Key Specifications
Choose one or multiple features to search for items that have the same specifications.
Specifications
Description
Store availability
Delivery
Price development
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 8 |
| Console port | RJ-45 |
| Basic switching RJ-45 Ethernet ports type | 10G Ethernet (100/1000/10000) |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| SFP module slots quantity | 2 |
| Weight & dimensions | |
| Weight | 2 kg |
| Height | 152 mm |
| Width | 112 mm |
| Depth | 135 mm |
| Energy management | |
| Power consumption (typical) | 6 W |
| Power source | PoE |
| Input current | 6.3 A |
| AC input voltage | 120 - 230 V |
| DC input voltage | 9.6 - 60 V |
| Power supply included |  |
| Operational conditions | |
| Operating relative humidity (H-H) | 5 - 95% |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating temperature (T-T) | -40 - 70 °C |
| Non-operating altitude | 0 - 4572 m |
| Protocols | |
| Management protocols | IEEE 802.1, 802.3 standard, NTP, UDLD, CDP, LLDP, unicast MAC filter, PAgP, LACP VTPv2, VTPv3, EtherChannel, voice VLAN, PVST+, MSTP, and RSTP |
| Switching protocols | IGMPv1, v2, v3 snooping, IGMP filtering, IGMP querier |
| Networking | |
| Networking standards | IEEE 1588, IEEE 802.11ac, IEEE 802.11n, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ah, IEEE 802.3u, IEEE 802.3x |
| Link aggregation | |
| Broadcast storm control | |
| Spanning tree protocol | |
| 10G support | |
| Data transmission | |
| MAC address table | 8000 entries |
| Number of queues | 8 |
| Security | |
| Security algorithms | 802.1x RADIUS |
| MAC address filtering | |
| Access Control List (ACL) | |
| IGMP snooping | |
| BPDU filtering/protection | |
| Authentication | Guest VLAN |
| IGMP entries | 1000 |
| 2000 | |
| Access Control List (ACL) IPv6 entries | 512 |
| DHCP features | DHCP snooping |
| Certificates | |
| Certification | UL, BSMI CNS 13438 Class A, CISPR 24, cUL, EN55022, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, NOM, VCCI Class A ITE, IEC 60950, EN55 |
| Management features | |
| MIB support | 802.1X MIB, CISCO-DHCP-SNOOPING-MIB, CISCO-UDLDP-MIB, CISCO-ENVMON-MIB, CISCO-PRIVATE-VLAN-MIB, CISCO-PAE-MIB, Cisco-Port-QoS-MIB, CISCO-ERR-DISABLE-MIB, CISCO- PROCESS-MIB, LLDP-MIB, CiscoMACNotification-MIB, CISCO-CONFIG-COPY-MIB, LLDP-MED-MIB, Bridge-MIB, CISCO-CAR-MIB, CISCO-LAG-MIB, CISCO-SYSLOG-MIB, CISCO-FTP-CLIENT-MIB, CISCO-VLAN-IFTABLE-RELATIONSHIP-MIB, CISCO-VLAN-MEMBERSHIP-MIB, Cisco-REP-MIB, CISCO-PORT-STORM-CONTROL-MIB, CISCO-CDP-MIB, CISCO-IP-STAT-MIB, CISCO-LICENSE-MGMT-MIB, CISCO-STP-EXTN-MIB, CISCO-VTP-MIB, IEEE8023-LAG-MIB, SMON-MIB, CISCO-ACCESS-ENVMON-MIB, CISCO-CALLHOME-MIB, CISCO-CONFIG-MAN-MIB, CISCO-FLASH-MIB, CISCO-ENTITY-SENSOR-MIB, IP-MIB, CISCO-PAGP-MIB |
| Switch layer | L2/L3 |
| Quality of Service (QoS) support | |
| System event log | |
| Switch type | Managed |
| ARP inspection | |
| Packaging content | |
| Cables included | AC |
| Manual | |
| User guide | |
| Other features | |
| Connectivity technology | Wired |
| Design | |
| Rack mounting | |
| LED indicators | |
| Product colour | Black |
| International Protection (IP) code | IP20 |
| DIN rail mounting | |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | |
| Total Power over Ethernet (PoE) budget | 480 W |
| Performance | |
| Internal memory | 4000 MB |
| Mean time between failures (MTBF) | 611.35 h |
| Flash memory | 1500 MB |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
| Multicast features | |
| Multicast support | |
| EAN | 0889728321679 |
| Warranty | 1 year |
The Cisco Catalyst IE3300 Rugged Series is an L2/L3 managed switch for structured network deployments. It features eight 10G Ethernet RJ-45 ports for high-bandwidth local connections. Integrated Power over Ethernet (PoE) provides a total power budget of 480 W to connected endpoints via standard data cabling. Network access is managed through 802.1x RADIUS authentication, ARP inspection, and DHCP snooping.
The switch features a rack-mountable black chassis, weighs 2000 g, and fits standard equipment cabinets. It has a typical power consumption of 6 W and an IP20 rating. Administrators use an RJ-45 console port to configure Access Control Lists (ACLs) and link aggregation. The system includes 4000 MB of RAM and 1500 MB of flash storage for routing configurations.
Key Features:- MAC address table capacity of 8000 entries for tracking local network hardware.
- Eight hardware queues for precise traffic prioritization and Quality of Service (QoS) management.
- Broadcast storm control and spanning tree protocol support to maintain network stability during topology changes.
- Multicast handling through IGMPv1, v2, and v3 snooping, filtering, and querier protocols.
- MAC address filtering and Guest VLAN authentication for isolating specific endpoint traffic.
