Key Specifications
Choose one or multiple features to search for items that have the same specifications.Processor | |
Compatible processor series | Ryzen,AMD A,Athlon |
Processor family | AMD |
Processor socket | AM4 |
Memory | |
Maximum internal memory | 64 GB |
Non-ECC | |
Supported memory clock speeds | 2133,2400,2666,2933,3200 MHz |
Supported memory types | DDR4 |
Memory channels | Dual |
Unbuffered memory | |
Memory slots type | DIMM |
Number of memory slots | 4 |
Weight & dimensions | |
Width | 244 mm |
Depth | 244 mm |
Networking | |
Ethernet LAN | |
LAN controller | Realtek RTL8111H |
Ethernet interface type | Gigabit Ethernet |
Internal I/O | |
USB 2.0 connectors | 2 |
CPU fan connector | |
Number of COM connectors | 1 |
ATX Power connector (24-pin) | |
Number of EATX power connectors | 1 |
Number of chassis fan connectors | 1 |
Front panel audio connector | |
USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
Number of SATA III connectors | 6 |
Number of M.2 (M) slots | 1 |
Back panel I/O ports | |
PS/2 ports quantity | 2 |
Ethernet LAN (RJ-45) ports | 1 |
Headphone outputs | 1 |
Microphone in | |
VGA (D-Sub) ports quantity | 1 |
DVI-D ports quantity | 1 |
HDMI ports quantity | 1 |
USB 3.0 (3.1 Gen 1) Type-A ports quantity | 4 |
USB 3.1 (3.1 Gen 2) Type-A ports quantity | 2 |
BIOS | |
BIOS memory size | 16 MB |
BIOS type | UEFI AMI |
ACPI version | 6.1 |
Clear CMOS jumper | |
Performance | |
Motherboard chipset | AMD B350 |
Audio system | Realtek ALC887 |
Motherboard form factor | Micro ATX |
Audio output channels | 7.1 channels |
Windows operating systems supported | Windows 10 Education x64,Windows 10 Enterprise x64,Windows 10 Home x64 |
Motherboard chipset family | AMD |
Component for | PC |
Features | |
Motherboard chipset | AMD B350 |
Motherboard | |
Motherboard form factor | Micro ATX |
EAN | 4712900673586 |
ASUS Prime is the next evolution of the ASUS motherboard, born of a pedigree that stretches back to 1989. Our team of world-class engineers are passionate about empowering everyone to enjoy the benefits of customization and tuning, and the driving force behind the development of Prime is to make advanced enthusiast controls easily accessible — maximizing performance, stability and compatibility for the very best DIY PC experiences. Simply stated: it's time for Prime.
Reliable Stability and Compatibility
Built to Last
ASUS is the world's foremost motherboard manufacturer, renowned for our unique Design Thinking approach. Our exhaustive testing exceeds industry standards, supported by high-quality components for exceptional real-world protection. Our motherboards are proven to be compatible with more than 1,000 components and devices, and each new model undergoes a minimum of 8,000 hours of strict validation. ASUS gives you the peace of mind of knowing that your motherboard is fit for all environments and applications. By choosing ASUS, you also gain the freedom to select outstanding component options, for trouble-free DIY experiences.
Optimized Cooling
Fan Xpert
Dedicated CPU and case fan controls
Exclusive Fan Xpert ensures every fan achieves the best balance of cooling performance and low noise - and with Prime B350 series boards and their hardware-level 4-pin/3-pin PWM/DC mode for case fans, a simple BIOS adjustment lets you run your case fan in PWM/DC. Fan Xpert even includes Auto-Tuning mode to scan and detect all fan characteristics for single-click customization!
* Specifications and features vary by model, and all images are illustrative. Please refer specification pages for full details.
Game in Your Way
Brighten Up Your Build
LED-illuminated control for trace paths
Built-in LED lighting options can illuminate your build in a variety of mesmerizing styles. With specially-designed Fan RGB header control, you can even personalize your own fan lighting scheme with the exclusive AMD RGB Fan!
All-round Energy Saving
Energy Efficient Design
EPU
With the Energy Processing Unit (EPU) you'll enjoy system power savings. EPU automatically optimizes power consumption, and maximizes savings with Away mode.
Ultrafast Transfer Speeds
10Gb/s USB 3.1 Onboard
With backward-compatible USB 3.1 Type-A, you'll experience ultimate connection flexibility and blazing data-transfer speeds of up to 10Gb/s (twice as fast as standard USB 3.0).
Speed Up with Onboard M.2 Up to 32Gb/s
With x4 PCI Express 3.0/2.0 bandwidth, M.2 supports up to 32Gb/s data-transfer speeds. It is the perfect choice for an operating system or application drive, making your whole PC or professional apps work as fast as possible.
* Specifications and features vary by model, and all images are illustrative. Please refer specification pages for full details.
Easy PC DIY
Safe Motherboard Mounting
Component-free areas to minimize damage risk
Fitting your ASUS motherboard is now safer than ever. The comprehensive component-free 'safe zones' around every case-mounting hole minimizes the risk of damage and short circuits caused by contact - so you'll assemble your PC with total confidence!
One-Stop Controls
Media-acclaimed UEFI BIOS
The smoothest, slickest mouse-controlled graphical BIOS has been improved to make it even more appealing. Whether you're a PC novice or a seasoned overclocker, EZ and Advanced modes help you find your way, quickly and easily.
