Thermaltake Smart BM3 550W - Power supply, 80 Plus Bronze
Manufacturer: THERMALTAKE
ID: PS-SPD-0550MNFABE-3
8090€
Show VAT 0%
Show VAT 25,5%
Multitronic Vaasa
Multitronic Pietarsaari
Multitronic Jyväskylä
Multitronic Lappeenranta
Multitronic Mariehamn
Key Specifications
Choose one or multiple features to search for items that have the same specifications.
Specifications
Description
Store availability
Delivery
Price development
| Ports & interfaces | |
| Motherboard power connector | 24-pin ATX |
| Number of SATA power connectors | 3 |
| Peripheral (Molex) power connectors (4-pin) | 7 |
| PCI Express power connectors (6+2 pin) | 2 |
| Cabling type | Semi-Modular |
| Motherboard power cable length | 60 cm |
| SATA power cable length | 150,500 mm |
| Peripheral (Molex) power cable length | 150,500 mm |
| Weight & dimensions | |
| Height | 86 mm |
| Width | 150 mm |
| Depth | 140 mm |
| Energy management | |
| Input current | 12 A |
| Nominal power | 550 W |
| Hold time | 17 ms |
| Power protection features | Over power, Over voltage, Overheating, Overload, Short circuit, Under voltage |
| Power Factor Correction (PFC) type | Active |
| Combined power (+3.3V) | 105 W |
| Combined power (+12V) | 550 W |
| Combined power (+5V) | 105 W |
| Combined power (-12V) | 3.6 W |
| Combined power (+5Vsb) | 15 W |
| Max output current (+3.3V) | 16 A |
| Max output current (+12V) | 45.85 A |
| Max output current (+5V) | 16 A |
| Max output current (-12V) | 0.3 A |
| Max output current (+5Vsb) | 3 A |
| AC input frequency | 50/60 Hz |
| AC input voltage | 100 - 240 V |
| Total power | 550 W |
| Operational conditions | |
| Operating relative humidity (H-H) | 20 - 85% |
| Storage temperature (T-T) | -40 - 55 °C |
| Operating temperature (T-T) | 5 - 45 °C |
| Storage relative humidity (H-H) | 10 - 95% |
| Certificates | |
| 80 PLUS certification | 80 PLUS Bronze |
| Design | |
| Product colour | Black |
| Number of fans | 1 fan(s) |
| On/off switch |  |
| Cooling type | Active |
| Fan diameter | 12 cm |
| Performance | |
| Mean time between failures (MTBF) | 100000 h |
| Safety | CE/UKCA/LVD/UKCA/FCC/ICES/TUV/CB/cTUVus/BSMI/CCC |
| Purpose | PC |
| ATX version | 3.0 |
| Power supply unit (PSU) form factor | ATX |
| EAN | 4713227539524 |
Thermaltake Smart BM3 550W 80 PLUS Bronze certified semi modular PSU, compatible with Intel’s ATX 3.0 specifications. Designed with a native PCIe Gen 5.0 connector, it can power up next-gen entry level GPUs with one 12VHPWR cable.
PCIe Gen 5.0 Ready
Smart BM3 Bronze series comes with a 16-pin connector to offer powerful and stable performance allowing the PSU to natively run next-generation GPUs.
The wattage marked on the 12VHPWR’s connector is the recommended wattage. (Ref. Intel design guideline)
The native 16-pin (12VHPWR) PCIe connector of the Smart BM3 550W can deliver up to 300W for PCIe 5.0 graphics cards.
Note:
Recommended wattage is an estimation of system power demand. Actual power demands may vary based on specific components, usage, and many other factors.
Please follow the recommended power requirements from the GPU manufactures before using the 12VHPWR cable.
PCIe Gen 5.0 Ready
Smart BM3 Bronze series comes with a 16-pin connector to offer powerful and stable performance allowing the PSU to natively run next-generation GPUs.
The wattage marked on the 12VHPWR’s connector is the recommended wattage. (Ref. Intel design guideline)
The native 16-pin (12VHPWR) PCIe connector of the Smart BM3 550W can deliver up to 300W for PCIe 5.0 graphics cards.
Note:
Recommended wattage is an estimation of system power demand. Actual power demands may vary based on specific components, usage, and many other factors.
Please follow the recommended power requirements from the GPU manufactures before using the 12VHPWR cable.
