No price development information for this product.
Product unavailable
This product is end of life or currently not available.
This product is end of life or currently not available.
Key Specifications
Choose one or multiple features to search for items that have the same specifications.
Specifications
Description
Store availability
Delivery
Price development
| Ports & interfaces | |
| Floppy disk drive connector |  |
| Motherboard power connector | 20+4 pin ATX |
| Number of SATA power connectors | 16 |
| Peripheral (Molex) power connectors (4-pin) | 8 |
| EPS power connector (8-pin) | |
| CPU power connector (4+4 pin) | |
| PCI Express power connectors (6+2 pin) | 8 |
| Cabling type | Fully-Modular |
| Motherboard power cable length | 60 cm |
| CPU power cable length | 70 cm |
| PCI Express power cable length | 55 cm |
| Weight & dimensions | |
| Weight | 3.1 kg |
| Height | 86 mm |
| Width | 150 mm |
| Depth | 180 mm |
| Energy management | |
| Nominal power | 1200 W |
| Efficiency | 94% |
| Power protection features | Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage |
| Power Factor Correction (PFC) type | Active |
| Combined power (+3.3V) | 120 W |
| Combined power (+12V) | 996 W |
| Combined power (+5V) | 120 W |
| Combined power (-12V) | 3.6 W |
| Combined power (+5Vsb) | 12.5 W |
| Max output current (+3.3V) | 25 A |
| Max output current (+12V) | 100 A |
| Max output current (+5V) | 22 A |
| Max output current (-12V) | 0.3 A |
| Max output current (+5Vsb) | 2.5 A |
| AC input frequency | 50 - 60 Hz |
| Total power | 1200 W |
| Operational conditions | |
| Operating relative humidity (H-H) | 5 - 95% |
| Storage temperature (T-T) | -20 - 70 °C |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage relative humidity (H-H) | 5 - 95% |
| Packaging data | |
| Manual | |
| Package type | Box |
| Number of straps | 5 |
| Cable storage bag included | |
| Certificates | |
| 80 PLUS certification | 80 PLUS Platinum |
| Packaging content | |
| Cables included | AC |
| Other features | |
| Number of screws | 4 |
| Screws included | |
| Cable ties included | |
| Design | |
| Product colour | Black |
| Number of fans | 1 fan(s) |
| Cooling type | Active |
| Fan diameter | 13.5 cm |
| Fan location | Top |
| Performance | |
| Certification | UL, FCC, CB, CE, EAC, KC, WEEE |
| Purpose | PC |
| Power supply unit (PSU) form factor | ATX |
| EAN | 8809213768781 |
| Warranty | 1 year |
High quality components
High quality made in Japan 105°C capacitor guarantees Stability at high temperatures, frequencies and currents.
High quality components
Powerful and highly reliable DC-DC module
Active PFC
Built-in Active PFC circuit provides high power factor and efficiency
Single Rail +12V DC output
Single +12V DC output design for stabilized voltage supply
Secondary Protection IC
Heavy-duty protection circuitry of Over Current, Over Power, Over Voltage, Under Voltage, Over Temperature and Short-Circuit Protection.
Modular cable type
Neatly organized DC output modular cable help to increase air flow inside the case.
Ultra quiet 135mm for smart cooling
Smart Fan control system optimizes thermal control while minimizing noise levels.
