INTEL NUC Compute Element BKCM8I7CB8N Core i7-8565U RAM 8GB LPDDR3
Manufacturer: INTEL
ID: BKCM8I7CB8N
Product unavailable
This product is end of life or currently not available.
This product is end of life or currently not available.
Specifications
Description
Store availability
Delivery
Price development
| Processor | |
| Processor model | i7-8565U |
| Processor lithography | 14 nm |
| Processor family | Intel Core i7 |
| Processor cores | 4 |
| Processor threads | 8 |
| Processor boost frequency | 4.6 GHz |
| Processor cache | 8 MB |
| Bus type | OPI |
| Processor frequency | 1.8 GHz |
| Configurable TDP-down | 10 W |
| Configurable TDP-down frequency | 0.8 GHz |
| Configurable TDP-up frequency | 2 GHz |
| Configurable TDP-up | 25 W |
| Memory types supported by processor | LPDDR3-SDRAM |
| Processor generation | 8th gen Intel® Core™ i7 |
| Memory | |
| Internal memory type | LPDDR3 |
| ECC |  |
| Memory clock speed | 2133 MHz |
| Supported memory types | DDR3 |
| Memory channels | Dual-channel |
| Internal memory | 8 GB |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 0 |
| HDMI ports quantity | 1 |
| DisplayPorts quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 0 |
| Weight & dimensions | |
| Height | 65 mm |
| Width | 95 mm |
| Depth | 6 mm |
| Networking | |
| Wi-Fi standards | Wi-Fi 5 (802.11ac) |
| Bluetooth version | 5.0 |
| Bluetooth |  |
| Wi-Fi | |
| Storage | |
| Card reader integrated | |
| Operating system/software | |
| Compatible operating systems | Windows 10, 64-bit*|Windows 10 IoT Enterprise* |
| Packaging content | |
| Processor included | Intel® Core™ i7-8565U Processor (8M Cache, up to 4.60 GHz) |
| Graphics | |
| On-board graphics card model | Intel® UHD Graphics |
| On-board graphics card | |
| Number of displays supported | 3 |
| Graphics output | 2x DDI (configurable as DP/HDMI), 1x eDP |
| Number of displays supported (on-board graphics) | 3 |
| Discrete graphics card | |
| Processor special features | |
| Intel Flex Memory Access | |
| Intel® AES New Instructions (Intel® AES-NI) | |
| Enhanced Intel SpeedStep Technology | |
| Execute Disable Bit | |
| Idle States | |
| Intel Trusted Execution Technology | |
| Intel Enhanced Halt State | |
| Intel VT-x with Extended Page Tables (EPT) | |
| Embedded options available | |
| Intel TSX-NI | |
| Intel 64 | |
| Intel Virtualization Technology for Directed I/O (VT-d) | |
| Intel Clear Video Technology | |
| Intel Software Guard Extensions (Intel SGX) | |
| Intel Identity Protection Technology version | 1.00 |
| Intel Secure Key Technology version | 1.00 |
| Intel Smart Response Technology version | 1.00 |
| Intel Virtualization Technology (VT-x) | |
| Intel TSX-NI version | 0.00 |
| Intel® Platform Trust Technology (Intel® PTT) | |
| Intel® vPro™ Platform Eligibility | |
| Performance | |
| Status | Launched |
| ARK ID | 205881 |
| Export Control Classification Number (ECCN) | 5A992C |
| Commodity Classification Automated Tracking System (CCATS) | G157815L2 |
| Logistics data | |
| Harmonized System (HS) code | 84713000 |
| EAN | 0675901794541 |
| Warranty | 1 year |
| Source: Icecat.biz | |
Intel® Virtualization Technology for Directed I/O (VT-d)
Intel® Virtualization Technology for Directed I/O (VT-d) continues from the existing support for IA-32 (VT-x) and Itanium® processor (VT-i) virtualization adding new support for I/O-device virtualization. Intel VT-d can help end users improve security and reliability of the systems and also improve performance of I/O devices in virtualized environments.
Intel® Virtualization Technology (VT-x)
Intel® Virtualization Technology (VT-x) allows one hardware platform to function as multiple “virtual” platforms. It offers improved manageability by limiting downtime and maintaining productivity by isolating computing activities into separate partitions.
Intel® Virtualization Technology for Directed I/O (VT-d) continues from the existing support for IA-32 (VT-x) and Itanium® processor (VT-i) virtualization adding new support for I/O-device virtualization. Intel VT-d can help end users improve security and reliability of the systems and also improve performance of I/O devices in virtualized environments.
Intel® Virtualization Technology (VT-x)
Intel® Virtualization Technology (VT-x) allows one hardware platform to function as multiple “virtual” platforms. It offers improved manageability by limiting downtime and maintaining productivity by isolating computing activities into separate partitions.
