TP-Link AX6600 Tri-Band Wi-Fi 6 Gaming Router Tri-band - Wi-Fi 6 router
This product is end of life or currently not available.
Key Specifications
Choose one or multiple features to search for items that have the same specifications.Ports & interfaces | |
USB 2.0 ports quantity | 1 |
Ethernet LAN (RJ-45) ports | 5 |
DC-in jack | |
Memory card slot(s) | |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
USB port | |
Weight & dimensions | |
Height | 51.8 mm |
Width | 212 mm |
Depth | 212 mm |
Energy management | |
Output voltage | 12 V |
Output current | 5 A |
Power source type | DC |
Operational conditions | |
Operating relative humidity (H-H) | 10 - 90% |
Storage temperature (T-T) | -40 - 70 °C |
Operating temperature (T-T) | 0 - 40 °C |
Storage relative humidity (H-H) | 5 - 90% |
Protocols | |
Supported network protocols | IPv4, IPv6 |
DHCP client | |
DHCP server | |
Universal Plug and Play (UPnP) | |
Networking | |
Cabling technology | 10/100/1000Base-T(X) |
Ethernet LAN | |
Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
Ethernet LAN data rates | 10,100,1000 Mbit/s |
Port forwarding | |
Ethernet LAN interface type | Gigabit Ethernet |
Security | |
Access Control List (ACL) | |
Parental control | |
DMZ support | |
Firewall | |
Stateful Packet Inspection (SPI) | |
Wireless LAN features | |
Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
Wi-Fi band | Tri-band (2.4 GHz / 5 GHz / 5 GHz) |
WLAN data transfer rate (max) | 6600 Mbit/s |
WLAN data transfer rate (first band) | 4804 Mbit/s |
WLAN data transfer rate (second band) | 1201 Mbit/s |
WLAN data transfer rate (third band) | 574 Mbit/s |
Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
Management features | |
Reset button | |
WPS push button | |
Packaging content | |
AC adapter included | |
Cables included | LAN (RJ-45) |
Manual | |
Antenna | |
Antennas quantity | 4 |
Detachable antenna(s) | |
Design | |
LED indicators | LAN, Power, WLAN |
Product colour | Black, Red |
Indication light | |
On/off switch | |
Product type | Tabletop router |
Mobile networking | |
3G | |
4G | |
Features | |
Processor frequency | 1500 MHz |
Certification | FCC, CE, RoHS |
Processor cores | 4 |
Built-in processor | |
WAN connection | |
WAN connection type | RJ-45 |
DSL WAN | |
Ethernet WAN | |
SIM card slot | |
3G/4G USB modem compatibility | |
EAN | 6935364089696 |
Warranty | 3 years |
Source: Icecat.biz |
Faster. Broader. Unstoppable.
Higher speeds create less congestion for gaming rigs. Archer GX90 provides tri-band Wi-Fi 6 for outstanding online gaming experiences. One dedicated Gaming Band with HT160 offers 4.8 Gbps of bandwidth—more than enough for your gaming needs.
Battle-Tested Hardware.
Powerful quad-core CPU assures every packet of data is transmitted without delay even under heavy loads. The 2.5 Gbps gaming port breaks the gigabit bottleneck and unleashes huge throughput for your online play.
Keep Elements Secure.
Game Protector keeps your accounts and system safe. Alongside the latest WPA3 protocol, this HomeCare™ security system protects every device from the latest cyber threats, ensuring your total security while gaming online.
Flexible Whole-Home Wi-Fi
Eight high-performance antennas, Beamforming, and high-power FEM combine to deliver broad coverage. Furthermore, Archer GX90 supports OneMesh™ to form seamless whole-home coverage, preventing drops and lag when moving between signals.
