Product unavailable
This product is end of life or currently not available.
This product is end of life or currently not available.
Key Specifications
Choose one or multiple features to search for items that have the same specifications.
Specifications
Description
Store availability
Delivery
Price development
| Processor | |
| Processor manufacturer | Intel |
| Compatible processor series | Intel® Xeon® |
| Processor socket | LGA 4189 |
| Memory | |
| Maximum internal memory | 4 TB |
| ECC |  |
| Memory voltage | 1.2 V |
| Supported memory clock speeds | 2666,2933,3200 MHz |
| Supported memory types | DDR4 |
| Memory slots type | DIMM |
| Supported memory module capacities | 8GB, 16GB, 32GB, 64GB, 128GB, 256GB |
| Number of memory slots | 16 |
| Weight & dimensions | |
| Width | 304.8 mm |
| Depth | 330.2 mm |
| Operational conditions | |
| Operating relative humidity (H-H) | 8 - 90% |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating temperature (T-T) | 10 - 35 °C |
| Storage relative humidity (H-H) | 5 - 95% |
| Networking | |
| Ethernet LAN | |
| LAN controller | Intel I210 |
| Ethernet interface type | Gigabit Ethernet |
| Internal I/O | |
| Number of COM connectors | 1 |
| TPM connector | |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors | 2 |
| Number of SATA III connectors | 10 |
| USB 3.2 Gen 2 (3.1 Gen 2) connectors | 1 |
| Back panel I/O ports | |
| VGA (D-Sub) ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 1 |
| Storage controllers | |
| RAID levels | 0, 1, 5, 10 |
| RAID support | |
| Supported storage drive interfaces | M.2, SATA III |
| Packaging content | |
| Bundled software | SuperDoctor® 5, SUM, SPM, Intel® Node Manager, SSM, Watchdog, IPMI (Intelligent Platform Management Interface) v2.0 with KVM support |
| Expansion slots | |
| Number of M.2 (M) slots | 1 |
| PCI Express x16 (Gen 4.x) slots | 5 |
| PCI Express x8 (Gen 4.x) slots | 1 |
| BIOS | |
| BIOS type | UEFI AMI |
| Graphics | |
| On-board graphics card model | Aspeed AST2600 |
| Features | |
| Motherboard chipset | Intel C621A |
| Motherboard form factor | Extended ATX |
| Audio output channels | 7.1 channels |
| PC health monitoring | Fan, LED, Temperature, Voltage |
| Component for | Server |
| EAN | 0672042451517 |
| Source: Icecat.biz | |
Supermicro motherboards support the latest generation Intel and AMD processors, memories and offer the most advanced technologies in the IT field – NVMe, M.2, 10GbE network ports. Thanks to their high scalability and a wide choice of form factors, the boards can fulfill the needs of even the most demanding customers. Supermicro offers the broadest selection of servers designed for industrial use, which is reflected in the overall quality of the boards. Materials that guarantee a long lifespan are used for manufacturing Supermicro motherboards, thanks to which a minimal failure rate is achieved. Supermicro motherboards go through a generational exchange approximately once every seven years, which guarantees long support by the manufacturer. Each Supermicro motherboard also allows free installation of specialized software for basic system monitoring.
