Ubiquiti UniFi WAN Switch (USW-WAN) - Managed switch, Grey
Manufacturer: UBIQUITI NETWORKS
ID: USW-WAN
31290€
Show VAT 0%
Show VAT 25,5%
Multitronic Vaasa
Multitronic Pietarsaari
Multitronic Jyväskylä
Multitronic Lappeenranta
Multitronic Mariehamn
Key Specifications
Choose one or multiple features to search for items that have the same specifications.
Specifications
Description
Store availability
Delivery
Price development
Manuals
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 1 |
| Gigabit Ethernet (copper) ports quantity | 1 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Basic switching RJ-45 Ethernet ports quantity | 1 |
| SFP+ module slots quantity | 3 |
| Power connector | AC/DC |
| Power cables quantity | 2 |
| Weight & dimensions | |
| Weight | 2.2 kg |
| Height | 43.7 mm |
| Width | 442.4 mm |
| Depth | 120 mm |
| Energy management | |
| Power consumption (typical) | 13 W |
| Number of power supply units | 2 |
| Power source | AC/DC |
| Redundant power supply (RPS) support |  |
| AC input frequency | 50/60 Hz |
| AC input voltage | 100 - 240 V |
| Power consumption (max) | 13 W |
| Power supply included | |
| Operational conditions | |
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | -5 - 40 °C |
| Networking | |
| 10G support |  |
| Data transmission | |
| Switching capacity | 20 Gbit/s |
| Maximum data transfer rate | 10 Gbit/s |
| Forwarding rate | 15 Mpps |
| Throughput | 10 Gbit/s |
| Certificates | |
| Compliance certificates | CE, Federal Communications Commission (FCC), Industry Canada (IC), National Defense Authorization Act (NDAA) |
| Management features | |
| Switch layer | Layer 2 |
| Switch type | Managed |
| Packaging content | |
| Cables included | Power |
| Rack mount kit | |
| Other features | |
| Bandwidth | 20 Gbit/s |
| Design | |
| Rack mounting | |
| Form factor | 1U |
| LED indicators | Network, System |
| Product colour | Grey |
| Reset button | |
| Housing material | SGCC |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | |
| EAN | 0810177160113 |
| Warranty | 2 years |
The Ubiquiti UniFi WAN Switch (USW-WAN) is a Layer 2 managed switch for network edge or WAN entry points. It provides high-speed backbone connectivity via three SFP+ slots and a single Gigabit Ethernet RJ-45 port for local management. With a total switching capacity of 20 Gbit/s, the switch manages traffic between internet gateways and internal hardware; its non-blocking architecture supports up to 10 Gbit/s across individual fibre links.
The grey SGCC steel housing is designed for standard 1U rack-mount installations. To ensure high availability, the chassis includes two independent power supplies for redundancy. Front-panel LEDs indicate network activity and system status for quick visual inspection. The design is intended for edge environments where installation space is limited, featuring a shallow depth that fits compact networking cabinets.
Key Features:- 15 Mpps hardware forwarding rate.
- 10 Mpps total throughput.
- 13 W typical and maximum power consumption.
- Data-link switching without Power over Ethernet (PoE) capabilities.
- Dimensions: 442.4 x 120 x 43.7 mm; mass: 2200 g.
