Key Specifications
Choose one or multiple features to search for items that have the same specifications.Technical details | |
Sustainability certificates | California Energy Commission (CEC) |
Ports & interfaces | |
ATX Power connector (24-pin) | ![]() |
Motherboard power connector | 24-pin ATX |
Number of SATA power connectors | 6 |
Peripheral (Molex) power connectors (4-pin) | 6 |
PCI Express power connectors (6+2 pin) | 6 |
Cabling type | Semi-Modular |
Motherboard power cable length | 60 cm |
SATA power cable length | 150,500 mm |
CPU power cable length | 70 cm |
Peripheral (Molex) power cable length | 150,500 mm |
PCI Express power cable length | 65 cm |
Weight & dimensions | |
Height | 150 mm |
Width | 150 mm |
Depth | 86 mm |
Energy management | |
Nominal power | 750 W |
Efficiency | 87.5% |
Combined power (+3.3V) | 120 W |
Combined power (+12V) | 750 W |
Combined power (+5V) | 120 W |
Combined power (-12V) | 3.6 W |
Combined power (+5Vsb) | 15 W |
Max output current (+3.3V) | 22 A |
Max output current (+12V) | 62.5 A |
Max output current (+5V) | 22 A |
Max output current (-12V) | 0.3 A |
Max output current (+5Vsb) | 3 A |
AC input frequency | 50 - 60 Hz |
AC input voltage | 100 - 240 V |
Total power | 750 W |
Operational conditions | |
Operating temperature (T-T) | 0 - 50 °C |
Certificates | |
80 PLUS certification | 80 PLUS Gold |
Packaging content | |
Cables included | AC, CPU, PCIe, Peripheral (Molex), SATA |
Design | |
Product colour | Black |
Number of fans | 1 fan(s) |
Cooling type | Active |
Fan diameter | 12 cm |
Fan speed | 0 - 2300 RPM |
Performance | |
Mean time between failures (MTBF) | 100000 h |
Noise level | 44.5 dB |
Purpose | PC |
Bearing technology | FDB |
ATX version | 2.52 |
EPS version | 2.92 |
Power supply unit (PSU) form factor | ATX |
EAN | 5060301697526 |
The NZXT C-Series C750 power supply delivers stable and efficient 750W power, making it an excellent choice for gaming PCs, workstations, and even providing headroom for overclocking. With its 80 Plus Gold certification, this PSU ensures high energy efficiency, reducing energy waste and keeping your system cool. The fully modular design allows you to use only the cables you need, minimizing clutter and improving airflow inside your case.
Designed to fit any case conforming to the ATX standard, the NZXT C750 supports NVIDIA GPUs up to the 3090 and AMD GPUs up to the RX 6800 XT. It features a zero RPM fan mode that keeps the fan silent under low-load conditions, and a dynamic 135mm fluid-dynamic bearing fan ensures efficient cooling when needed. Built with high-quality components and comprehensive protection features, this PSU provides safe and reliable power for your components.
Key Features- 750W Power Output: Provides ample power for gaming and enthusiast systems.
- 80 Plus Gold Certified: Ensures high energy efficiency and reduced heat.
- Fully Modular Design: Allows for clean cable management and improved airflow.
- ATX Form Factor: Compatible with most standard PC cases.
- 135mm Fluid Dynamic Bearing (FDB) Fan: Offers quiet and efficient cooling.
- Zero RPM Fan Mode: Fan remains off during low loads for silent operation.
- Supports High-End GPUs: Compatible with NVIDIA GeForce RTX 3090 and AMD Radeon RX 6800 XT.
- Active Power Factor Correction (PFC): Improves power efficiency and stability.
- Comprehensive Protection: Includes OCP, OVP, SCP, and OTP for added safety.
- 10-Year Warranty: Provides long-term peace of mind.
- Japanese Capacitors: Premium components for enhanced reliability and lifespan.
- NZXT C750 Power Supply
- 1 x 24-Pin ATX Power Cable
- 2 x 4+4-Pin CPU Power Cables
- 6 x 6+2-pin PCIe Power Cable
- 6 x SATA Cables
- 2 x Peripherals Cables
- 4 x 6-32 Screws
- 1 x AC Power Cord
- User Manual
