply units | 2 |
| Redundant power supply (RPS) support |  |
| AC input frequency | 50 - 60 Hz |
| AC input voltage | 100-240 V |
| Power supply unit (PSU) capacity | 580 W |
| Operational conditions | |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage temperature (T-T) | -40 - 60 °C |
| Operating temperature (T-T) | 5 - 40 °C |
| Storage relative humidity (H-H) | 5 - 95% |
| Operating shock | 5 G |
| Non-operating shock | 10 G |
| Non-operating vibration | 1 G |
| Operating vibration | 0.3 G |
| Networking | |
| Ethernet LAN | |
| Wi-Fi | |
| Storage | |
| HDD speed | 7200 RPM |
| RAID levels | 0,1,5,6,10,50,60,JBOD |
| RAID support | |
| Storage drive size | 2.5/3.5" |
| Storage drive interface | Serial Attached SCSI (SAS) |
| Number of storage drives supported | 16 |
| Storage drives installed | |
| Number of storage drives installed | 16 |
| Installed storage drive type | HDD |
| Supported storage drive types | HDD & SSD |
| Hot-swap drive bays | |
| Storage drive capacity | 4000 GB |
| Certificates | |
| Certification | 80Plus, CE, FCC Class A, UL/cUL, TUV, BSMI Class A, VCCI Class A, CB, KCC, NOM, GOST-R, IRAM, C-Tick, S-Mark |
| Other features | |
| Compatible operating systems | OS X/OS X Server (10.8), Microsoft Windows Server 2008 w/SP2, Microsoft Windows Server 2008 R2, Windows Server 2012, RedHat Enterprise Linux 6.2, RedHat Enterprise Linux 6.3, SuSE Linux Enterprise Server 11.2, VMware ESX Server 5.4, Vmware |
| Design | |
| Chassis type | Rack (3U) |
| LED indicators | |
| Product colour | Grey |
| Cooling type | Active |
| Built-in display | |
| Performance | |
| Type | Storage server |
| Backup function | |
| Backup features | Cloud, iSCSI LUN |
| EAN | 704118101351 |
| Warranty | 1 year |
| Source: Icecat.biz | |
- 3U/16 form factor featuring hot-swappable drive bays in SBB 2.0 package
- Supports 6G and 3G SAS and SATA drives simultaneously
- Dual active/active SAS JBOD I/O modules
- Provides up to 90% power efficiency
- Multi-ported, multi-lane 6G mini SAS (4x) ports provide large bandwidth capabilities
- Redundant, hot-swappable Field Replaceable Units (FRUs)
- SES-2 compliant enclosure management
- Compatible with leading SAS/SATA drives, HBAs and RAID controllers
- Supports 6G and 3G SAS and SATA drives simultaneously
- Dual active/active SAS JBOD I/O modules
- Provides up to 90% power efficiency
- Multi-ported, multi-lane 6G mini SAS (4x) ports provide large bandwidth capabilities
- Redundant, hot-swappable Field Replaceable Units (FRUs)
- SES-2 compliant enclosure management
- Compatible with leading SAS/SATA drives, HBAs and RAID controllers
