This product is end of life or currently not available.
System requirements | |
Windows operating systems supported | |
Mac operating systems supported | |
Linux operating systems supported | |
Ports & interfaces | |
Parallel ports quantity | 1 |
Ethernet LAN | |
Connectivity technology | Wired & Wireless |
Bluetooth | |
USB 2.0 ports quantity | 1 |
Wi-Fi | |
RS-232 ports | 1 |
USB port | |
Weight & dimensions | |
Weight | 2.35 kg |
Height | 173 mm |
Width | 200 mm |
Depth | 252 mm |
Printing | |
Colour | |
Maximum resolution | 203 x 203 DPI |
Print technology | Direct thermal / Thermal transfer |
Printing colours | Black |
Print speed | 178 mm/sec |
Maximum printing width | 10.8 cm |
Minimum print length | 6 mm |
Energy management | |
AC input frequency | 50 - 60 Hz |
AC input voltage | 100 - 240 V |
Operational conditions | |
Operating relative humidity (H-H) | 10 - 80% |
Storage temperature (T-T) | -20 - 60 °C |
Operating temperature (T-T) | 5 - 40 °C |
Storage relative humidity (H-H) | 10 - 90% |
Paper handling | |
Media thickness | 0.06 - 0.2 mm |
Ribbon length | 74 m |
Supported paper width | 20 - 110 mm |
Maximum roll diameter | 13 cm |
Packaging content | |
AC adapter included | |
Manual | |
Drivers included | |
Other features | |
LED indicators | |
Design | |
Display | No |
Product colour | Black, Grey |
Performance | |
Internal memory | 64 MB |
Flash memory | 128 MB |
Built-in barcodes | 1D, AZTECCODE, CODABAR (NW-7), Code 11, Code 39, Code 93, Code-128 Codabar Library, Data Matrix, EAN13, EAN8, GS1 DataBar, IMB, Industrial 2/5, Interleaved 2/5, MaxiCode, MicroPDF417, PDF417, POSTNET, QR Code, TLC39, UPC-A, UPC-E |
EAN | 5656565656562 |
Warranty | 2 years |
Source: Icecat.biz |
Compact desktop printer for 74 m ribbon
Label printer for Android mobile devices
Wireless shipping label printer
Wristband printer
1D and 2D Barcode printer
Flexible to Use
- Compatible with Android-based smart devices
- Triple interface supported: USB + Serial + Parallel
- Optional Ethernet and WLAN supported (USB dongle type)
Outstanding Form Factor
- Fast printing speed up to 7 ips (178 mm/sec)
- Quick data processing through powerful memory
- Compact design for 74m ribbon
- Energy-efficient product
Intelligent Function
Smart Media Detection™ is Bixolon’s world-class technology that detects label length and media types such as gap media, black mark media, and short length media paper. Intelligent Leap-over™ detects empty label and automatically leaps to the next label.
Premium-level Compatibility
Fully compatible with market-leading programming languages
User-friendly Design
- Various type of media sensor supported
- Easy paper loading with adjustable paper guide
- Simple to change ribbon, thermal print head, and roller
Label Artist™
Bixolon provides its custom label design program as bundle. It supports database connection as well as text, drawing lines and boxes, all kinds of graphics and 1D/2D Barcode printing.
