Key Specifications
Choose one or multiple features to search for items that have the same specifications.Technical details | |
Product type | Processor |
Processor cache | 4096 KB |
Status | Discontinued |
Launch date | Q1'10 |
Bus type units | GT/s |
Bus bandwidth | 2.5 |
Maximum memory | 16.38 GB |
Processor brand name | Intel Core i5 vPro |
Last change | 63903513 |
Product family | Previous Generation Intel Core i5 Processor |
Processor | |
Processor model | i5-650 |
Processor lithography | 32 nm |
Processor family | Intel Core i5 |
Box | |
Processor socket | LGA 1156 (Socket H) |
Stepping | C2 |
Processor cores | 2 |
Processor code | SLBLK |
CPU multiplier (bus/core ratio) | 24 |
Processor threads | 4 |
Processor operating modes | 64-bit |
Processor boost frequency | 3.46 GHz |
Processor cache | 4 MB |
Bus type | DMI |
Processor frequency | 3.2 GHz |
Processor codename | Clarkdale |
Processor cache type | L3 |
Processor series | Intel Core i5-600 Desktop series |
Memory bandwidth supported by processor (max) | 21 GB/s |
Processor ARK ID | 43546 |
Memory | |
Maximum internal memory supported by processor | 16 GB |
Weight & dimensions | |
Processor package size | 37.5 x 37.5 mm |
Energy management | |
VID Voltage Range | 0.65 - 1.400 V |
Thermal Design Power (TDP) | 73 W |
Operational conditions | |
Maximum operating temperature | 72.6 °C |
Tcase | 72.6 °C |
Other features | |
Maximum internal memory | 16777 MB |
Graphics | |
On-board graphics card model | |
On-board graphics card | |
On-board graphics card base frequency | 733 MHz |
Number of displays supported (on-board graphics) | 2 |
Processor special features | |
Intel® vPro™ Technology | |
Intel® Hyper Threading Technology (Intel® HT Technology) | |
Intel® Turbo Boost Technology | 1.0 |
Intel FDI Technology | |
Intel® Clear Video HD Technology (Intel® CVT HD) | |
Intel Dual Display Capable Technology | |
Intel® AES New Instructions (Intel® AES-NI) | |
Enhanced Intel SpeedStep Technology | |
Intel Trusted Execution Technology | |
Intel Enhanced Halt State | |
Intel VT-x with Extended Page Tables (EPT) | |
Intel Demand Based Switching | |
Intel 64 | |
Intel Virtualization Technology for Directed I/O (VT-d) | |
Intel Virtualization Technology (VT-x) | |
Conflict-Free processor | |
Features | |
Supported instruction sets | SSE4.2 |
PCI Express slots version | 2.0 |
Execute Disable Bit | |
Idle States | |
Thermal Monitoring Technologies | |
CPU configuration (max) | 1 |
Number of Processing Die Transistors | 382 M |
Embedded options available | |
Processing Die size | 81 mm² |
Number of Graphics & IMC Die Transistors | 177 M |
Graphics & IMC lithography | 45 nm |
Graphics & IMC Die Size | 114 mm² |
PCI Express configurations | 1x16,2x8 |
Maximum number of PCI Express lanes | 16 |
Physical Address Extension (PAE) | 36 bit |
Market segment | DT |
EAN | 0675901022712 |
Source: Icecat.biz |
Unleash the multimedia multitasker within
With intelligent performance that accelerates in response to demanding tasks, such as playing games and editing photos, the Intel Core i5 processor moves faster when you do.
The Intel Core i5 processor automatically allocates processing power where it's needed most. Whether you’re creating HD video, composing digital music, editing photos, or playing the coolest PC games - with the Intel Core i5 processor you can multitask with ease and be more productive than ever.
Get a major boost in PC power with the intelligent performance of the Intel® Core™ i5 processor
32nm dual-core processing runs two independent processor cores in one physical package at the same frequency.
Intel® Turbo Boost Technology maximizes speed for demanding applications, dynamically accelerating performance to match your workload—more performance when you need it the most.
Intel® Hyper-Threading Technology delivers two processing threads per physical core for a total of four threads for massive computational throughput. This 4-way multi-task processing allows each core of your processor to work on two tasks at the same time.
Intel® HD Graphics provides superb visual performance for sharper images, richer color, and life-like video and audio. Available on select models of the all new 2010 Intel® Core™ processor family.
Integrated memory controller enables two channels of high-speed DDR3 1333 MHz memory. This memory controller's lower latency and higher memory bandwidth delivers amazing performance for data-intensive applications.
Intel® Smart Cache is a shared cache dynamically allocated to each processor core, based on workload. This efficient, dual-core-optimized implementation increases the probability that each core can access data from the fast cache, significantly reducing latency to frequently used data and improving performance. Optimized for industry-leading multi-threaded games.
