Intel Xeon D-1540 Broadwell, 2 GHz, 8 Cores, 16 Threads, 12 MB Cache, BGA 1667, Server/Workstation - processor, tray

Technical details
Supported memory types	DDR4
Product type	System on Chip
Processor cache	12288 KB
Status	Launched
Launch date	Q1'15
Product name	Intel Xeon D-1540 (12M Cache, 2.00 GHz)
Born on date	Q1'15
Maximum memory	128 GB
Processor brand name	Intel Xeon
Last change	63903513
Product family	Intel Xeon Processor D Family
Processor
Processor model	D-1540
Processor manufacturer	Intel
Processor lithography	14 nm
Processor family	Intel Xeon
Box
Processor socket	FCBGA1667
Stepping	V1
Processor cores	8
Processor code	SR29A
Processor threads	16
Processor operating modes	64-bit
Processor boost frequency	2.6 GHz
Component for	Server/workstation
Processor cache	12 MB
Thermal Design Power (TDP)	45 W
Processor codename	Broadwell
Processor cache type	L3
Processor series	Intel Xeon D-1500
Processor ARK ID	87039
Cooler included
Memory
ECC
Memory channels	Dual-channel
Maximum internal memory supported by processor	128 GB
Memory types supported by processor	DDR4-SDRAM
Weight & dimensions
Processor package size	37.5 x 37.5 mm
Operational conditions
Tcase	80 °C
Other features
Maximum internal memory	128 GB
Intel® Virtualization Technology (Intel® VT)	VT-d,VT-x
Cache memory	12 MB
Graphics
On-board graphics card model	Not available
On-board graphics card
Processor special features
Intel® Hyper Threading Technology (Intel® HT Technology)
Intel® Turbo Boost Technology	2.0
Intel® Smart Cache
Intel® AES New Instructions (Intel® AES-NI)
Enhanced Intel SpeedStep Technology
Intel Trusted Execution Technology
Intel Enhanced Halt State
Intel VT-x with Extended Page Tables (EPT)
Intel TSX-NI
Intel® Secure Key
Intel 64
Intel® OS Guard
Intel Virtualization Technology for Directed I/O (VT-d)
Intel Secure Key Technology version	1.00
Intel Virtualization Technology (VT-x)
Intel TSX-NI version	1.00
Conflict-Free processor
Features
Supported instruction sets	AVX 2.0
PCI Express slots version	2.0,3.0
Execute Disable Bit
Idle States
Thermal Monitoring Technologies
Scalability	1S
CPU configuration (max)	1
Embedded options available
Graphics & IMC lithography	14 nm
PCI Express configurations	1x4,1x8,1x16
Maximum number of PCI Express lanes	32
Market segment	Server
I/O configuration
USB version	2.0/3.2 Gen 1 (3.1 Gen 1)
USB ports quantity	8
UART
General Purpose IO	Yes
Integrated LAN
Total number of SATA connectors	6
EAN
Warranty	1 year

Advanced Encryption Standard New Instructions (AES-NI) are a set of instructions that enable fast and secure data encryption and decryption. AES-NI are valuable for a wide range of cryptographic applications, for example: applications that perform bulk encryption/decryption, authentication, random number generation, and authenticated encryption.

Intel® 64 architecture delivers 64-bit computing on server, workstation, desktop and mobile platforms when combined with supporting software. Intel 64 architecture improves performance by allowing systems to address more than 4 GB of both virtual and physical memory.

Enhanced Intel SpeedStep® Technology is an advanced means of enabling high performance while meeting the power-conservation needs of mobile systems. Conventional Intel SpeedStep® Technology switches both voltage and frequency in tandem between high and low levels in response to processor load. Enhanced Intel SpeedStep® Technology builds upon that architecture using design strategies such as Separation between Voltage and Frequency Changes, and Clock Partitioning and Recovery.
