Sony VPL-FW60 - LCD-projektori - 5200 lumenia - WXGA (1280 x 800) - 16:10 - HD 720p - standardit objektiivit - LAN

Manufacturer: SONY
ID: VPL-FW60
Product unavailable
This product is end of life or currently not available.

Key Specifications

Choose one or multiple features to search for items that have the same specifications.
Specifications
Description
Store availability
Delivery
Price development
Display
Built-in displaycross
Ports & interfaces
Serial interface typeRS-232C
DVI portcheckmark
VGA (D-Sub) ports quantity2
PC Audio incheckmark
AC (power) incheckmark
HDMI ports quantity1
PC Audio outcheckmark
BNC input ports1
Remote (IR) output1
HDMI connector typeFull-size
HDBaseT portcheckmark
Lens system
Zoom capabilitycheckmark
FocusAuto
Throw ratio1.39 - 2.23:1
Zoom ratio1.6:1
Zoom typeAuto/Manual
Horizontal lens shift range-32 - 32%
Vertical lens shift range-5 - 60%
Weight & dimensions
Weight13 kg
Height169 mm
Width460 mm
Depth515 mm
Energy management
Power consumption (typical)404 W
Power sourceAC
Power consumption (standby)0.5 W
AC input frequency50 - 60 Hz
AC input voltage100-240 V
Power consumption (max)416 W
Power consumption (network standby)15 W
Operational conditions
Operating relative humidity (H-H)20 - 80%
Storage temperature (T-T)-10 - 60 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)20 - 80%
Networking
Ethernet LANcheckmark
Ethernet LAN (RJ-45) ports1
Wi-Ficross
Ethernet LAN data rates10,100 Mbit/s
Projector
Contrast ratio (typical)2000:1
Horizontal scan range15 - 92 kHz
Vertical scan range48 - 92 Hz
Projection technology3LCD
Projector brightness5200 ANSI lumens
Heat dissipation1419 BTU/h
Screen size compatibility1016 - 15240 mm (40 - 600")
Keystone correction, vertical-30 - 30°
Keystone correction, horizontal-30 - 30°
Projector brightness (economic mode)3400 ANSI lumens
Matrix size1.93 cm (0.76")
Matrix type3-panel (p-Si TFT active)
Native aspect ratio16:10
Projector native resolutionWXGA (1280x800)
Video
Analog signal format systemNTSC, NTSC 3.58,NTSC 4.43,PAL, PAL 60,PAL M, PAL N, SECAM
Supported graphics resolutions1920 x 1200 (WUXGA)
Supported video modes480i,480p,576i,576p,720p,1080i,1080p
3Dcross
Storage
Card reader integratedcross
Packaging content
Remote control includedcheckmark
Cables includedAC
Manualcheckmark
Quick start guidecheckmark
Batteries includedcheckmark
Other features
RS-232 ports1
RS-232Ccheckmark
Design
Product colourBlack, White
Product typeDesktop projector
Features
Noise level28 dB
On Screen Display (OSD)checkmark
On Screen Display (OSD) languagesArabic, Simplified Chinese, Traditional Chinese, German, Dutch, English, Spanish, Farsi, Finnish, French, Greek, Hungarian, Indonesian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese, Russian, Swedish, Thai, Turkish, Vietnamese
HDCPcheckmark
Multimedia
Built-in speaker(s)cross
Light source
Lamp typeUHP
Lamps quantity1 lamp(s)
EAN4905524996173
Warranty1 year
Source: Icecat.biz
Bring presentations to life with impressive brightness, flexible integration and powerful picture features.
The VPL-FW60 installation projector is ideal for a wide range of business, education and entertainment applications. The energy-efficient High Pressure Mercury (HPM) lamp source is teamed with Sony's advanced BrightEra 3LCD projection engine to deliver extremely bright, crisp WXGA resolution images with powerful 5200 lumens maximum light output and rich, stable colours. Reality Creation and Contrast Enhancer technologies fine-tune image quality even further to assure exceptional clarity and realism with every presentation.

Offering a stylish blend-in design, tidy cable management and low fan noise, the VPL-FW60 fits smoothly into almost any environment – from academic institutions, corporate, medical training and public sector organisations to visitor attractions and retail spaces. Seamlessly blend images from multiple projectors to create super-sized displays, or project accurately proportioned images onto angled or curved surfaces. Mount the projector at any angle, even on its side or upside down. Set-up is easy with a friendly installation menu.

Very high image quality with BrightEra 3LCD projection engine
The energy-efficient High Pressure Mercury (HPM) lamp source is coupled with Sony's acclaimed BrightEra 3LCD projection engine to ensure high 5200 lumen image brightness with vivid, natural colour reproduction.

Advanced picture refinement technologies
Picture quality is boosted by advanced processing featured on Sony home cinema projectors. Reality Creation uses a powerful pattern-matching database to optimise every pixel. Contrast Enhancer actively analyses and refines dark and light image areas for sparkling highlights and rich, deep blacks.

Crisp WXGA image quality
View PC presentations or videos with WXGA (1280 x 800) 16:10 resolution.

Hassle-free automatic filter cleaning
Focus on great-looking images instead of arduous maintenance tasks: automated filter cleaning system removes dust every 100 hours.

Powered Wide Lens Shift
Generous lens shift adjustments give more flexibility for positioning the projector where you need it: close to ceilings or even horizontally offset.

Included powered standard zoom lens plus wide choice of lens options
Installation flexibility is increased by a wide range of compatible lens options to suit virtually any size of room and throw requirements. Quick-release bayonet mount simplifies quick lens exchange.

Supports HDBaseT
Simpler, more cost-effective installation and connectivity with digital transmission of HD video, audio and networking/control over a single Ethernet cable.

Create super-size displays with Edge Blending
Seamlessly join accurately colour-matched images from multiple projectors, simplifying creation of stunning super-size displays for corporate and education.

Project onto non-flat surfaces with Image Warping
Easily correct image geometry for natural-looking projections – even on convex or concave surfaces. Corner and edge correction can be easily adjusted with the supplied remote and on-screen menu.

Quiet operation
Low fan noise ensures discreet, unobtrusive operation in quiet environments from museums and galleries to lecture theatres.

Slim, attractive blend-in design
The slim, stylish case design features a flat top surface that blends in discreetly when the projector is ceiling mounted. The clean appearance is accentuated by a terminal cover that reduces cable clutter.

Picture Mode
Picture Mode ensures great-looking presentations in a wide range of operating conditions. Select Standard, Dynamic, Brightness Priority or Multi Screen mode for optimised image quality, with any source and in every room.

Simple set-up with friendly Installation menu
Easily adjust projector settings with remote commander, including image warping and edge blending.

Project Side by Side
Project images from two inputs at the same time: ideal for applications such as video conferencing and medical training where two images need to be seen simultaneously.
