Key Specifications
Choose one or multiple features to search for items that have the same specifications.
Specifications
Description
Store availability
Delivery
Price development
| Ports & interfaces | |
| PCI Express power connectors (6-pin) | 1 |
| Motherboard power connector | 20+4 pin ATX |
| Floppy drive power connector | 1 |
| Number of SATA power connectors | 3 |
| Peripheral (Molex) power connectors (4-pin) | 2 |
| ATX power connector (20+4 pin) |  |
| CPU P4 connector (4-pin) | 1 |
| Cabling type | Non-Modular |
| Weight & dimensions | |
| Height | 86 mm |
| Width | 150 mm |
| Depth | 140 mm |
| Energy management | |
| Peak power | 450 W |
| Input current | 3 A |
| Nominal power | 400 W |
| Efficiency | 85.68% |
| Power protection features | Over current,Over power,Over voltage,Short circuit,Under voltage |
| Power Factor Correction (PFC) type | Active |
| Combined power (+3.3V) | 120 W |
| Combined power (+5V) | 120 W |
| Combined power (-12V) | 16.1 W |
| Combined power (+5Vsb) | 16.1 W |
| Max output current (+3.3V) | 24 A |
| Max output current (+5V) | 15 A |
| Max output current (-12V) | 0.3 A |
| Max output current (+5Vsb) | 2.5 A |
| AC input frequency | 47 - 63 Hz |
| AC input voltage | 180 - 264 V |
| Max output current (+12V2) | 17 A |
| Max output current (+12V1) | 17 A |
| Total power | 400 W |
| Maximum input current (@110V) | +12V1,+12V2,+3.3V,+5V,-12V,-5Vsb |
| Certificates | |
| Energy Star certified | |
| RoHS compliance | |
| Cooling | |
| Number of fans | 1 fan(s) |
| Cooling type | Active |
| Fan location | Side |
| Other features | |
| Dimensions (WxDxH) | 150 x 140 x 86 mm |
| Design | |
| Product colour | Grey |
| Performance | |
| Noise level | 30.9 dB |
| Purpose | PC |
| On/off switch | |
| ATX version | 2.4 |
| Power supply unit (PSU) form factor | ATX |
| EAN | 4711140488622 |
This ATX / PS2 power supply unit (PSU) has a real power rating of 400W (continuous). The eco-friendly design allows APN 85+ series to reach more than 85% efficiency. APN series also protects your PC by providing complete protection (OCP, OVP and SCP). APN series does the job efficiently and reliably, making it a stable power supply unit built to satisfy the demands of users looking for entry-level power or the budget-minded system builder.
The efficiency of this power supply meets the 80 PLUS® Bronze requirements at 230V input. However, as EPRI only test power supplies at 115V input; this PSU cannot be certified by 80 PLUS® (as implemented by ECOVA). This also meets the Energy Star Version 5.0 Power Supply and Power Management Requirements for Computers: Effective July 1st, 2009.
The efficiency of this power supply meets the 80 PLUS® Bronze requirements at 230V input. However, as EPRI only test power supplies at 115V input; this PSU cannot be certified by 80 PLUS® (as implemented by ECOVA). This also meets the Energy Star Version 5.0 Power Supply and Power Management Requirements for Computers: Effective July 1st, 2009.
