Product unavailable
This product is end of life or currently not available.
This product is end of life or currently not available.
Specifications
Description
Store availability
Delivery
Price development
Display | |
Contrast ratio (typical) | 1200:1 |
Viewing angle, horizontal | 178° |
Viewing angle, vertical | 178° |
Display diagonal | 2.49 m (98") |
Display brightness | 500 cd/m² |
Response time | 8 ms |
Display resolution | 4K 3840 x 2160 pixels |
Touchscreen | ![]() |
Contrast ratio (dynamic) | 1000000:1 |
Display technology | IPS |
Native aspect ratio | 16:9 |
HD type | 4K Ultra HD |
Display number of colours | 1.06 billion colours |
Audio | |
Built-in speaker(s) | ![]() |
Ports & interfaces | |
Ethernet LAN | ![]() |
DVI port | ![]() |
DVI-D ports quantity | 1 |
Wi-Fi | ![]() |
HDMI ports quantity | 3 |
HDMI version | 2.2/1.4 |
DisplayPorts quantity | 2 |
USB version | 2.0 |
Remote (IR) input | 1 |
DisplayPorts out | 1 |
USB ports quantity | 1 |
RS-232C | ![]() |
USB port | ![]() |
Weight & dimensions | |
Weight | 18.1 kg |
Height | 1246.8 mm |
Width | 2191.8 mm |
Depth | 83.8 mm |
Energy management | |
Power consumption (typical) | 420 W |
Heat dissipation | 1433.25 BTU/h |
AC input frequency | 50 - 60 Hz |
AC input voltage | 100 - 240 V |
Operational conditions | |
Operating relative humidity (H-H) | 10 - 80% |
Operating temperature (T-T) | 0 - 40 °C |
Certificates | |
Certification | CB, NRTL, Yes, FCC Class "A" / CE / KC, ErP |
Packaging content | |
Remote control included | ![]() |
Design | |
Product colour | Black |
Placement supported | Indoor |
Panel mounting interface | 800 x 400 mm |
Product design | Digital signage flat panel |
Bezel width (side) | 1.49 cm |
Bezel width (top) | 1.49 cm |
Bezel width (bottom) | 1.49 cm |
VESA mounting | ![]() |
Orientation | Horizontal/Vertical |
Performance | |
Operating hours (hours/days) | 24/7 |
EAN | 8806098774203 |
Warranty | 3 years |
Source: Icecat.biz |
Clear View with Non-glare Coating
Viewers can be annoyed by unnecessary reflections when watching a screen under brightly lit conditions. The UH5F-H series has resolved such inconveniences by increasing the level of haze, which enhances visibility and text readability.
ULTRA HD Resolution
With the resolution that is 4 times higher than FHD, it makes the color and details of the contents more vivid and realistic. In addition, the wide viewing angle applied with an IPS panel, provides clear contents with no distortion.
High-Performance with webOS
Built-in Quad Core SoC can execute several tasks at once while providing smooth content playback without the need for a media player. Also, LG webOS smart signage platform enhances user convenience with intuitive GUI and simple app development tools.
Various Sensor Applications
LG webOS smart signage platform easily supports connections with external sensors such as GPIO, NFC/RFID, temperature sensors, etc, via USB plug-in. The overall cost for maintenance is reduced as there's no need to purchase additional software or media players for creating value-added solutions.
Compatible with AV Control System
The UH5F-H series has been certified Crestron Connected® for high compatibility with professional AV controls to achieve seamless integration and automated control*, boosting business management efficiency.
Compatible with Video Conference System
For the optimum visual meeting, the UH5F-H series has certified its compatibility with Cisco System that offers powerful and integrated control* for a smarter video conference, eliminating a waste of time for setting up the picture quality or changing input on incoming calls.
Real-time Monitoring & Control
Through the Control Manager, the embedded web monitoring solution, you can control and monitor the status of multiple UH5F-H series displays in different locations in real-time. It is available on internet connected devices, allowing you to flexibly and rapidly respond to emergency situations anywhere
Multiscreen Feature with PBP / PIP
PBP (Picture-By-Picture)features multiple screens in a single display with up to 4 input sources while PIP (Picture-In-Picture) supports playing both a main screen and a subscreen at the same time with various layouts. This gives great flexibility to allocate space for each content source.
Wireless Access Point
The UH5F-H series operates as a virtual router which can be an wireless access point for mobile devices.
Viewers can be annoyed by unnecessary reflections when watching a screen under brightly lit conditions. The UH5F-H series has resolved such inconveniences by increasing the level of haze, which enhances visibility and text readability.
ULTRA HD Resolution
With the resolution that is 4 times higher than FHD, it makes the color and details of the contents more vivid and realistic. In addition, the wide viewing angle applied with an IPS panel, provides clear contents with no distortion.
High-Performance with webOS
Built-in Quad Core SoC can execute several tasks at once while providing smooth content playback without the need for a media player. Also, LG webOS smart signage platform enhances user convenience with intuitive GUI and simple app development tools.
Various Sensor Applications
LG webOS smart signage platform easily supports connections with external sensors such as GPIO, NFC/RFID, temperature sensors, etc, via USB plug-in. The overall cost for maintenance is reduced as there's no need to purchase additional software or media players for creating value-added solutions.
Compatible with AV Control System
The UH5F-H series has been certified Crestron Connected® for high compatibility with professional AV controls to achieve seamless integration and automated control*, boosting business management efficiency.
Compatible with Video Conference System
For the optimum visual meeting, the UH5F-H series has certified its compatibility with Cisco System that offers powerful and integrated control* for a smarter video conference, eliminating a waste of time for setting up the picture quality or changing input on incoming calls.
Real-time Monitoring & Control
Through the Control Manager, the embedded web monitoring solution, you can control and monitor the status of multiple UH5F-H series displays in different locations in real-time. It is available on internet connected devices, allowing you to flexibly and rapidly respond to emergency situations anywhere
Multiscreen Feature with PBP / PIP
PBP (Picture-By-Picture)features multiple screens in a single display with up to 4 input sources while PIP (Picture-In-Picture) supports playing both a main screen and a subscreen at the same time with various layouts. This gives great flexibility to allocate space for each content source.
Wireless Access Point
The UH5F-H series operates as a virtual router which can be an wireless access point for mobile devices.
