| Technical details | |
| Form factor | uATX |
| USB version | 2.0/3.2 Gen 1 (3.1 Gen 1) |
| USB ports quantity | 7 |
| Product type | Server/Workstation Board |
| Status | Launched |
| Launch date | Q1'17 |
| Maximum memory | 64 GB |
| Supported RAID configuration | Software RAID RST (0,1,10,5) and ESRT2 (0,1,10) |
| Last change | 63903513 |
| Expected discontinuance date | Q3'20 |
| Target market | Small and Medium Business |
| Additional information URL | http://www.intel.com/content/www/us/en/motherboards/server-motherboards/server-board-s1200sp.html |
| Extended warranty available for purchase (select countries) |  |
| Processor | |
| Processor manufacturer | Intel |
| Intel Xeon series | E3-1200 |
| Number of processors supported | 1 |
| CPU configuration (max) | 1 |
| Thermal Design Power (TDP) | 80 W |
| Maximum number of PCI Express lanes | 20 |
| Maximum internal memory supported by processor | 64 GB |
| Memory bandwidth supported by processor (max) | 68.256 GB/s |
| ECC supported by processor | |
| Product family | Single-socket server board |
| Product series | Intel S1200SP |
| Product codename | Silver Pass |
| Memory | |
| Maximum internal memory | 64 GB |
| ECC | |
| Number of DIMM slots | 4 |
| Supported memory types | DDR4 |
| Memory channels | Dual-channel |
| Maximum UDIMM memory | 64 GB |
| Number of memory slots | 4 |
| Networking | |
| Ethernet LAN | |
| Wi-Fi |  |
| Ethernet interface type | Gigabit Ethernet |
| Internal I/O | |
| Number of SATA connectors | 6 |
| Total number of SATA connectors | 6 |
| Back panel I/O ports | |
| Serial ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 2 |
| Storage controllers | |
| HDD interface | SATA |
| RAID levels | 0,1,5,10 |
| RAID support | |
| Supported storage drive interfaces | SATA |
| Packaging content | |
| Packaging content | (1) Server Board, (4) SATA Data Cables, (1) I/O Shield, (1) Attention Document; (1) Quick Start User’s Guide; (1) Quick Configuration Label |
| Expansion slots | |
| PCI Express slots version | 3.0 |
| PCI Express x8 (Gen 3.x) slots | 2 |
| PCI Express x4 (Gen 3.x) slots | 1 |
| Other features | |
| Number of DIMM slots | 4 |
| Maximum UDIMM memory | 64 GB |
| Intel Xeon series | E3-1200 |
| Number of processors supported | 1 |
| CPU configuration (max) | 1 |
| Embedded options available | |
| Thermal Design Power (TDP) | 80 W |
| Graphics output | VGA |
| PCI Express x8 (Gen 3.x) slots | 2 |
| PCI Express x4 (Gen 3.x) slots | 1 |
| Motherboard ARK ID | 97949 |
| Graphics | |
| On-board graphics card | |
| Discrete graphics support | |
| Graphics output | VGA |
| Processor special features | |
| Trusted Platform Module (TPM) | |
| Intel Trusted Execution Technology | |
| Intel I/O Acceleration Technology | |
| Intel Intelligent Power Node Manager | |
| Integrated systems available | |
| Embedded options available | |
| Low halogen options available | |
| Intel Server Management Software | |
| Intel Rapid Storage Technology enterprise | |
| Intel Virtualization Technology for Directed I/O (VT-d) | |
| Features | |
| Motherboard chipset | Intel C232 |
| Chassis type | Rack or Pedestal |
| Motherboard form factor | Micro ATX |
| Trusted Platform Module (TPM) | |
| Component for | Server |
| InfiniBand | |
| Embedded USB (eUSB) SSD option | |
| Physical Address Extension (PAE) | 40 bit |
| Market segment | Server |
| Product family | Single-socket server board |
| Product series | Intel S1200SP |
| Product codename | Silver Pass |
| EAN | 5032037097802 |
| Warranty | 1 year |
Intel® Trusted Execution Technology for safer computing is a versatile set of hardware extensions to Intel® processors and chipsets that enhance the digital office platform with security capabilities such as measured launch and protected execution. It enables an environment where applications can run within their own space, protected from all other software on the system.
Internal IO expansion module indicates a mezzanine connector on Intel® Server Boards that supports a variety of Intel(r) I/O Expansion Modules using a x8 PCI Express* interface. These modules are either RoC (RAID-on-Chip) or SAS (Serial Attached SCSI) modules that are not used for external connectivity through the rear I/O panel.
Intel ® Rapid Storage Technology enterprise (Intel ® RSTe) provides performance and reliability for supported systems equipped with Serial ATA (SATA) devices, Serial Attached SCSI (SAS) devices, and/or solid state drives (SSDs) to enable an optimal enterprise storage solution.
