Product unavailable
This product is end of life or currently not available.
This product is end of life or currently not available.
Key Specifications
Choose one or multiple features to search for items that have the same specifications.
Specifications
Description
Store availability
Delivery
Price development
| Processor | |
| Processor manufacturer | Intel |
| Compatible processor series | Intel® Xeon® |
| Processor socket | LGA 4189 |
| Processor cores | 40 |
| Memory | |
| Maximum internal memory | 4 TB |
| Memory voltage | 1.2 V |
| Supported memory clock speeds | 2666,2933,3200 MHz |
| Supported memory types | DDR4 |
| Maximum RDIMM memory | 4 TB |
| Memory slots type | DIMM |
| Number of memory slots | 18 |
| ECC сompatibility | ECC |
| Weight & dimensions | |
| Width | 304.8 mm |
| Depth | 330.2 mm |
| Operational conditions | |
| Operating relative humidity (H-H) | 8 - 90% |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating temperature (T-T) | 10 - 35 °C |
| Storage relative humidity (H-H) | 5 - 95% |
| Networking | |
| Ethernet LAN |  |
| LAN controller | Intel® I350 |
| Ethernet interface type | Gigabit Ethernet |
| Internal I/O | |
| TPM connector | |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors | 3 |
| Number of SATA III connectors | 14 |
| Back panel I/O ports | |
| Serial ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 2 |
| VGA (D-Sub) ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 4 |
| Storage controllers | |
| RAID levels | 0, 1, 5, 10 |
| RAID support | |
| Supported storage drive interfaces | M.2, SATA |
| Packaging content | |
| Bundled software | Intel® Node Manager, IPMI2.0, KVM with dedicated LAN, SPM, SSM, SUM, SuperDoctor® 5, Watchdog |
| Expansion slots | |
| Number of M.2 (M) slots | 1 |
| PCI Express x16 (Gen 4.x) slots | 4 |
| PCI Express x8 (Gen 4.x) slots | 2 |
| BIOS | |
| BIOS type | UEFI AMI |
| Graphics | |
| Graphics card | AST2600 |
| Graphics card family | ASPEED |
| Features | |
| Motherboard chipset | Intel C621A |
| Motherboard form factor | Extended ATX |
| PC health monitoring | LED, Temperature, Voltage |
| Motherboard chipset family | Intel |
| Component for | Server |
| EAN | 0672042451463 |
| Warranty | 1 year |
| Source: Icecat.biz | |
3rd Gen Intel® Xeon® Scalable processors
Dual Socket LGA-4189 (Socket P+) supported, CPU TDP supports Up to 270W TDP, 3 UPI up to 11.2 GT/s
Intel® C621A
Up to 4TB 3DS ECC RDIMM, DDR4-3200MHz; Up to 4TB 3DS ECC LRDIMM, DDR4-3200MHz
Up to 4TB Intel® Optane™ Persistent Memory 200 Series, DDR4-3200MHz, in 18 DIMM slotsP1-DIMMB2 and P2-DIMMB2 are reserved for Intel Optane Persistent Memory 200 Series only.
2 PCI-E 4.0 x8,
4 PCI-E 4.0 x16,
2 PCI-E 4.0 NVMe x8 Internal Port(s)
M.2 Interface: 1 PCI-E 4.0 x4
M.2 Form Factor: 2280/22110
M.2 Key: M-Key
2 VGA (1 rear bezel, 1 front panel) ports
Intel® C621A controller for 14 SATA3 (6 Gbps) ports; RAID 0,1,5,10
Dual LAN with Intel® i350 Gigabit Ethernet Controller
Dual Socket LGA-4189 (Socket P+) supported, CPU TDP supports Up to 270W TDP, 3 UPI up to 11.2 GT/s
Intel® C621A
Up to 4TB 3DS ECC RDIMM, DDR4-3200MHz; Up to 4TB 3DS ECC LRDIMM, DDR4-3200MHz
Up to 4TB Intel® Optane™ Persistent Memory 200 Series, DDR4-3200MHz, in 18 DIMM slotsP1-DIMMB2 and P2-DIMMB2 are reserved for Intel Optane Persistent Memory 200 Series only.
2 PCI-E 4.0 x8,
4 PCI-E 4.0 x16,
2 PCI-E 4.0 NVMe x8 Internal Port(s)
M.2 Interface: 1 PCI-E 4.0 x4
M.2 Form Factor: 2280/22110
M.2 Key: M-Key
2 VGA (1 rear bezel, 1 front panel) ports
Intel® C621A controller for 14 SATA3 (6 Gbps) ports; RAID 0,1,5,10
Dual LAN with Intel® i350 Gigabit Ethernet Controller
