Lenovo ThinkCentre M720q 10T7 - Mini pöytätietokone - 1 x Core i5 8400T / 1.7 GHz - RAM 8 GB - SSD 128 GB - UHD Graphics 630 - GigE - WLAN: 802.11ac, Bluetooth

Manufacturer: LENOVO
ID: 10T7006SMX
Product unavailable
This product is end of life or currently not available.
Specifications
Description
Store availability
Delivery
Price development
Technical details
Device typeSSD
Processor
Processor modeli5-8400T
Number of processors installed1
Processor manufacturerIntel
Processor lithography14 nm
Processor familyIntel Core i5
Processor socketLGA 1151
SteppingU0
Processor cores6
System bus rate8 GT/s
Processor threads6
PCI Express slots version3.0
Processor operating modes64-bit
Processor boost frequency3.3 GHz
Processor cache9 MB
Tjunction100 °C
Bus typeDMI3
PCI Express configurations1x16,1x8+2x4,2x8
Processor frequency1.7 GHz
Thermal Design Power (TDP)35 W
Processor codenameCoffee Lake
Maximum number of PCI Express lanes16
Configurable TDP-down25 W
Processor cache typeSmart Cache
Configurable TDP-down frequency1.2 GHz
Maximum internal memory supported by processor64 GB
Memory types supported by processorDDR4-SDRAM
Memory clock speeds supported by processor2666 MHz
Memory bandwidth supported by processor (max)41.6 GB/s
ECC supported by processorcross
Memory
Internal memory typeDDR4-SDRAM
Memory slots2x SO-DIMM
Maximum internal memory32 GB
Non-ECCcheckmark
Memory channelsDual-channel
Internal memory8 GB
Ports & interfaces
Serial ports quantity1
Ethernet LAN (RJ-45) ports1
Headphone outputs1
Microphone incheckmark
DVI portcross
VGA (D-Sub) ports quantity1
HDMI ports quantity1
DisplayPorts quantity1
Combo headphone/mic portcheckmark
USB 3.0 (3.1 Gen 1) Type-A ports quantity3
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity1
USB 3.1 (3.1 Gen 2) Type-A ports quantity2
Weight & dimensions
Weight1.32 kg
Height34.5 mm
Width179 mm
Depth182.9 mm
Energy management
Power supply65 W
Networking
Wi-Fi standards802.11a,Wi-Fi 5 (802.11ac),802.11b,802.11g,Wi-Fi 4 (802.11n)
Cabling technology10/100/1000Base-T(X)
Bluetooth version4.2
Ethernet LANcheckmark
Bluetoothcheckmark
Wi-Ficheckmark
Ethernet LAN data rates10,100,1000 Mbit/s
Top Wi-Fi standardWi-Fi 5 (802.11ac)
Storage
Drive capacity128 GB
Total storage capacity128 GB
Card reader integratedcross
Number of SSDs installed1
Storage mediaSSD
Number of storage drives installed1
Operating system/software
Operating system installedWindows 10 Pro
Operating system architecture64-bit
Packaging content
Display includedcross
Mouse includedcheckmark
Manualcheckmark
Keyboard includedcheckmark
Design
Chassis typemini PC
Product colourBlack
Placement supportedHorizontal/Vertical
Volume1 L
Housing materialMetal
Graphics
On-board graphics card modelIntel® UHD Graphics 630
Discrete graphics card modelNot available
On-board graphics cardcheckmark
On-board graphics adapter base frequency350 MHz
On-board graphics adapter dynamic frequency (max)1050 MHz
On-board graphics adapter ID0x3E92
Maximum on-board graphics adapter memory64 GB
Number of displays supported (on-board graphics)3
On-board graphics adapter DirectX version12.0
On-board graphics adapter OpenGL version4.5
Discrete graphics adaptercross
On-board graphics adapter familyIntel® UHD Graphics
Processor special features
Supported instruction setsAVX 2.0,SSE4.1,SSE4.2
Processor codeSR3X6
Intel® Identity Protection Technology (Intel® IPT)checkmark
Intel® Hyper Threading Technology (Intel® HT Technology)cross
Intel® Turbo Boost Technology2.0
Intel® Quick Sync Video Technologycheckmark
Intel® InTru™ 3D Technologycheckmark
Intel® Clear Video HD Technology (Intel® CVT HD)checkmark
Intel® AES New Instructions (Intel® AES-NI)checkmark
Enhanced Intel SpeedStep Technologycheckmark
Execute Disable Bitcheckmark
Idle Statescheckmark
Thermal Monitoring Technologiescheckmark
Intel Trusted Execution Technologycross
Scalability1S
CPU configuration (max)1
Intel Enhanced Halt Statecheckmark
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)checkmark
Intel VT-x with Extended Page Tables (EPT)checkmark
Embedded options availablecross
Intel TSX-NIcross
Intel® Secure Keycheckmark
Thermal solution specificationPCG 2015A
Intel 64checkmark
Intel Stable Image Platform Program (SIPP)cross
Intel® OS Guardcheckmark
Intel Virtualization Technology for Directed I/O (VT-d)checkmark
Intel Clear Video Technologycheckmark
Intel Software Guard Extensions (Intel SGX)checkmark
Intel Identity Protection Technology version1.00
Intel Secure Key Technology version1.00
Intel Virtualization Technology (VT-x)checkmark
Intel Stable Image Platform Program (SIPP) version0.00
Intel TSX-NI version0.00
Processor package size37.5 x 37.5 mm
Conflict-Free processorcheckmark
Processor ARK ID129940
Performance
Motherboard chipsetIntel B360
Trusted Platform Module (TPM)checkmark
Password protection typeHDD, Power on, Supervisor
Product typeMini PC
Password protectioncheckmark
Audio chipRealtek ALC233VB2
EAN0192940521094
Warranty3 years
Source: Icecat.biz

The compact PC that makes a big impact
The ThinkCentre M720 Tiny gives most desktops a run for their money but won't clutter your desk. Powered by Intel® 8th Gen processors with next-gen memory and storage, it’s fast, responsive, and versatile. Tiny in name but not on performance, this compact PC boasts enhanced security, reliability, and energy efficiency, too.

Perfect for users, even better for IT managers
Power-packed and business-ready, the ThinkCentre M Series, which includes the Tower, SFF, Tiny, and Thin Client, is the perfect choice for progressive IT managers looking for high-performance, reliable, and secure desktops. Easy to set up, deploy, and manage in any office environment, they boast the latest processing, memory, and storage technology, and have a number of large storage capacity options. In addition, they come with robust security features to safeguard your critical data and the built-in reliability your organization can count on.

Real power, real results
Despite its size, the ThinkCentre M720 Tiny is as powerful and responsive as a full-sized desktop. With the latest generation of Intel® processors, plus PCIe SSD storage coupled with DDR4 memory, it takes everything in its stride, enabling you to get things done more quickly and efficiently

What are you waiting for?
For an even faster, smoother, and more responsive PC experience, opt for a hard drive with Intel® Optane™ memory. By recognizing the way you work, this smart next-gen technology accelerates everything—from booting up and opening large apps, to finding files fast and multitasking seamlessly.

All the right connections
The ThinkCentre M720 Tiny is packed with ports, including USB 3.1 Gen 2 for faster charging and transferring data even if the PC is shut down or in sleep mode. You can also opt for a Thunderbolt™ 3 USB-C port—the lightning-quick connection technology for high-resolution displays and more robust performance.

One less thing to worry about
Every ThinkCentre M720 Tiny is equipped with Smart USB Protection. It lets you restrict what USB devices can access the PC, while ensuring that no malware enters the system or network through USB ports. In addition, your data is encrypted via the Trusted Platform Module (TPM), and a Kensington Lock is included for you to physically secure the M720 Tiny.

Can fit—and work—anywhere
On a bookshelf, behind a monitor, under the desk…you can fit your ThinkCentre M720 Tiny anywhere. What’s more, it’s been rigorously tested to work in almost any environment—from the arctic to the desert and everywhere in between.

Go green, save green
With Energy Star® 7.0 and EPEAT™ Gold ratings, the ThinkCentre M720 Tiny is proven to be extremely energy efficient. In addition, it also has been rigorously test and awarded the world's first Ultra Low Noise Certificate by TÜV Rheinland.
