Key Specifications
Choose one or multiple features to search for items that have the same specifications.
Specifications
Description
Store availability
Delivery
Price development
| Ports & interfaces | |
| ATX Power connector (24-pin) |  |
| Motherboard power connector | 24-pin ATX |
| Floppy drive power connector | 1 |
| Number of SATA power connectors | 8 |
| Peripheral (Molex) power connectors (4-pin) | 3 |
| EPS power connector (8-pin) | |
| CPU power connector (4+4 pin) | |
| PCI Express power connectors (6+2 pin) | 5 |
| Cabling type | Fully-Modular |
| Motherboard power cable length | 60 cm |
| SATA power cable length | 600 mm |
| CPU power cable length | 55 cm |
| Peripheral (Molex) power cable length | 600 mm |
| PCI Express power cable length | 55 cm |
| EPS power connector (4+4 pin) | |
| Weight & dimensions | |
| Weight | 3.08 kg |
| Height | 86 mm |
| Width | 150 mm |
| Depth | 160 mm |
| Energy management | |
| Input current | 4.5 - 9 A |
| Nominal power | 700 W |
| Efficiency | 91% |
| Power protection features | Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage |
| Power factor | 99.9 |
| Power Factor Correction (PFC) type | Active |
| Combined power (+12V) | 696 W |
| Combined power (-12V) | 3.6 W |
| Combined power (+5Vsb) | 15 W |
| Max output current (+3.3V) | 20 A |
| Max output current (+12V) | 58 A |
| Max output current (+5V) | 20 A |
| Max output current (-12V) | 0.3 A |
| Max output current (+5Vsb) | 3 A |
| AC input frequency | 50 - 60 Hz |
| AC input voltage | 100 - 240 V |
| Total power | 700 W |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Certificates | |
| 80 PLUS certification | 80 PLUS Gold |
| Design | |
| Product colour | Black |
| Number of fans | 1 fan(s) |
| On/off switch | |
| Cooling type | Active |
| Fan diameter | 13.5 cm |
| Fan location | Top |
| Fan speed | 1000 - 1900 RPM |
| Performance | |
| Certification | UL, FCC, KC, CE, CB, RoHS, EAC |
| Mean time between failures (MTBF) | 100000 h |
| Purpose | PC |
| Bearing technology | Ball bearing |
| ATX version | 2.31 |
| Silent mode | |
| Power supply unit (PSU) form factor | ATX |
| EAN | 8809213769283 |
| Warranty | 1 year |
High-Efficiency silent computer power supply
