LG LSCB018-RK LED Signage P1.8mm 163inch FHD 800cd/m2 Front Service EMC Class B. wallmount webOS ready
Display | |
Pixel pitch | 1.88 x 1.88 mm |
Contrast ratio (typical) | 5000:1 |
Viewing angle, horizontal | 160° |
Viewing angle, vertical | 160° |
Display brightness | 800 cd/m² |
Display technology | LED |
Native aspect ratio | 16:9 |
Rated lifetime | 100000 h |
Native refresh rate | 3840 Hz |
High Dynamic Range (HDR) supported | ![]() |
High Dynamic Range (HDR) technology | High Dynamic Range 10 (HDR10), High Dynamic Range 10 Pro (HDR10 Pro) |
Energy management | |
Power consumption (typical) | 150 W |
Heat dissipation | 171 BTU/h |
AC input frequency | 50 - 60 Hz |
AC input voltage | 100 - 240 V |
Operational conditions | |
Operating relative humidity (H-H) | 0 - 80% |
Operating temperature (T-T) | -10 - 45 °C |
Certificates | |
Certification | CE EMC Class B, FCC, ETL, RoHS |
Design | |
Product colour | Black |
Placement supported | Indoor |
Product design | Digital signage flat panel |
Screen shape | Flat |
Performance | |
Purpose | Commercial |
International Protection (IP) code | IP30 |
EAN | 8806091526458 |
Warranty | 3 years |
Source: Icecat.biz |
LSCB Direct View LED Customizable to fit your needs
For added installation flexibility, the LSCB series offers half-height/ half-width and curved cabinets to create various types of screens, including customized curvature, concave and convex configurations.
Ultra Slim Depth
The LSCB Series’ ultra-slim cabinet design, with 37.5mm edge thickness, is its most significant advantage. This feature enables the LSCB Series to be installed and utilized in any type of venue without restriction.
Front and Rear Installation and Maintenance
The LSCB series cabinets can be accessed from the front or rear for maintenance for added convenience and enhanced installation options.
16:9 FHD/UHD Configuration
Each cabinet uses a 16:9 aspect ratio, the most commonly used in FHD and UHD content displays. This allows you to keep using existing content without additional cost and time for editing.
EMC Certified & Fire Resistant Design
The LSCB Series is safe from electromagnetic waves, harmful to the environment and human body, with EMC Class B Certification and is designed with fire protection certification to prevent the fast spread of flames even if it catches on fire.
Compatibility with LG Software Solution
Powered by LG’s high-performance system controller, the LSCB series is compatible with LG software solutions, including SuperSignCMS, LED Assistant, and ConnectedCare, which help customers operate their own business flawlessly.
