Key Specifications
Choose one or multiple features to search for items that have the same specifications.
Specifications
Description
Store availability
Delivery
Price development
Ports & interfaces | |
Number of SATA connectors | 8 |
Motherboard power connector | 20+4 pin ATX |
Floppy drive power connector | 1 |
Number of SATA power connectors | 8 |
Peripheral (Molex) power connectors (4-pin) | 3 |
EPS power connector (8-pin) | ![]() |
CPU power connector (4+4 pin) | ![]() |
PCI Express power connectors (6+2 pin) | 4 |
Cabling type | Modular |
Weight & dimensions | |
Height | 86 mm |
Width | 165 mm |
Depth | 150 mm |
Energy management | |
Nominal power | 650 W |
Efficiency | 88% |
Power protection features | Over current,Over power,Over voltage,Overheating,Short circuit |
Power factor | 0.9 |
Power Factor Correction (PFC) type | Active |
Combined power (+3.3V) | 100 W |
Combined power (+12V) | 650 W |
Combined power (+5V) | 100 W |
Combined power (-12V) | 3.6 W |
Combined power (+5Vsb) | 12.5 W |
Max output current (+3.3V) | 20 A |
Max output current (+12V) | 54.17 A |
Max output current (+5V) | 20 A |
Max output current (-12V) | 0.3 A |
Max output current (+5Vsb) | 2.5 A |
AC input frequency | 50/60 Hz |
AC input voltage | 100 - 240 V |
Total power | 650 W |
Maximum input current (@110V) | 10 A |
Maximum input current (@220V) | 5 A |
Certificates | |
80 PLUS certification | 80 PLUS Bronze |
Design | |
Product colour | Black |
Number of fans | 1 fan(s) |
On/off switch | ![]() |
Fan diameter | 12 cm |
Performance | |
Mean time between failures (MTBF) | 100000 h |
Noise level | 40 dB |
Purpose | PC |
Bearing technology | Sleeve |
ATX version | 2.4 |
EPS version | 2.92 |
Power supply unit (PSU) form factor | ATX |
EAN | 4713224520471 |
Warranty | 2 years |
Hyper M85+ Series, FSP brand new 80 PLUS Bronze semi-modular ATX PSU, featured with DC to DC module and +12V single-rail design, taken with full Japanese e-capacitors and quiet 120mm silent fan,built in with complete protections: OCP, OVP, SCP, OPP, OTP and approved by global safety regulation. Hyper M 85+ Series comes out with two models – 550W and 650W.
FSP HYPER M85+ series of semi-modular ATX PSU feature excellent electrical performance, are 80 PLUS Bronze certified. HYPER M85+ units feature Japanese electrolytic capacitors with a full protection suite. The modular cable system assists with a clean installation and helps maximize airflow through your computer's case.
Excesses 80 Plus® Bronze Standard
HYPER M85+ 650W not only comes with 80 PLUS bronze certified but also excesses the standard through its high efficiency up to 88%, 80 PLUS Silver certified.
DC to DC Module Design Provides Stable Power Outputs
HYPER M85+ series designed with DC-DC module are able to provide a consistent power source and good power conversion efficiency, which is the right power for your needs.
Fast Installation with Semi-modular Design
The semi-modular ATX PSU with flat black ribbon cables makes installation fast and straightforward, with good-looking results and enhances airflow patterns inside the case.
120mm Low Noise Fan
120mm quiet fan and high ventilation- effect fan guard design makes HYPER M85+ spin quietly and keep cooling under maximum operation.
Full Japanese E-capacitor Inside
The high-quality Japanese E-capacitors can prolong product's life span by producing supreme stability and performance with low impedance characteristics.
Complete Protection
OCP, OVP, SCP, OPP, UVP, OTP, a full guardian of circuit protections to keep hardware safe.
FSP HYPER M85+ series of semi-modular ATX PSU feature excellent electrical performance, are 80 PLUS Bronze certified. HYPER M85+ units feature Japanese electrolytic capacitors with a full protection suite. The modular cable system assists with a clean installation and helps maximize airflow through your computer's case.
Excesses 80 Plus® Bronze Standard
HYPER M85+ 650W not only comes with 80 PLUS bronze certified but also excesses the standard through its high efficiency up to 88%, 80 PLUS Silver certified.
DC to DC Module Design Provides Stable Power Outputs
HYPER M85+ series designed with DC-DC module are able to provide a consistent power source and good power conversion efficiency, which is the right power for your needs.
Fast Installation with Semi-modular Design
The semi-modular ATX PSU with flat black ribbon cables makes installation fast and straightforward, with good-looking results and enhances airflow patterns inside the case.
120mm Low Noise Fan
120mm quiet fan and high ventilation- effect fan guard design makes HYPER M85+ spin quietly and keep cooling under maximum operation.
Full Japanese E-capacitor Inside
The high-quality Japanese E-capacitors can prolong product's life span by producing supreme stability and performance with low impedance characteristics.
Complete Protection
OCP, OVP, SCP, OPP, UVP, OTP, a full guardian of circuit protections to keep hardware safe.
