Key Specifications
Choose one or multiple features to search for items that have the same specifications.
Specifications
Description
Store availability
Delivery
Price development
| Ports & interfaces | |
| ATX Power connector (24-pin) |  |
| Floppy disk drive connector | |
| PCI Express connector | |
| Motherboard power connector | 24-pin ATX |
| Floppy drive power connector | 1 |
| Number of SATA power connectors | 9 |
| Peripheral (Molex) power connectors (4-pin) | 4 |
| PCI Express power connectors (6+2 pin) | 6 |
| Cabling type | Modular |
| Motherboard power cable length | 60 cm |
| SATA power cable length | 550,650,750 mm |
| Peripheral (Molex) power cable length | 550,650,750,850 mm |
| PCI Express power cable length | 85 cm |
| Floppy disk drive cable length | 10 cm |
| Weight & dimensions | |
| Weight | 3.17 kg |
| Height | 86 mm |
| Width | 150 mm |
| Depth | 150 mm |
| Energy management | |
| Input current | 5 - 12 A |
| Nominal power | 850 W |
| Power protection features | Over current, Over power, Over voltage, Short circuit, Under voltage |
| Combined power (+3.3V) | 120 W |
| Combined power (+12V) | 850 W |
| Combined power (+5V) | 120 W |
| Combined power (-12V) | 6 W |
| Combined power (+5Vsb) | 15 W |
| Max output current (+3.3V) | 24 A |
| Max output current (+12V) | 70.8 A |
| Max output current (+5V) | 24 A |
| Max output current (-12V) | 0.5 A |
| Max output current (+5Vsb) | 3 A |
| AC input frequency | 50/60 Hz |
| AC input voltage | 100 - 240 V |
| Total power | 850 W |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 50 °C |
| Design | |
| Product colour | Black |
| Number of fans | 1 fan(s) |
| On/off switch | |
| Cooling type | Active |
| Fan diameter | 13.5 cm |
| Fan location | Top |
| Performance | |
| Certification | TUV, CB, CE, FCC, RCM, cTUVus, WEEE, RoHS |
| Mean time between failures (MTBF) | 100000 h |
| Purpose | PC |
| Bearing technology | FDB |
| 80 PLUS certification | 80 PLUS Platinum |
| Power supply unit (PSU) form factor | ATX |
| EAN | 4250812438850 |
| Warranty | 1 year |
The EVGA SuperNOVA P5 joins the elite ranks of the EVGA 80 PLUS Platinum power supplies. These power supplies continue to push the envelope with the latest certifications and Intel� power-on standards. Replete with 80 PLUS Platinum-rated efficiency, a fully-modular cable design, 100% Japanese capacitors, and an ultra-quiet 135mm Fluid Dynamic bearing fan with EVGA ECO mode, these power supplies are built for performance and silence.
