CH/BTP/PE T640/Chassis 8 x 3.5"/Xeon Bro

Technical details
Device type	SSD
Processor
Processor model	3106
Number of processors installed	1
Processor lithography	14 nm
Processor family	Intel Xeon
Processor socket	LGA 3647
Stepping	U0
Processor cores	8
Processor code	SR3GL
Processor threads	8
Processor operating modes	64-bit
Processor cache	11 MB
Execute Disable Bit
Scalability	2S
Tcase	77 °C
Embedded options available
Processor frequency	1.7 GHz
Thermal Design Power (TDP)	85 W
Processor codename	Skylake
Maximum number of PCI Express lanes	48
Processor cache type	L3
Maximum internal memory supported by processor	768 GB
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	2133 MHz
Memory channels supported by processor	Hexa
ECC supported by processor
Processor package size	76 x 56.5 mm
Conflict-Free processor
Memory
Internal memory type	DDR4-SDRAM
Memory slots	24 x DIMM
Maximum internal memory	3000 GB
ECC
Memory layout (slots x size)	1 x 16 GB
Internal memory	16 GB
Ports & interfaces
Serial ports quantity	1
USB 2.0 ports quantity	3
Ethernet LAN (RJ-45) ports	2
VGA (D-Sub) ports quantity	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	5
Weight & dimensions
Package weight	40.9 kg
Height	443.5 mm
Width	304.5 mm
Depth	692.8 mm
Package depth	616 mm
Package height	598 mm
Package width	905 mm
Energy management
Power supply	750 W
Power supply input frequency	50 - 60 Hz
Redundant power supply (RPS) support
Number of main power supplies	1
Number of redundant power supplies installed	1
Operational conditions
Operating altitude	0 - 3048 m
Operating relative humidity (H-H)	10 - 80%
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	5 - 95%
Non-operating altitude	0 - 12000 m
Networking
Ethernet LAN
Ethernet interface type	10 Gigabit Ethernet
Storage
Drive capacity	240 GB
Optical drive type	N
Hot-Plug support
Total storage capacity	240 GB
Number of HDDs supported	8
Maximum storage capacity	216 TB
Supported HDD sizes	3.5"
RAID support
Number of SSDs installed	1
Supported storage drive interfaces	SAS,Serial ATA III
Supported RAID controllers	PERC H330+
Operating system/software
Compatible operating systems	- Canonical Ubuntu LTS - Citrix XenServer - Microsoft Windows Server with Hyper-V - Red Hat Enterprise Linux
Operating system installed
Packaging content
Cables included	AC
Expansion slots
PCI Express slots version	3.0
PCI Express x8 (Gen 3.x) slots	1
PCI Express x4 (Gen 3.x) slots	1
PCI Express x16 (Gen 3.x) slots	1
Design
Rack mounting
Chassis type	Tower (5U)
Product colour	Black
Redundant fans support
Processor special features
Intel® Hyper Threading Technology (Intel® HT Technology)
Intel® Turbo Boost Technology
Intel® AES New Instructions (Intel® AES-NI)
Enhanced Intel SpeedStep Technology
Intel Trusted Execution Technology
Intel VT-x with Extended Page Tables (EPT)
Intel TSX-NI
Intel 64
Intel Virtualization Technology for Directed I/O (VT-d)
Intel Virtualization Technology (VT-x)
Processor ARK ID	123540
Performance
Remote administration	iDRAC9 Enterprise
EAN	5397184231708
Warranty	3 years
Source: Icecat.biz

Powerful, versatile and scalable
Scale as your workloads evolve, with peak 2-socket server performance and huge internal storage capacity.
