Product unavailable
This product is end of life or currently not available.
This product is end of life or currently not available.
Specifications
Description
Store availability
Delivery
Price development
Ports & interfaces | |
Ethernet LAN (RJ-45) ports | 2 |
Weight & dimensions | |
Weight | 443 g |
Height | 40.8 mm |
Width | 180.4 mm |
Depth | 180.4 mm |
Energy management | |
Power over Ethernet (PoE) | ![]() |
Power consumption (max) | 9 W |
Operational conditions | |
Operating relative humidity (H-H) | 10 - 90% |
Storage temperature (T-T) | -10 - 60 °C |
Operating temperature (T-T) | 0 - 45 °C |
Protocols | |
Supported network protocols | IPv4, IPv6, 802.1Q, 802.1p, 802.1x, 802.11e/WMM |
Packaging data | |
Package weight | 774 g |
Package depth | 220 mm |
Package height | 79 mm |
Package width | 228.5 mm |
Security | |
Security algorithms | WEP, WPA, WPA2, WPA2-PSK, WPA3 |
Number of SSID supported | 32 |
Antenna | |
Antenna type | Internal |
Antenna gain level (max) | 4 dBi |
Design | |
Certification | FCC, CE, RCM, IC |
Cable lock slot | ![]() |
LED indicators | Status |
Product colour | White |
Placement | Wall |
Cable lock slot type | Kensington |
Features | |
Maximum data transfer rate | 1770 Mbit/s |
Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
Quality of Service (QoS) support | ![]() |
Ethernet LAN data rates | 10,100,1000 Mbit/s |
VLAN support | ![]() |
Maximum indoor range | 175 m |
2.4 GHz | ![]() |
5 GHz | ![]() |
MIMO | ![]() |
Maximum data transfer rate (2.4 GHz) | 573.5 Mbit/s |
Maximum data transfer rate (5 GHz) | 1201 Mbit/s |
Logistics data | |
Harmonized System (HS) code | 85176990 |
EAN | 6947273703518 |
Warranty | 1 year |
Source: Icecat.biz |
The GWN7660 is an enterprise-grade 802.11ax Wi-Fi 6 access point and offers dual-band 2x2:2 MU-MIMO with DL/UL OFDMA technology and a sophisticated antenna design for maximum network throughput, that allows businesses to build next-generation Wi-Fi networks for high-density environments.
The GWN7660 offers dual-band 2x2:2 MU-MIMO with DL/UL OFDMA technology and a sophisticated antenna design for maximum network throughput and expanded Wi-Fi coverage range. To ensure easy installation and management, the GWN7660 uses a controller-less distributed network management design in which the controller is embedded within the product’s Web user interface. The GWN7660 is also supported by GWN.Cloud and GWN Manager, Grandstream’s cloud and on-premise Wi-Fi management platform. It is the ideal Wi-Fi AP for voice-over-Wi -Fi deployments and offers a seamless connection with Grandstream’s Wi-Fi capable IP phones. With support for advanced QoS, low-latency real-time applications, mesh networks, captive portals, 256 concurrent clients per AP and dual Gigabit network ports with PoE/PoE+, GWN7660 is an ideal Wi-Fi access point for medium wireless network deployments with medium-to-high user density.
The GWN7660 offers dual-band 2x2:2 MU-MIMO with DL/UL OFDMA technology and a sophisticated antenna design for maximum network throughput and expanded Wi-Fi coverage range. To ensure easy installation and management, the GWN7660 uses a controller-less distributed network management design in which the controller is embedded within the product’s Web user interface. The GWN7660 is also supported by GWN.Cloud and GWN Manager, Grandstream’s cloud and on-premise Wi-Fi management platform. It is the ideal Wi-Fi AP for voice-over-Wi -Fi deployments and offers a seamless connection with Grandstream’s Wi-Fi capable IP phones. With support for advanced QoS, low-latency real-time applications, mesh networks, captive portals, 256 concurrent clients per AP and dual Gigabit network ports with PoE/PoE+, GWN7660 is an ideal Wi-Fi access point for medium wireless network deployments with medium-to-high user density.
