Key Specifications
Choose one or multiple features to search for items that have the same specifications.
Specifications
Description
Store availability
Delivery
Price development
| Processor | |
| Processor manufacturer | Intel |
| Processor socket | LGA 1151 |
| Intel Xeon series | E3-1200 |
| Memory | |
| Memory voltage | 1.2 V |
| Supported memory clock speeds | 1866,2133 MHz |
| Supported memory types | DDR4 |
| Memory channels | Dual-channel |
| Memory slots type | DIMM |
| Number of memory slots | 4 |
| Weight & dimensions | |
| Width | 244 mm |
| Depth | 244 mm |
| Operational conditions | |
| Operating relative humidity (H-H) | 8 - 80% |
| Operating temperature (T-T) | 10 - 35 °C |
| Networking | |
| Ethernet LAN |  |
| LAN controller | Intel I210 |
| Internal I/O | |
| USB 2.0 connectors | 1 |
| CPU fan connector | |
| Number of COM connectors | 1 |
| ATX Power connector (24-pin) | |
| Chassis intrusion connector | |
| Number of chassis fan connectors | 1 |
| TPM connector | |
| Number of SATA III connectors | 6 |
| Back panel I/O ports | |
| Serial ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 2 |
| VGA (D-Sub) ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| Storage controllers | |
| RAID levels | 0, 1, 5, 10 |
| Supported storage drive interfaces | SATA III |
| Packaging data | |
| Package depth | 308.5 mm |
| Package height | 78.5 mm |
| Package width | 321 mm |
| Packaging content | |
| Cables included | SATA |
| Expansion slots | |
| PCI Express x16 (Gen 3.x) slots | 1 |
| BIOS | |
| Clear CMOS button | |
| Other features | |
| Number of DIMM slots | 4 |
| Quick installation guide | |
| Supported UDIMM module capacity | 16GB |
| PCI Express x8 (Gen 3.x) slots | 1 |
| Graphics | |
| On-board graphics card model | Aspeed AST1400 |
| Discrete graphics support | |
| Performance | |
| Motherboard chipset | Intel C232 |
| Motherboard form factor | Micro ATX |
| Features | |
| Motherboard chipset | Intel C232 |
| Motherboard chipset family | Intel |
| Component for | Server |
| EAN | 4719331841362 |
Supports the Intel Xeon E3-1200 V5 Processors
Formerly known as Greenlow, this new generation of single socket server and workstation processors is based on the 14nm process technology but comes with the new Skylake microarchitecture.
Among the main features of this new product family is the adoption of the DDR4 memory technology within the Xeon E3 line of processors, which brings a significant memory speed and capacity boost over the previous generation (up to 64GB at 2133MHz). The other big new feature is the increase of the number and speed of PCIe lanes available from 8 Gen2 lanes to up to 20 Gen3 lanes, which allows much wider board configuration possibilities.
