Asustor AS3104T NAS 4-Bay Tower/2GB/Intel/GbEx2

Manufacturer: ASUS
ID: AS3104T
Product unavailable
This product is end of life or currently not available.

Key Specifications

Choose one or multiple features to search for items that have the same specifications.
Specifications
Description
Store availability
Delivery
Price development
Processor
Processor modelN3050
Processor lithography14 nm
Processor familyIntel Celeron
Processor socketBGA 1170
SteppingC0
Processor cores2
System bus rate5 GT/s
Processor threads2
PCI Express slots version2.0
Processor operating modes64-bit
Processor boost frequency2.16 GHz
Processor cache2 MB
CPU configuration (max)1
Tjunction90 °C
Processor frequency1.6 GHz
Thermal Design Power (TDP)6 W
Scenario Design Power (SDP)4 W
Processor codenameBraswell
Processor cache typeL2
Processor seriesIntel Celeron N3000 series
Maximum internal memory supported by processor8 GB
ECC supported by processorcross
Processor package size25 mm
Conflict-Free processorcheckmark
Integrated 4G WiMAXcross
Processor ARK ID87257
Memory
Internal memory typeDDR3L
Memory clock speed1600 MHz
Internal memory2 GB
Ports & interfaces
Ethernet LAN (RJ-45) ports1
HDMI ports quantity1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity3
Weight & dimensions
Weight1.6 kg
Height165 mm
Width164 mm
Depth218 mm
Energy management
Power consumption (typical)24.5 W
Power consumption (sleep)0.69 W
Operational conditions
Operating relative humidity (H-H)5 - 95%
Operating temperature (T-T)5 - 35 °C
Networking
Supported network protocolsCIFS / SMB, SMB 2.0 / 3.0, AFP, NFS, FTP (Unicode Supported), TFTP, WebDAV, Rsync, SSH, SFTP, iSCSI, HTTP, HTTPS, Proxy, SNMP, Syslog
Ethernet LANcheckmark
Wake-on-LAN readycheckmark
Wi-Ficross
Jumbo frames supportcheckmark
DHCP clientcheckmark
Ethernet LAN data rates10,100,1000 Mbit/s
iSCSI supportcheckmark
Storage
RAID levels0, 1, 5, 6, 10, JBOD
Supported file systemsFAT32,HPFS,NTFS,ext3,ext4
RAID supportcheckmark
Storage drive size3.5"
Storage drive interfaceSerial ATA II, Serial ATA III
Number of storage drives supported4
Storage drives installedcross
Maximum supported storage capacity32 TB
Installed storage drive typecross
Supported storage drive typesHDD
Hot-swap drive bayscheckmark
Certificates
CertificationFCC, CE, VCCI, BSMI, C-TICK
Operating system/software
Operating system installedADM
Operating system version2.6
Windows operating systems supportedcheckmark
Mac operating systems supportedMac OS X 10.6 Snow Leopard,Mac OS X 10.7 Lion,Mac OS X 10.8 Mountain Lion,Mac OS X 10.9 Mavericks
Linux operating systems supportedcheckmark
Server operating systems supportedWindows Server 2003,Windows Server 2008,Windows Server 2012
Design
Product colourBlack
Number of fans1 fan(s)
Cooling typeActive
Fan diameter12 cm
Graphics
On-board graphics card modelcheckmark
On-board graphics card base frequency320 MHz
On-board graphics card burst frequency600 MHz
Maximum on-board graphics card memory8 GB
Number of displays supported (on-board graphics)3
Processor special features
Intel® Identity Protection Technology (Intel® IPT)checkmark
Intel® Anti-Theft Technology (Intel® AT)cross
Intel® Smart Response Technologycross
Intel Smart Connect Technologycross
Intel® vPro™ Technologycross
Intel® Hyper Threading Technology (Intel® HT Technology)cross
Intel® Turbo Boost Technologycross
Intel® Quick Sync Video Technologycheckmark
Intel® InTru™ 3D Technologycross
Intel® Wireless Display (Intel® WiDi)checkmark
Intel® Clear Video HD Technology (Intel® CVT HD)checkmark
Intel® Insider™cross
Intel® AES New Instructions (Intel® AES-NI)checkmark
Enhanced Intel SpeedStep Technologycheckmark
Execute Disable Bitcheckmark
Idle Statescheckmark
Thermal Monitoring Technologiescheckmark
Intel Trusted Execution Technologycross
Intel Enhanced Halt Statecheckmark
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)checkmark
Intel VT-x with Extended Page Tables (EPT)checkmark
Embedded options availablecheckmark
Intel Rapid Storage Technologycross
Intel® High Definition Audio (Intel® HD Audio)checkmark
Intel® Small Business Advantage (Intel® SBA)cross
Intel® Secure Keycheckmark
Intel 64checkmark
Intel Stable Image Platform Program (SIPP)cross
Intel® OS Guardcross
UARTcheckmark
Intel Virtualization Technology for Directed I/O (VT-d)cross
Number of execution units12
Maximum number of PCI Express lanes4
Intel Secure Bootcheckmark
Intel Clear Video Technologycheckmark
Intel Identity Protection Technology version1.00
Intel Secure Key Technology version1.00
Intel Secure Boot Technology version1.00
Intel Small Business Advantage (SBA) version0.00
Intel Smart Response Technology version0.00
Intel Virtualization Technology (VT-x)checkmark
Intel Stable Image Platform Program (SIPP) version0.00
Intel Smart Connect Technology version0.00
Memory types supported by processorDDR3L-SDRAM
Memory channels supported by processorDual
Performance
TypeNAS
Security algorithmsHTTPS,SSH,SSL/TLS
Noise level (idle)19.7 dB
Multilingual supportcheckmark
Device classHome & Home Office
Backup functioncheckmark
Backup featuresCloud
EAN4710474830749
Source: Icecat.biz

Powered by the latest Intel Celeron processors
AS3104 is powered by Intel Celeron Braswell dual-core processors, equipped with 2GB of dual-channel memory, and feature read speeds of over112 MB/s and write speeds of over 112 MB/s under RAID 5 configurations.

Dual-channel power
The AS31 models support dual-channel memory, be able to smoothly playback 4K video. Furthermore, AS31 series devices are not only energy efficient, but offer a combination of performance and price that is unmatched in its class. Get ready to enjoy brilliant ultra high-definition 4K video from the comfort of your own home!

Supercharge your multimedia experience
You no longer need to worry about running into resolution compatibility issues when playing videos on your phone, tablet or computer.
Media Converter utilizes a quick and simple conversion method, allowing you to execute conversion tasks in the background.
The exclusive built-in Hyper-Transcoding technology was expertly crafted by ASUSTOR. This technology utilizes the Intel CPU hardware acceleration function to make video file conversions faster and simpler than ever before. Using Hyper-Transcoding to convert video files can reduce the normal conversion time by at least 10 times.

Toolless installation
The AS31 series’ sliding outer cover design allows it to be conveniently removed when needed. The inner hard disk rails and outer cover all use hand screws allowing for the simple installation of hard disks without any extra tools.

Add modern flair to your favorite space
The AS31 series devices redefine the aesthetics of a NAS. The stylish diamond-plate finished cover makes it an elegant addition to any space, no matter if it is a family room, living room or office.

Hardware encryption engine
Protecting your data is ASUSTOR’s top priority. The AS31 series devices feature Intel AES-NI encryption engines, allowing data to be completely protected from the moment it is first stored on the NAS. This means that you never have to worry about your confidential data falling into the wrong hands even if your hard disks become lost or stolen. The built-in hardware encryption engine also features read speeds of over 112 MB/s and write speeds of over 71 MB/s for encrypted data providing an optimal combination of file security and system performance.

High capacity cloud storage for all your digital assets
The AS3104 provides a large capacity NAS for home users at an affordable price. Users can install four 8 TB hard disks to immediately create a high capacity storage space of up to 32 TB. When taking photos or recording videos of family vacations, gatherings and other cherished memories, users no longer need to be confined to the limited storage on memory cards. With high capacity AS3104, users can save all of their videos and photos in high quality resolution, preserving them perfectly. Additionally, RAID 5 and 6 storage volume setting provide comprehensive protection for all digital assets stored on the NAS, minimizing the risk of data loss due to hard disk failure or accidents.

Create the Ultimate Home Multimedia Center
Enjoy electrifying digital entertainment on demand with ASUSTOR NAS. The built-in HDMI interface and variety of multimedia Apps let you to enjoy all of your favorite multimedia from your NAS by directly connecting it to an LCD/LED TV or amplifier.

ASUSTOR NAS supports Full HD (1080p) output, allowing you to savor your movies, TV shows, music and photos in high definition. What's more, through ASUSTOR's App Central, you can install additional multimedia server Apps such as UPnP Media Server and iTunes Server giving your NAS the ability to stream multimedia content to your computers, TVs and mobile devices.

Additionally, you can also further add a surround sound amplifier to create an unprecedented high definition multi-channel listening experience. Imagine watching your favorite racing movie and being immersed in the roar of the engines. Feel the thrill and the sense of speed as you listen to the sounds of cars whizzing by. Prepare for an unparalleled entertainment experience that will have you on the edge of your seat.

Even More Reliable After-Sales Service
ASUSTOR has extended the warranty period on all of its products to three years, continuing to make customer service a huge priority. It is ASUSTOR's mission to continue to provide its customers with products of the highest quality along with only the most reliable and attentive after-sales service and technical support.
