Key Specifications
Choose one or multiple features to search for items that have the same specifications.
Specifications
Description
Store availability
Delivery
Price development
Display | |
Contrast ratio (typical) | 4000:1 |
Viewing angle, horizontal | 178° |
Viewing angle, vertical | 178° |
Display diagonal | 139.7 cm (55") |
Display brightness | 700 cd/m² |
Response time | 8 ms |
Display resolution | 1920 x 1080 pixels |
Touchscreen | ![]() |
LED backlighting type | Edge-LED BLU |
HD type | Full HD |
Audio | |
Number of built-in speakers | 2 |
RMS rated power | 20 W |
Built-in speaker(s) | ![]() |
Ports & interfaces | |
Ethernet LAN | ![]() |
Ethernet LAN (RJ-45) ports | 1 |
DVI port | ![]() |
DVI-I ports quantity | 1 |
Wi-Fi | ![]() |
Audio (L/R) in | 1 |
Audio (L/R) out | 1 |
HDMI ports quantity | 2 |
DisplayPorts quantity | 2 |
USB version | 2.0 |
USB ports quantity | 2 |
RS-232C | ![]() |
USB port | ![]() |
Weight & dimensions | |
Weight | 16.4 kg |
Height | 701 mm |
Width | 1226.8 mm |
Depth | 27.9 mm |
Energy management | |
Power consumption (typical) | 134 W |
Power consumption (standby) | 0.5 W |
AC input frequency | 50 - 60 Hz |
AC input voltage | 100 - 240 V |
Operational conditions | |
Operating relative humidity (H-H) | 10 - 80% |
Operating temperature (T-T) | 0 - 40 °C |
Packaging data | |
Package weight | 21.9 kg |
Package depth | 180.3 mm |
Package height | 810.3 mm |
Package width | 1333.5 mm |
Packaging content | |
Remote control included | ![]() |
Cables included | AC |
Batteries included | ![]() |
Other features | |
Plug and Play | ![]() |
Quick start guide | ![]() |
Display technology | LED |
DisplayPort version | 1.2 |
SMART Signage TV (SSTV) | ![]() |
Design | |
Product colour | Black |
Placement supported | Indoor |
Panel mounting interface | 400 x 400 mm |
Product design | Digital signage flat panel |
Bezel width (side) | 6.9 mm |
Bezel width (top) | 6.9 mm |
Bezel width (bottom) | 8.9 mm |
VESA mounting | ![]() |
Orientation | Horizontal/Vertical |
Performance | |
TV tuner integrated | ![]() |
Purpose | Universal |
On Screen Display (OSD) | ![]() |
HDCP | ![]() |
Operating hours (hours/days) | 24/7 |
Computer system | |
Processor model | A12 |
Processor family | ARM Cortex |
Operating system installed | Tizen 4.0 |
Processor cores | 4 |
Internal storage capacity | 8 GB |
Processor frequency | 1.3 GHz |
Internal memory | 2.5 GB |
Computer system | ![]() |
EAN | 8806088677309 |
Warranty | 1 year |
Source: Icecat.biz |
At a Glance
Samsung PHF-P Series high brightness commercial displays feature an ultra-slim and narrow design. They're built for 24/7 run-time and have an embedded System-on-Chip (SoC) media player for simple remote content management. The non-glare panel offers improved visibility, plus IP5X certified dust protection allows for smooth installation.
- Next gen Smart Signage Platform (SSP) 4.0 powered by Tizen OS for powerful, streamlined 24/7 remote content management
- IP5X certified dust protection provides proven durability for smooth installation without the need for additional housing
- Non-glare, high brightness panel offers improved visibility in bright ambient light
- Ultra-slim, ADA-Compliant profile of just 1.1" chassis depth and 6.9mm bezel width
Built for 24/7 Use & IP5X Certified for Dust Protection
PHF-P Series displays are built for dependable 24/7 continuous use with commercial-level cooling technologies and are proven durable with IP5X certified dust protection. So you can install your signage smoothly in dusty environments without the need for additional housing, while meeting around the clock operating requirements. They also feature anti-vibration technologies to protect sensitive components.
Non-Glare, High Brightness Panel for Improved Visibility
The non-glare, high brightness panel features 700nit brightness to improve visibility of your message in bright ambient light.
System-on-Chip Platform for Simple Remote Content Management
Powered by an embedded System-on-Chip (SoC) semiconductor and quad core CPU with 8GB of storage, Samsung's SMART Signage Platform is an open and integrated player side media platform that provides a powerful, streamlined digital signage solution, with digital signage software like MagicInfo T for PC-less content creation, scheduling and playing and remotely managing content.
Ultra-Slim, ADA-Compliant Profile of Just 1.1”
The PHF-P Series features an ultra-thin 6.9mm bezel and 1.1" chassis depth for an elegant, sophisticated look. And they’re ADA-compliant when installed with the appropriate mount.
Enhanced Web Compatibility
Samsung B2B SDK allows developers to build web-based apps for customer functionality and greater interactivity.
More Content Possibilities
PHF-P Series displays are designed to use content from various external sources including Samsung PIMs. Samsung PIMs use Intel® Open Pluggable Specification (OPS) connectivity to enable power and video source delivery through a single cable. No additional power cord is necessary.
Full Connectivity
Discover versatile connectivity options to display a full range of exceptional content that speaks to your audience. Connections include DVI-I, Display Port 1.2, HDMI, USB 2.0, RS232C/RJ45 and more.
Built-In Wi-Fi®
Enjoy the versatility of expanded connectivity to mobile devices, from easy media sharing and screen control to simple content mirroring from a tablet or mobile phone to your display.
Samsung PHF-P Series high brightness commercial displays feature an ultra-slim and narrow design. They're built for 24/7 run-time and have an embedded System-on-Chip (SoC) media player for simple remote content management. The non-glare panel offers improved visibility, plus IP5X certified dust protection allows for smooth installation.
- Next gen Smart Signage Platform (SSP) 4.0 powered by Tizen OS for powerful, streamlined 24/7 remote content management
- IP5X certified dust protection provides proven durability for smooth installation without the need for additional housing
- Non-glare, high brightness panel offers improved visibility in bright ambient light
- Ultra-slim, ADA-Compliant profile of just 1.1" chassis depth and 6.9mm bezel width
Built for 24/7 Use & IP5X Certified for Dust Protection
PHF-P Series displays are built for dependable 24/7 continuous use with commercial-level cooling technologies and are proven durable with IP5X certified dust protection. So you can install your signage smoothly in dusty environments without the need for additional housing, while meeting around the clock operating requirements. They also feature anti-vibration technologies to protect sensitive components.
Non-Glare, High Brightness Panel for Improved Visibility
The non-glare, high brightness panel features 700nit brightness to improve visibility of your message in bright ambient light.
System-on-Chip Platform for Simple Remote Content Management
Powered by an embedded System-on-Chip (SoC) semiconductor and quad core CPU with 8GB of storage, Samsung's SMART Signage Platform is an open and integrated player side media platform that provides a powerful, streamlined digital signage solution, with digital signage software like MagicInfo T for PC-less content creation, scheduling and playing and remotely managing content.
Ultra-Slim, ADA-Compliant Profile of Just 1.1”
The PHF-P Series features an ultra-thin 6.9mm bezel and 1.1" chassis depth for an elegant, sophisticated look. And they’re ADA-compliant when installed with the appropriate mount.
Enhanced Web Compatibility
Samsung B2B SDK allows developers to build web-based apps for customer functionality and greater interactivity.
More Content Possibilities
PHF-P Series displays are designed to use content from various external sources including Samsung PIMs. Samsung PIMs use Intel® Open Pluggable Specification (OPS) connectivity to enable power and video source delivery through a single cable. No additional power cord is necessary.
Full Connectivity
Discover versatile connectivity options to display a full range of exceptional content that speaks to your audience. Connections include DVI-I, Display Port 1.2, HDMI, USB 2.0, RS232C/RJ45 and more.
Built-In Wi-Fi®
Enjoy the versatility of expanded connectivity to mobile devices, from easy media sharing and screen control to simple content mirroring from a tablet or mobile phone to your display.
