Key Specifications
Choose one or multiple features to search for items that have the same specifications.Display | |
Pixel pitch | 0.55926 x 0.55926 mm |
Viewing angle, horizontal | 178° |
Viewing angle, vertical | 178° |
Display diagonal | 124.5 cm (49") |
Display brightness | 450 cd/m² |
Response time | 12 ms |
Display resolution | 1920 x 1080 pixels |
Touchscreen | |
Native aspect ratio | 16:9 |
HD type | Full HD |
Audio | |
Built-in speaker(s) | |
Ports & interfaces | |
Ethernet LAN | |
Ethernet LAN (RJ-45) ports | 1 |
DVI port | |
DVI-D ports quantity | 1 |
Audio (L/R) out | 1 |
HDMI ports quantity | 2 |
DisplayPorts quantity | 2 |
USB version | 3.2 Gen 1 (3.1 Gen 1) |
VGA (D-Sub) input ports | 1 |
USB ports quantity | 1 |
RS-232C | |
USB port | |
Weight & dimensions | |
Weight | 14.1 kg |
Height | 638.5 mm |
Width | 1102.2 mm |
Depth | 38.6 mm |
Energy management | |
Power consumption (typical) | 85 W |
Power consumption (off) | 0.5 W |
Power consumption (sleep) | 0.5 W |
AC input frequency | 50 - 60 Hz |
AC input voltage | 100 - 240 V |
Operational conditions | |
Operating relative humidity (H-H) | 10 - 80% |
Operating temperature (T-T) | 0 - 40 °C |
Packaging data | |
Package weight | 17.2 kg |
Package depth | 166 mm |
Package height | 760 mm |
Package width | 1197 mm |
Packaging content | |
Remote control included | |
Cables included | AC, VGA |
Batteries included | |
Other features | |
Manual | |
Display technology | LED |
Panel type | IPS |
Design | |
Product colour | Black |
Placement supported | Indoor |
Panel mounting interface | 300 x 300 mm |
Product design | Digital signage flat panel |
Bezel width (side) | 1.19 cm |
Bezel width (top) | 1.19 cm |
Bezel width (bottom) | 1.8 cm |
VESA mounting | |
Orientation | Horizontal/Vertical |
Performance | |
TV tuner integrated | |
Purpose | Retail |
Picture-in-Picture | |
Computer system | |
Operating system installed | Web OS |
Processor cores | 4 |
Internal memory | 8 GB |
Computer system | |
Computer system type | System on Chip (SoC) |
EAN | 8806087763553 |
Warranty | 1 year |
Source: Icecat.biz |
Quad Core SoC
The high-performance SoC can execute several tasks at the same time and provides smooth content playback without an external media player.
PBP (Picture-By-Picture) / PIP (Picture-In-Picture)
PBP (Picture-By-Picture) and PIP (Picture-In-Picture) features enable you to compose various layouts for several digital devices.
Integrated CMS (Contents Management System)
You can edit contents, check your schedule, and use group manager function etc. without a separate PC. It is one-stop system that enables you to manage the signage.
Portrait & Landscape Mode
When using the signage in Portrait Mode, GUI taliored to Portrait Mode is provided without affecting images' original ratio and resolution.
EZ Setting
As all of its unique functions are indexed in EZ setting, you can enjoy convenient access to setting for effi cient management.
IP Streaming Protocol
Various types of IP video streaming protocol are supported, such as RTSP/RTP, MMS, HLS and MPEG-2 TS.
Secure Communication Protocol
By supporting HTTPS protocol, communication between server and signage is more secure.
Proxy Server
Web access speed and security can be improved by supporting Proxy Server (A server that acts as an intermediary for requests from clients seeking resources from other servers.)
Mirroring
Content sharing is more convenient on a Wi-Fi network.
Soft AP
The SM5D with Soft AP software can operate as a wireless access point for mobile devices.
Enhanced Connectivity
Through its diverse interface, the signage lets you connect more than one device for optimal use.
BEACON
With BEACON and Bluetooth Low Energy (BLE) supported by SM5D, retail stores can provide coupons and information in real time.
Dust & Humidity Protection
Circuit board reliability is enhanced with conformal coating that protects against dust, iron powder, humidity and other harsh conditions.
Detachable logo
The detachable logo allows for installation in the desired orientation: landscape or portrait mode.
